Notes: Tallin is a dual voltage controlled amplifier (VCA) with overdrive, offering some unusual control features and a range of attractive tonal characteristics. Each of the two identical channels offers two simultaneously available inputs for voltage control over signal attenuation or gain, with linear and exponential response to CV. Volume control knobs offer manual gain settings ranging from fully closed (-80dB) up to +18dB. A colour LED indicator displays output signal levels. A soft-clip circuit avoids harsh clipping distortion, while a switchable overdrive circuit offers two carefully crafted distortion responses, simulating the sound of classic tube amplifiers.

Since both CV inputs are simultaneously active, they can be jointly exploited within patches featuring more complex volume control that otherwise would require using two traditional VCAs in series. As the signal path is DC-coupled, Tallin can also be used for handling the control voltages.

Notes: Part of Xaoc's Leibniz subsystem, which processes signals and voltages by manipulating binary 8-bit numbers, the Poczdam allows switching between two data sources.

Supplier's Notes:
Poczdam is a binary data routing solution for the Xaoc Leibniz Subsystem. It facilitates manual and remote switching between two Leibniz data sources, modifying individual bits of the data stream, and re-clocking the data with its onboard voltage-controlled wideband oscillator or any external clock signal. Poczdam is particularly useful within complex Leibniz setups where the user needs to reconfigure the data flow between multiple modules. However, it can also be employed in small creative patches, e.g., for waveform splicing, disrupting rhythmic loops, or generating digital chaos.
To better understand the device and avoid common pitfalls, it is strongly advised to read through the entire user manual before use.

Component of the Leibniz Binary Subsystem
Routing Leibniz data
Reclocking Leibniz data
Additional CV clock generator (up to 2MHz)

6hp, 30mm deep
Current draw: +20mA/-10mA
Reverse power protection

The high quality Coal Mine black panels are available for all Xaoc Devices modules. Sold separately. Ask your favourite retailer.

Drezno is the input/output front-end of the system, consisting of an analogue-to-digital converter (ADC) and a digital-to-analogue converter (DAC), that alone can be used for manipulating analogue signals and voltages based on their binary representation.

Lipsk is a binary logic processing expander module that can flip (invert) individual bits of the digital signal representation. There are more Leibniz Binary Subsystem elements coming, with specialized and advanced sets of features.

Jena is a digital module that may be used as a flexible waveshaper for CV and audio signals, a wavetable oscillator, a Walsh function generator, or a rhythm generator.

Erfurt is a bi-directional digital counter, frequency divider. It has multiple applications: the output of the counter may be used as a phase source driving a digital wavetable, connected to other Leibniz modules it may scan waveshapes in Jena, produce stepped voltages useful for making interesting glissandi with Drezno and any VCO, generate gate patterns animating the spectrum of Odessa harmonic banks, spawn pseudo-chaotic sequences when fed back to Lipsk, etc.

Notes: User-friendly mid/side processing module. Tweak the stereo image or split a stereo signal into mid and side elements then route out to other modules for further processing before summing back together. Powerful.

Supplier's Notes:
Minsk is a stereo image processor. It is a hybrid tool that combines digital and analog processing to facilitate advanced mid/side (M/S) manipulation of a stereo signal pair. It allows for separate treatment of the mid and side components, which affects the depth and width of the auditory scene. Minsk offers both manual and voltage control of the stereo width, as well as two dimension effects for enhancing the existing stereo image or creating a faux stereo image based on the stereo or mono input source. Minsk is especially handy during the preparation of a vinyl release or before a club concert, because it can eliminate out-of-phase low-end frequencies (high pass filter at 300Hz with the filter slope 12dB/oct, 50Hz with the filter slope 24dB/oct).

Dimensions:
6 HP

Current Draw:
140 mA +12V
40 mA -12V
0 mA 5V

Notes: Lipsk facilitates the inversion of the individual bits produced by Drezno (or any other module connected to its input header at the back), and delivers the resulting code to its output header. Bit inversion can be manually controlled by pressing any of combination of its eight illuminated buttons, or it can be automated by patching gate signals into its gate input sockets. An active (5V) gate flips the state of the respective bit. If the button is active (bit already flipped), then the gate flips the bit again yielding double inversion (no inversion). The corresponding LEDs show the combined effect of both manual and gate actions. The bit processing logic is hardware-based, so there is virtually no latency, allowing the binary signals to be manipulated at extreme rates.

Notes: Gera is a component of the Leibniz subsystem that allows masking individual bits of the digital data by the use of logical AND operation.

It features 8 individual gate inputs that affect the individual bits of data, as well as 8 illuminated tact switches for manual inverting of each control input. When connected to Drezno that is processing a waveform or voltage, masking of individual bits yields various forms of quantization. However, Gera can function on its own. The AND operation is a basic building block for sequence automation, chaos and rhythm generation, and various computer-like modular patches.

Bit processing logic in Gera is hardware based, hence there is virtually no latency, and the binary signals may change at extreme rates.

Main features:

Logical AND operation on Leibniz data
Masking of individual bits controlled manually and by gate signals
Visual indication by illuminated buttons
6HP
30 mm depth (including ribbon cable brackets)
- +12V: +45mA / -12V: 0mA / +5V: 0mA

Notes: Add external feedback loops, tilt filters and more to the Timiszoara effects module with this versatile expander. A must-have for Timiszoara owners.

Supplier's Notes:
Deva is an expander for Xaoc Devices' Timiszoara multi-fx module designed for creative exploration of the dirty/nasty side of signal processing. Deva opens up the Timiszoara programs you've come to love with some unexpected twists and turns along the way. The analog side features two external feedback loops (for the left and right channel) with tilt filters adjustable via sliders with two additional switches for choosing positive or negative feedback (for each channel). The third slider controls the DAC clock - from overclocking by a factor of two down to 16-times slower, so you can go from chipmunk to hardcore teeth gnashing of underclocked goodness. A switch allows for turning the clock control off for normal/regular operation. All features have inputs for external CV.

Technical details

Eurorack synth compatible
8hp, skiff friendly
Power drawn from Timiszoara: +60mA/ -50mA
Reverse power protection

Notes: The tiny but mighty Eurorack power supply with all the bells and whistles

Micronova is a miniature power supply with a big soul. It can provide up to 18W of power for your modules and multiple units can be easily daisy chained to power larger systems.

This bundle includes:

an assembled Micronova
an assembled Micronova busboard
a Micronova front entry kit

Please note that the front entry requires assembly. It's a delightfully easy kit, but make sure you know what you're getting into!

A suitable AC-DC power adapter is required. We have adapters available for domestic customers. International customers please take a look at the manual for guidance and recommendations.

Check out the manual to get to know Micronova and all of the delightful ways you can integrate it into your case.

100 mm x 30 mm x 13 mm
15-20V, 1.5A
+12V @ 1A
-12V @ 300mA
+5V @ 500mA
Daisy chainable
Busboard included
Front entry kit included

Notes: DASSBRUM is a powerful kick module capable of producing a wide variety of sounds, ranging from classic kick tones to complex folded timbres. It features an analogue core processed through a digitally controlled matrix of analogue wave folders and envelopes, offering deep sonic flexibility in a compact 8HP form factor. A built-in sweet spot mode ensures optimal pitch envelope relationships for consistently punchy and dynamic kicks.

Consumption: 120mA +12V /30mA -12V
Width: 8HP
Depth: 29mm

Inputs maximum ratings
Fold type (rear switch): 0/5V
Trigger IN: 5V (>0.5V)
Other inputs: -5/10V

Notes: EME (Eloquencer MIDI Expansion) is the perfect companion for the Eloquencer, adding capabilities to sync with MIDI devices, control most of the eloquencer parameters with MIDI interfaces, generating MIDI voices from the eloquencer tracks, and converting MIDI signals to the eurorack world.

Description:
MAIN FEATURES
IN / OUT
DIN-5 MIDI Input, DIN-5 MIDI Output, USB Host.

BUTTONS
4 freely assignable buttons. They can be assigned to:

Next/previous pattern
Next/previous part
Direct access to Pattern mode, Play parts, Duplicate, Project, Gate REC, CV Key REC, MIDI key REC, Free Play...
Save current project
Random 1 to 3 layers of selected track
Reset LFO of selected track
On/Off LFO of selected track
Freeze
Revert
Fill A to H or selected track
Mute A to H or selected track
DJ Nudge FWD/BCK fine/coarse

MIDI CLOCK
Eloquencer can receive 24ppqn sync from MIDI device from its DIN-5 MIDI Input, and can send 24ppqn MIDI clock through its DIN-5 MIDI out.
When working as 'internal' it will send the internal clock to the MIDI output.
When working as 'external' will send the eurorack incoming clock to the MIDI output transformed into 24ppqn.

MIDI OUT
The Eloquencer tracks can be independently assigned to:
- Voice events (note on/off, velocity, ch pressure...) For example Track A can be assigned to Channel 1 Note on/off and Track B can be assigned to Channel 1 Velocity, so track A gates and CV control Channel 1 notes and pitch, and track B controls Channel 1 Velocity.
- Control Change (CC)
- Program Change (PC)

The gate and CV output will work as usual when a MIDI OUTPUT is assigned, so voices can be doubled using the modular and an external synth.

There's a particular execution order for MIDI out events, so the first to be launched is the Program Change, followed by the CC and then the voice events. This way, we can launch program changes before the note on message is received allowing preset changes for each step.

MIDI IN
Both, the DIN-5 MIDI in and the USB can be used to change eloquencer parameters using controllers or to introduce notes in REC MODE using a keyboard.

There are 3 different groups of controls associated to MIDI channels:
- Channel : 8 MIDI channels to control parameters of specific tracks from A to H
- Global : 1 MIDI channel to control Global parameters.
- Focus: 1 MIDI channel to control the parameters of the currently selected track (track in focus). That means that if Track A is selected and we send CC 38, we will be shifting track A, but if we select track B and we send the same CC 38, we will be shifting track B.

When using the USB host input, the EME can send feedback information in case the controller that is being used has LEDs to be updated.

There is a big amount of eloquencer parameters that can be controlled using an external MIDI interface / controller. For example:

Non-destructive track parameters addition/subtraction (CV, CVP, CVR, GL GLP, R...)
Track length
Step mode / Step mode DIV / Step mode REP
Track shift
LFO on/off / Type / Length / amplitude.
Fill
Mute
Random
CV Gate link
Scale group and root
Tempo
DJ Nudge
Shuffle
Clock out
Play / Stop
Direct access to modes (Pattern, Project, Live REC...)
MIDI INTERFACE

A MIDI Channel can be assigned to an Eloquencer Track, so the gate and CV outputs will stop listening to what is sequenced and start listening all note on/off messages coming from the chosen MIDI channel.

Notes: The Z4000 NS is a snappy voltage-controlled analog envelope generator with a built-in CV processor for scaling, inverting, and voltage-controlled deviating of the envelope shape. The Z4000 generates an envelope made of the four classic segments: Attack, Decay, Sustain and Release, in which each segment can be manually set using knobs or dynamically set under voltage control.

Control knobs for the Attack, Decay, and Release segments are scaled. The first 0-50% of the knobs rotation is dedicated to high resolution adjustment in the millisecond range.

The output levels are fully adjustable with signals that can reach up to 10V in either polarity and can be mirrored into the opposite polarity or clipped using the voltage-controlled deviater-scaler. A bi-color LED indicates intermediate values in both polarities and their crossfade state.

The Attack slope switch allows selection of a logarithmic or exponential curve for the Attack segment. This subtle effect helps further the fine adjustment of the Attack segment slope. A Shoot button is provided to let you fire the envelope manually. The Z4000 also provides a retrigger input allowing you to create legato notes when using a classic keyboard interface.

Going down to nuts and bolts, the Z4000's smoothness and snappiness is made possible by a four segment active-charge discrete circuit which is an extended version of circuits found in classic two segment rise / fall transient generators.

Size: 8HP
Depth: 28mm
Power: +12V 34ma / -12V 18ma

Notes: The SD909 adapts the iconic TR-909 snare drum and noise generator for use in the Eurorack modular synthesizer format. Tiptop painstakingly tested the module in their lab to sound like a fresh machine coming off of the assembly line back in the 80s. On top of the original circuit, Tiptop have added new features that expand the palette of what can be produced with this analogue circuit.

The sound of the SD909 consists of two main sections: the binary noise generator and two modulated triangle oscillators. The oscillators provide the low end punch while the noise makes up the upper sonic spectrum, resulting in a combination that makes the 909 snare sound so rich. In the SD909 module, the noise generator and oscillators are variable and voltage-controllable, pushing the circuit beyond its original boundaries, offering new sounds and many variations of the original tone. The panel also has markings to guide setting the knobs to reproduce the vintage snare sound of the original machine.

Just like the other drums in this series, the SD909's high-powered output gain stage allows further enhancement of the sound through distortion and clipping. Tiptop have designed a dual pulse-shaper circuit on each gate input so you can trigger your SD909 with Trigger/Gate signals from step sequencers, clock dividers, or any other pulse/clock sources. Also, the SD909 is equipped with access to the MIXZ MixBus, matching the rest of the Tiptop line of percussive modules.

TR-909 is a Trademark of Roland Corp Japan

Size: 8HP
Depth: 46mm
Power: +12V 35ma / -12V 30ma

Notes: MIXZ is a multi-channel mixing module for mixing audio, CV, and gate signals with excellent linear response and low noise. Balancing a clear visual layout and multiple mixers in a small footprint makes the MIXZ easy to use in a variety of configurations within a modular synth. Its high-quality analog mixing circuitry makes for a great sounding mixer with plenty of headroom, providing a smooth, organic merge of dynamics and excellent separation of mixing sections and channels. MIXZ has three sections:

Mixer A: a low-noise, 4-channel mixer with independent gain control for each channel.
Mixer B: a low- noise, 4-channel mixer with master gain control.
MixBus: a multi-channel mixer that mixes signals from modules utilizing the Tiptop MixBus.

Mixer A and B can be configured as either two independent, 4-channel mixers or as a single 8-channel mixer. If the output of Mixer A is not in use, then Mixer A will be routed internally to Mixer B forming the 8-channel mixer.

Tiptop MixBus is a new method we have developed to mix audio signals through the Eurorack power bus board without patch cables. A little bit of magic, eh? Although this technique is not ideal for a low-noise mix, we found it to be useful for some applications, including mixing our drum modules, which all have a MixBus-enabled output. The result is that your drum modules are always available and mixed on the master out of the MIXZ with a flip of a switch. This will save you time and frees up cables for repatching sound again and again, while keeping the channels of MIXZ free to bring other signals into the mix.

Combining the MixBus with Mixer A and B, the MIXZ sums dozens of channels in only 10HP.

Dimensions:
10 HP
36 mm deep

Current draw:
14 mA +12V
14 mA -12V

Notes: Introducing the HATS909, part of TipTop's new series of drum modules that brings those classic percussion sounds into the modular synth world, instantly turning your system into a self-contained music machine.

The HATS909 is the TR-909's original Closed and Open Hi-Hats circuits adapted for use in Eurorack modular synthesizer format and was designed to sound like a machine coming fresh off the assembly line back in the 80's. Improving on the original, TipTop have added some great new features that expand the sound palette that can be produced with this small, powerful module.

The original TR-909 circuit is made with a combination of low-fi sound samples that pass through a series of analogue elements to provide envelope and filtering to the source sound. The HATS909 module allows for manual and voltage control of the sample's tuning, which provides anything from crushed hats and short ticks to the original sound and anything between. Additional controls allow you to send a voltage control signal to either the tune input or the internal VCA for modulation with external control signals and, using a modulation switch, add AM or FM synthesis in the audio range from external oscillators, other drum sounds, or just about any other sound source. Lastly, HATS909 also offers a switch that allows you to tap directly into the raw output of the module for a unique sound source that can used throughout your system.

Just like the other drums in this series, the HATS909 high-powered output gain stage allows you to further harmonize the sound through distortion and clipping. On each gate input, Tiptop have designed a dual pulse-shaper circuit so you can trigger your HATS909 with trigger/gate signals from step sequencers, clock dividers, or any other pulse/clock sources.

TR-909 is a Trademark of Roland Corp Japan

Size: 8HP
Depth: 36mm
Power: +12V 33ma / -12V 22ma

Notes: Introducing the HATS808, a drum module that brings the classic TR-808 closed and open hi-hat sounds to the Eurorack modular synth format. This module includes features like independent accent levels, a high-powered gain stage, dual input pulse-shaper, and adjustable Filter Q and VC-Q knobs for additional tuning.
The HATS808 uses six analogue square wave oscillators to create its signature sizzling sound, maintaining the unique metallic character of the original. The original "choke" circuitry is fully implemented but can be disabled if needed. The high-powered gain stage allows for further sound harmonization through distortion and clipping. The dual pulse-shaper circuit ensures consistent sound quality from any pulse source, making the HATS808 an easy and powerful addition to any modular synth setup.

TR-808 is a Trademark of Roland Corp Japan

Size: 8HP
Depth: 14mm
Power: +12V 30ma / -12V 25ma

Notes: Introducing the CYMBL909, part of Tiptop's new series of drum modules that brings those classic percussion sounds into the modular synth world, instantly turning your system into a self-contained music machine.

CYMBL909 is a dual voice module containing the TR-909's original Crash and Ride circuits adapted for use in Eurorack modular synthesizer format and was designed to sound like a fresh machine coming out of the assembly line back in the 80's. On top of the original, Tiptop have added some great new features that expand the sound palette of what can be produced with these two voice circuits.

The original circuits use a combination of low-fi 6-bit sound samples that pass through a series of analogue elements that provide envelope and filtering to the source sound. The CYMBL909 module adds manual and voltage control of the sample's analogue tuning section creating tones which range from heavy industrial at the low end, to the original crash/ride sound at the mid range, and bright hats-like sounds at the top end. Modulating the tune with an envelope, CV sequencer, or LFO makes interesting sound bending effects, which can be applied either in or out of sync with the triggering of the sounds.

Just like the other drums in this series, the CYMBL909 high-powered output gain stage allows you to further enhance the sound through distortion and clipping. Tiptop have designed a dual pulse-shaper circuit on each gate input so you can trigger your CYMBL909 with trigger/gate signals from step sequencers, clock dividers or any other pulse/clock.

TR-909 is a Trademark of Roland Corp Japan

Size: 8HP
Depth: 46mm
Power: +12V 60ma / -12V 40ma

Notes: Reverse-engineered from the original machine, the BD909 is an identical recreation of the original all-analogue drum circuit of the TR-909. Tiptop have added additional controls and synthesis features that turn this classic circuit into a chest-pounding analog bass drum laboratory - all tightly packed into an 8HP module. The BD909 sound differs from the BD808 in that the main sonic energy is centered in the mid to low frequency range (as opposed to the low frequency range of the BD808). This frequency range gives the needed headroom allowing your bass lines to deeply fill up the low end while the kick drum rides on top - creating a clear and punchy mix.

The BD909 includes all the controls found in the original: Attack, Decay, Tune Decay, Accent, and Level. Tiptop have gone beyond that and added controls that further increase the palette of sound this circuit is capable of. First off, a tuning control knob has been added for the oscillator and included its own CV input and attenuator that let you tune the 909 kick with your bass lines. Next, control knobs have been added for the tuning attack and extending tuning decay. Each one affects the other, allowing for intuitive and interactive sound shaping, opening Z8000 up numerous "sweet spots" and provides the ability to center the energy peak at different parts of the sound. Finally, Tiptop have offered additional punch and distortion by giving complete control over the internal waveshaper, which allows you to overload the waveform manually or with voltage control.

Beginning with the classic and pure sound of the 909 kick, these additional functions greatly expand the BD909's flexibility and let it create powerful analogue bass drums that range from soft and smooth to punchy and aggressive - and everything in between.

TR-909 is a Trademark of Roland Corp Japan

Size: 8HP
Depth: 36mm
Power: +12V 34ma / -12V 21ma

Notes: Smith: it's an 8 inputs & 8 outputs precision buffered matrix with presets. Each of the 8 outputs can take the signal from any of the 8 inputs, allowing over 16 million possible combinations.

This is not a mixer, the same input can be routed to many outputs, but several inputs can't be present at the same output simultaneously. The module works with both audio and CV signals, ins & outs have i10 volts range and minimum offset (1 millivolt approx.), which makes it perfect for distributing V/Oct signals too.

8 scenes that can be accessed through the dedicated push buttons but also by CV and trigger. 8 banks (with 8 scenes each, 64 scenes per preset). 8 persistent presets (with 8 banks of 8 scenes each).

This module can be used to store 'presets' for your live setup, allowing patch changes and easy rerouting signals with literally just pressing a button.

Another (more chaotic) way to use it is to plug several modulation sources to the inputs (such as envelopes, LFOs, sequenced CVs) and several modulation destinations to the outputs (filter cutoff, PWM, VCAs...). If you want to introduce a variation in the sound, select a different scene or directly randomize the current one to drastically change 'what is modulating what'.

Using audio sources can lead us to interesting territories too, sequencing waveform changes or using different processors (filter, distortion, folder...). Keep in mind that the switch performs pretty fast and the signal is passed without any modification (to preserve its accuracy, which is pretty important when using the module for v/oct) so with audio, the switching may be clicky. This depends on the sound source too, with 'dirty' ones there's no problem but with clean ones, like low pitched sine waves, it will be.

Notes: vcA Team is a dual Voltage Controlled Amplifier conceived with dynamic expression control in mind.

With Velocity control over both VCA channels, vcA Team expands the creative use of amplitude variations on your patch, bringing not only control over the contour but also over the loudness of your sound .

Each VCA is coupled with an extra linear VCA cell, for a simple and direct approach to Velocity control. The Velocity input can be modulated by the Velocity CV output of your keyboard or any other CV signal on your rack.

Linear or exponential response is available at the flip of a switch and an attenuator-inverter potentiometer is also implemented to attenuate or invert the CV input.

All inputs are DC-coupled, leaving the door open for processing audio signals or control voltage signals.

An additional Mix output sums the two VCA outputs into a single output, turning the vcA Team into a two channel mixer.

Features:

Dual VCA.
Velocity control over both VCA channels.
Linear and Exponential response.
CV input with Attenuator-Inverter.
Mixed output.
DC-coupled inputs.


Specs:

Width: 6HP
Depth: 33mm
Power consumption: 65mA +12 / 65mA -12
Eurorack Format
Doepfer power connection

Notes: The TBD module is a multifunctional DSP (digital signal processing) module that includes more than 30 different synthesis and audio processing plugins. It is a collaboration project between CTAG Kiel (an academic working group of Kiel University of Applied Sciences), instrumentsofthings.com (who produce this module for Eurorack) and tangiblewaves.

The module looks quite simplistic with it's only three knobs and three buttons, but the power lies in the web based user interface for editing and storing the parameters. For editing, the module is connected via USB to your computer and a small software tool running here is the bridge to the editing of the parameters via your web browser. IMPORTANT TO KNOW: When the editing is done, the module runs autonomously, without a computer!

Up to 10 favourites can be stored on the module and be chosen by the CONFIG button.

Dynamic control of the modules' parameters works via the two CV inputs and two trigger inputs (which are linked to two buttons), and two knobs are also available for live tweaking parameters. The assignment of inputs/knobs to actual parameters is done in the web based user interface.

Please note that the TBD module has mono audio input and output (compared to the Eurorack version which is stereo); plugins that do stereo audio work also in the AE TBD, but only on one channel. ("Why only mono?" you might ask; the limitation to mono is due to licensing agreements to keep the module price in the usual AE range.

The contained plugins are:

Talkbox (Vocoder), MSxxNoise (MS20 filter and Stone Phaser), Antique (Old Record / Tape Effect), Subotnik (Huge Modulations), VctrSyn, SpaceFX, Formantor, Bjorklund, Karpuskl, APCpp, Retroactor, Rompler (sample playback), WTOsc (custom wavetable), Claude (ported MI granular audio processor), BBeats, CStrip, CStripM, EveryTrim, MISVF, TBD03, PolyPad, TBDings (ported MI resonator), TBDaits (Ported MI Macro Oscillator), TBDeeps (ported MI Wavetable Oscillator), DustLoop, Dust, SubSynth, Sine Source, Simple VCA, SDelay, Plate Reverb, Pink Noise, MiVerb, MiVerb2, MiPShift, MiEnsemble, MiChorus, HiHat1, G-Verb, Freeverb, FBDlyLine, EChorus, Progen Reverb, CDelay

Notes: The SAMPLYR module is a sample player module, that plays sample files from a microSD card.

The samples are simple 8-bit mono WAV files. Features of the module are:

CV control for pitch with 1V/octave
Gate input
NO (practical) LENGTH LIMIT for the sample playback, because the module plays the samples directly from the memory card
Sample is displayed on the included OLED display
For each sample, following playback parameters can be edited: Sample start/end, loop start/end, loop crossfade, transpose/tune, all this settings are visible in the display and are saved per sample
Different loop modes can be selected: Oneshot, Reverse, Loop forward/reverse/alternating, loop hold (loop remains playing when gate goes to off)
Editing of the different parameters is accomplished with an endless encoder and a small menu
CV control for playback start, loop start, loop length, reverting playback, sample selection
Six buttons can be used for quick switching between six samples of the current folder
Additionally to the audio output, the SAMPLYR provides trigger outputs for loop start point, loop end point, playback end; by this, certain other operations can be triggered at these specific points, e.g. synchronizing to the loop points.

...and all this in a 1 unit AE module!

The sample files are organized as simple folders on the micro SD card named "A"..."Z" and per folder files named "0....wav, 1....wav, ..."

Included with the module is a micro-SD card with some demo samples; and each buyer will receive an update for the factory samples, made by the sound designer "empty vessel" exclusively for the SAMPLYR module (provided as download later this year).

The SAMPLYR module is of course not a hi-fi, high quality sampler module due to its 8-bit design. It has the flavour of the early samplers like EMU II, Fairlight CMI IIx, Ensoniq Mirage... The typical, recommended sample rate is 16000 Hz. these samples can be pitched up by approx. 1 1/2 octaves max.

Beyond the 8-bit resolution, the samples can be also encoded as uLaw and aLaw; in this case, the resolution is true 10 bits. For converting your existing samples, the open-source audio editor "Audacity" is great for the conversion and editing process.

Note: The SAMPLYR module is a sample player only; it doesn't offer recording of audio.

Notes: CIRRUS is a real-time granular processor for audio signals. This module is a 100% adaption of Mutable Instruments' Clouds module, a well known module in the Eurorack world.

The incoming audio signal is divided into separate short particles of selectable size, pitch and shape; these so called "grains" are then recombined in real-time in various assignments and by different algorithms, resulting in interesting, moving textures. This is even more intensified by allpass filters and a reverb, so even a short input pulse results in a huge wash of sound.

The audio processing works on up to 32kHz sampling rate in stereo and 16bit resolution for input and output (and can be reduced to 16kHz, 8bit mono for an increased sampling time of 8 seconds). Even with a mono input signal, a wide stereo output is simulated by randomly panning grains and the reverb.

A freeze button freezes the audio buffer and the sonic qualities can still be explored with the parameters in real-time..

All parameters can be CV controlled, of course.

Notes: The SetonixSynth Marsupial is a new dual filter design based around the re-issued AS3350 filter IC, originally used in rare synths such as the Synton Syrinx, Crumar Spirit and Rhodes Chroma but never widely utilized. Normalization between the control inputs and a Series/Parallel switch makes it simple to dial in a huge variety of unique and musical filter sounds.

Current draw: 36mA @ +12V; 35mA @ -12V

Eurorack width/depth: 8hp; 25mm

Notes: Motion Pictures

(Delay And Reverb)

Motion Pictures combines lush delay and reverb with intuitive, powerful controls within a 10HP module. Choose between a crisp digital delay or a warm analogue delay and pair it with a spacious, large-hall stereo reverb. Delay and reverb levels can be adjusted independently, allowing you to use them separately or together. The delay time can be controlled using a knob, tap tempo, or CV. You can even send opposing CV signals to the tap tempo and delay time for glitchy, pitch-bending, rhythmic effects. Additionally, CV control extends to the feedback, delay, and reverb levels, providing greater flexibility. Motion Pictures offers rich ambient sounds in a compact design, combining delay and reverb in one module to optimize rack space while preserving sonic depth.

Notes: Cutting Room Floor V3 Eurorack Module

(Vintage Reel-to-Reel Tape, Echo, and Stutter)

The Cutting Room Floor was designed to emulate the sound and functionality of vintage reel-to-reel tape overdrive and echo. This eurorack module reaches into the 21st century with customized features that traverse the world of modulation and delay. Imagine an abandoned factory with a fluttering tape machine left on repeat.

The Cutting Room Floor provides beautifully marred saturated tape tone, and ethereal repeats in a streamlined 6hp interface. Other features include a freeze button that traps any tone while still playing and CV control for time.

Designed and assembled in Seattle, Washington. Includes a limited 1-year warranty, if registered within 30 days of purchase.

6hp, 43mm deep, 150ma current draw.

Notes: Really nice approach to sequencing from Omni-Tone. The Melodi generates 'semi-random' patterns based on tunable parameters and probabilities. Dial in combinations of scales, pitch range, tempos and so on to create unique melodies.

Supplier's Notes:
Melodi generates sequences based on the mood you set so you can create the sound you're searching for- it can be tweaked to create anything from a powerful bassline to a sparkly melody.

Ships with version 2 of firmware

Improvements: Skip, tie, length are now LIVE knobs. Added a ping-pong trend line and a blues scale.

GENERATE

1. NEW - will prompt Melodi to generate a new sequence.
2. TRIGGER IN - accepts a trigger to prompt Melodi to generate a new sequence.

CYCLE

1. ON/OFF - determines if the sequence will loop or require retriggering.
2. TRIGGER - button and jack trigger the sequence to restart at the beginning.

TUNE

* While adjusting tunable parameters, the light bar will reflect the current selection. For continuous parameters the light bar shows amount from 0-100%, for quantized parameters the light bar shows steps.
1. SKIP (continuous) - sets the probability that a note will be skipped in a sequence.
2. PLUCK (continuous) - sets the length of the gate, from short plucks to gliding between notes (portamento).
3. TIE (continuous)- sets the probability that a note gets tied to the next (effectively making the note last two clock cycles).
4. TREND (continuous) - sets whether the sequence trends upwards or downwards in pitch.
5. SCALE (quantized) - select the quantization of the notes used in the sequence. Choose from perfect notes, pentatonic scale, diatonic scale, chromatic scale and completely unquantized.
6. RANGE (continuous) - sets the range of notes from 1 to 4 octaves (unquantized)
7. LENGTH (quantized) - select the number of notes to play in a sequence (from 1-16, or infinitely generating at the max position).
8. SPEED (continuous) - sets the tempo of the internal clock, between 20 and 2000 BPM.

OUT
1. GATE - outputs the gate of the notes in the sequence.
2. PITCH - outputs the pitch (in V/OCT) of the sequence.

CLOCK

1. SELECT - Melodi will generate internal clock signal if select switch is up, and will use external clock signal when down
2. IN - connect external clock signal
3. OUT - output clock signal

Technical specs:

- Module Size: 3U X 8HP X 25 Mm Deep.
- Current Draw: 85mA @ 12V, 10mA @ -12V.

What's in the box:

- Ready to use Assembled Module
- Mounting Screws
- Power Cable
- User Manual

Notes: Terci Ruina combines three classic distortions in 4 hp. Distortions are reinterpreted in classic NE style and routed through each other for complete sonic annihilation of any sound. Patch in and out anywhere in the signal chain to pick the best sound for your purpose (because modular). Looking for a pretty distortion? This is probably not your module. Unapologetically gross and dirty.

Notes: Nive Grad is a level shifter designed for simplicity. Two Eurorack signals can be attenuated down to pedal and line levels, and two external line or pedal signals can be amplified up to Eurorack level. Integrating a drum machine, external synth, effects processor, or guitar with your Eurorack system has never been easier!

Nive Grad uses 1/8" jacks to save HP. If you want to use 1/4" gear with your system, ask your modular supplier about mono/TS 1/8" to 1/4" adapters or adapter cables.

Nive Grad pairs well with Noise Engineering's Xer Mixa system mixer, but can be used in any Eurorack system.

Type: Universal drum synthesizer
Size: Level Shifter
Depth: .9 inches
Power: 2x5 Eurorack
+12 V: 25 mA
-12 V: 25 mA
5 V: 0mA
Nive - level - from Latin niveum

Grad - step or degree- from Latin Gradus

Notes: 8-input CV expander for Xer Mixa

Expando Expandi adds 8 freely assignable CV inputs to the Xer Mixa in just 4 HP. Connect up to two Expando Expandi to Xer Mixa for easy CV control over channel levels, pan, aux sends, and more.

Expando Expandi is not for use on its own and is currently compatible only with Xer Mixa.

Notes: 8-input CV expander for Xer Mixa

Expando Expandi adds 8 freely assignable CV inputs to the Xer Mixa in just 4 HP. Connect up to two Expando Expandi to Xer Mixa for easy CV control over channel levels, pan, aux sends, and more.

Expando Expandi is not for use on its own and is currently compatible only with Xer Mixa.

Notes: CV Random is a random CV generator with 4 types of randomness and a triggerable sample-and-hold function.

Sliders allow you to set the internal clock tempo (RATE), shape the probability of triggering (PROB), blend old with new values (RND) and set the shape of all four random outputs (SHAPE).

4 different sliders

RATE

Sets the tempo of the internal clock. The CV input below the slider adjusts the clock rate, with 1V/oct calibration when the CV attenuverter is 100%. Upon each clock trigger, the RATE slider light blinks, and there is a chance for the internal random source to generate a new value.

PROB

This probability is set by the PROB slider, and if a new value was generated, the PROB slider light blinks and a pulse is emitted from the TRIG output.

RND

When the internal random source generates a new value, it mixes the previous value with a random value, with an amount specified by the RND slider.

SHAPE

The SHAPE slider sets the shape of all four random outputs. At its lowest position (0%), all outputs immediately jump to the new random value (the target value) when the clock is triggered.

At non-zero positions, the outputs interpolate between the previous and the target value, using a different behaviour for each output.

Internal random clock source

Whenever the clock activates, the RATE slider's light flashes. At the same time, there's a chance that the internal random source will create a new value, depending on the PROB slider's setting.

If it does create a new value, the PROB slider's light flashes too, and a pulse comes out of the TRIG output.

External IN & TRIG inputs

If the TRIG input is patched, the RATE slider is ignored, and the internal clock is only triggered when an external trigger is received. The PROB slider is used to filter this trigger by applying some probability.

Self-modulation

Thanks to a switch in the back of the module, you can normalize the LIN output to the 4 CV inputs and adjust the amount of modulation for each parameter with the attenuverters.

This adds another layer of randomness to your results, enabling more dynamic and unpredictable outcomes.

SHAPE Outputs

The STEP output jumps to the new value in one step at 0% SHAPE, and divides the transition into 16 steps at 100% SHAPE.

The LIN output immediately reaches the new value at 0% SHAPE, and takes the whole clock cycle to do so at 100% SHAPE, staying constant in between.

The EXP output shifts exponentially, becoming linear at 100% SHAPE, with its pace adjusted by the SHAPE slider.

The SMTH output transitions smoothly, with the speed controlled by the SHAPE setting, holding at the target until the cycle ends.

Specifications

Dimensions 10HP - 50×128,5mm
Current 63 mA +12V / 11 mA -12V / 0 mA +5V
Input & Output Signals +/-10V
Impedance Input 10k - Output 10k
Materials PCB and Panel - FR4 1,6mm
Depth 40mm including connectors (Skiff friendly)

Notes: ST.FONT is a stereo liquid filter that takes the beloved core of our FONT module and expands it into a powerful stereo filtering tool.

With a dual filter core (one for each channel), it offers a massive liquid sound with smooth resonance, adding warmth and depth to any audio signal.

Independent filter cores for left and right channels with Low Pass, Band Pass, and High Pass modes, plus seamless crossfading between filter outputs.

Built-in VCA with soft clipping for rich sound shaping, plus CV control.

Switch between Mild for traditional resonance or Wild for extreme distortion and aggressive filtering.

Dedicated FREQ Span, RES Span, and MODE Span knobs allow you to create a wide, immersive stereo field by adjusting the spread of parameters across both channels.

Notes: A warm and deep sound source you can rely on

A flexible and warm Analog Multifunction Oscillator, rich in harmonics. Excellent for performance use!

ONA can work as an Audio Oscillator or as a Low Frequency Modulator and it provides control over all its parameters, making it a versatile, deep and easy-to-use oscillator.

Thanks to its triangle-core oscillator and wave-shapers you can choose between a big palette of output waveforms to give shape to your ideas.

Classic Waveforms. Sine, Triangle, Saw and Square.

2 Complex Waveforms with Pulse Width Modulation.

2 Sub-Waveforms to add some bass sounds easily.

Blend them to give unlimited depth to your sound!

Notes: ***B-STOCK: Slight surface marks ***


Designed to be a highly customizable connection matrix, 3DVCA packs a boat load of utility into a small 6HP package. Four VCAs share the three macro controls: X, Y, and Z. As a group, they shape incoming and outgoing signals and emulate the coordinates of a point in 3 dimensional space. This allow the VCAs to work together in a mono, stereo, or quad configuration and accomplish a variety of mixing, crossfading, and panning functions.

3DVCA is designed to be used in the following functions:

Quad monophonic crossfader
Dual stereo crossfader
Stereo balancer
Stereo VCA
Mono to stereo panner
Unity mixer with up to eight inputs
Quadraphonic panner

Each output has a dedicated SUM input which allows an external signal to be automatically mixed into the output signal. This allows 3DVCA to daisy chain both with other mixers and other 3DVCAs. For example, you can create a full mono, stereo, or quadraphonic mix by plugging the output of each 3DVCA into the sum inputs of the next 3DVCA in the chain. Using this method, a set of 3DVCAs can create a fully voltage controlled and decentralized mixer which ties together anything from a small skiff to a monster synth.

When 3DVCA works as a crossfader or panner, the X and Y parameters follow an equal-power curve that keep output signals at the same volume no matter how many inputs are mixed together. This is in contrast to the Z parameter which follows a linear curve to always behave predictably with external modulation sources. All inputs are fully DC coupled in order to work with modulation speed signals as well as static DC voltage sequences; this means that 3DVCA can handle any sort of signal that you throw at it. All op amps in the device employ rail-to-rail inputs and outputs to enable the largest headroom when mixing many different signals together.

Whether you need to maximize your mixing functionality in the smallest possible footprint or have the most control over every aspect of your system, 3DVCA provides a ton of functionality in any system. Enter a higher dimension of sound with the Mystic Circuits 3DVCA.

Dimensions
6 HP
30 mm deep

Current Draw
45 mA +12V
45 mA -12V

Notes: The Morphor VCF Multimode is an intuitive, no nonsense 8HP fully analogue filter module. Featuring a dedicated lowpass and highpass filter core.

To shape the sound exactly the way you want, both filter sections have a cutoff frequency control over the whole audible frequency range through a knob and bipolar CV jack. Additionally, resonance control and a switchable pole selection are available.

The second output acts as both a bandpass and highpass output, depending on the position of the BP/HP mixing knob. Combining all these features results in an easy-to-use but flexible module to perform your unique filter needs.

Weight: 110 g
Dimensions: 128.5 × 40.6 × 40 mm
Width: 8 HP

Notes: The Morphor Plectrum - Analogue BBD Pluck is the successor of Morphor's successful module. Now only 8 HP instead of 10 HP with additional CV-able feedback!

Plectrum is a high quality, fully analogue Eurorack module that can produce plucked string-like sounds. It is a compact all-in-one solution for generating amazing bass, acoustic guitar, percussion and other amazing sounds.

The module is based on the Karplus-Strong principle with a true analog audio path built with an authentic bucket brigade delay (BBD) circuit which is recognizable by its specific timbre. By using carefully chosen high quality components, this module has a rich, warm analogue sound.

Now being only 8 HP in width, you won't need a lot of space to get going and start creating some incredible sounds. If you're looking to fully sculpt the string-like sound, you can extend the internal Karplus-Strong loop by breaking out the signal and adding external modules like filters and/or FX modules to it.

Features

100% analogue
Karplus-Strong principle
Built with classic BBD chip
Break-out BBD loop
Internal/external loop switch
Trigger input
1V/oct input
Tune knob
Pitch modulation CV input
Feedback CV input
Colour CV input (i.e. internal loop LPF cut-off frequency)
Mono output

Specifications

Panel width: 8 HP
Panel height: 3 U
Module depth: 40 mm
Current draw: 12V : 40 mA | -12V : 40 mA | +5V : 0 mA
Dimensions: 128.5 x 40.3 x 40 mm
Weight: 259 g
Frequency Range: sub-audio range to roughly 800 Hz
Power Socket: 16-pin

Notes: The Morphor Mixer - 5 Channel Amplifier is a flexible analogue mixer module that can find a home in every type of Eurorack setup.

Each of the five channels feature an attenuator knob and mute switch to allow for instant playability, for example in live settings.

Input signals can be AC or DC-coupled depending on your preferred setting.

The output stage also features an extra attenuation/gain stage that allows you to double the mixed signal. An additional master mute switch, clipping LED are nice-to-haves that complete this intuitive mixer module.

Weight: 102 g
Dimensions: 128.5 × 40.3 × 30 mm
Width: 8 HP

Notes: 8HP Tides version 2

Fully calibrated.

Notes: Lush analogue EQ switchable between tilt and Baxandall high-shelf configurations.

Perform a variety of mixing and sound design duties ranging from subtle brightness and clarity adjustments to low-end rumble removal, boosted low-pass filtering and sweep EQ.

In the default tilt mode, turning the control knob clockwise simultaneously boosts treble and cuts bass. Turning anti-clockwise boosts bass and cuts treble. These boosts and cuts are pivoted around the mid-range. With the control knob at 12 o'clock the frequency response is neutral.

With Baxandall high-shelf mode enabled, turning the control knob clockwise past 12 o'clock introduces and gentle high-shelf EQ weighted around the upper mid-range. Turning the control knob anti-clockwise results in a wide high-shelf cut with subtle bass and mid-range adjustments.

Patching the channels in series allows for radical sound shaping and band-pass responses. Each channel provides up to +/- 8db of low and high-frequency gain control, summing into a low noise output stage. Hot input signals over 15vpp are saturated by active Zener diode clipping.

Features

Precise voltage control of EQ tilt and shelf
Seamless switching between EQ modes
High-quality components used throughout

Specifications

Intellijel 1U format
Width 18HP
Depth 32mm
Power requirements ~60mA +12V/~58mA -12V
Control voltage range 0-8V
Impedance Input 100K / Output 1K

Notes: Catena is a control voltage powerhouse, packing in four channels of attenuation and offsets, two VC slew engines, half and full wave rectification, input voltage doubling and switchable voltage reference sources with an external offset input. As well as the standard cascading offset and polarisation utilities, the module can act as a percussive envelope generator or sidechain ducker, slow lag or glide control, waveshaper and mixer. Four channels of attenuators or attenuvertors are chained together, running from left to right, with an additional alternative mode per channel. The channel functions are chosen using a three-way slide switch above each control pot. Alternative modes use attenuvertion at the preamp stage allowing the modified signal to be polarised.

Alternative Modes

CH 1: Percussive Slew

CH2: Lazy Slew

CH 3: Half Wave Rectification (with gain boost)

CH 4: Full Wave Rectification

VREF Control

With no CV input patched, each channel generates +-5V or +-10V depending on the attenuvertor and VREF Switch position. The switch toggles between +5V and +10V precision voltage references. All Inputs and outputs soft clip at +-10V.

Slew Controls

CH 1 & 2 in the alt (slew) modes can have the slew response switched between tight and loose. There is further CV control via the CV input jack.

Offset Control

The pot controls the additional VREF amount added to CH 2, 3 & 4. With a CV input patched the pot controls an external signal input amount.CH 1 can also be offset by shifting a jumper on the rear panel.

Signal Doubler

Instead of unity gain as per the other channels, CH 4 doubles the input gain of a patched signal, but keeps any chained or offset signals at unity gain.

Mixer

High quality OPA op amps are used throughout, and Catena will happily serve as a mixer for 1-4 channels of audio. A five channel mixer is also possible by adding an audio signal to the offset jack.

Specifications

Intellijel 1U format
Width 28HP
Depth 34mm
Power requirements ~80mA +12V/~80mA -12V
Control voltage range +-10V
Impedance Input 100K / Output 1K

Notes: Catena is a control voltage powerhouse, packing in four channels of attenuation and offsets, two VC slew engines, half and full wave rectification, input voltage doubling and switchable voltage reference sources with an external offset input. As well as the standard cascading offset and polarisation utilities, the module can act as a percussive envelope generator or sidechain ducker, slow lag or glide control, waveshaper and mixer. Four channels of attenuators or attenuvertors are chained together, running from left to right, with an additional alternative mode per channel. The channel functions are chosen using a three-way slide switch above each control pot. Alternative modes use attenuvertion at the preamp stage allowing the modified signal to be polarised.

Alternative Modes

CH 1: Percussive Slew

CH2: Lazy Slew

CH 3: Half Wave Rectification (with gain boost)

CH 4: Full Wave Rectification

VREF Control

With no CV input patched, each channel generates +-5V or +-10V depending on the attenuvertor and VREF Switch position. The switch toggles between +5V and +10V precision voltage references. All Inputs and outputs soft clip at +-10V.

Slew Controls

CH 1 & 2 in the alt (slew) modes can have the slew response switched between tight and loose. There is further CV control via the CV input jack.

Offset Control
The pot controls the additional VREF amount added to CH 2, 3 & 4. With a CV input patched the pot controls an external signal input amount.CH 1 can also be offset by shifting a jumper on the rear panel.

Signal Doubler

Instead of unity gain as per the other channels, CH 4 doubles the input gain of a patched signal, but keeps any chained or offset signals at unity gain.

Mixer

High quality OPA op amps are used throughout, and Catena will happily serve as a mixer for 1-4 channels of audio. A five channel mixer is also possible by adding an audio signal to the offset jack.

Specifications

Intellijel 1U format
Width 28HP
Depth 34mm
Power requirements ~80mA +12V/~80mA -12V
Control voltage range +-10V
Impedance Input 100K / Output 1K

Notes: Mixer & CV/clock-controlled Switcher

Focused versatility seems an oxymoron when describing the features that led to the design of the Mixwitch.

With only a pinch of mixing, inverting and controlled switching, Klavis Electronics brew up a plethora of combinations and uses.

This is voltage processing magic!

The Mixwitch design comes from a frustration with attenuvertors (bipolar attenuators-inverters) whose off (neutral) position is difficult to retrieve, especially in live situations.

Klavis went for a digitally-controlled analogue path where polarity inversion would be at the touch of a button. So, the usefulness of attenuating/inverting can be realized by turning the pot down, swiftly pressing the inversion button and reopening the level. The zero level is where you expect it, with the pot full down.

Once a clean polarity control was established, a mute function was added, offering the benefit of pre-adjusted pot settings ready to be activated at will.

The next step was to bring something extra, useful and creative. There are plenty of analogue switches controlled by a clock; but arbitrarily selecting an input with a voltage is less known. Having both control capabilities combined with Klavis' specific mixer features creates a unique fusion: welcome to the Mixwitch!

Dimensions
8 HP
25 mm deep

Current Draw
39 mA +12V
24 mA -12V
0 mA 5V

Notes: The Flexshaper is a highly versatile module when it comes to modify evolving voltages in other directions and levels.

Five settings allow you to fold/expand/clip/compress/invert partially or completely any CV or audio signal.

The module can act as an envelope-shaping tool, frequency multiplier, waveshaper, clipper, distortion, limiter, curve changer, and more.

Five CV inputs offer limitless control over the placement of the voltage points for dynamic signal sculpting.

Birth of the product

The idea of the Flexshaper comes from a feature in the Oberheimr Matrix synthesizers called Tracking Generator.

This signal processor was part of the modulation matrix and meant to be virtually inserted between modulation sources and destinations in order to change the shape of the controlling signal.

The Flexshaper applies the same concept using the same 5 shaping points. However, it goes beyond Oberheim's implementation on two main aspects:

It goes fast enough to process signals at full audio rate
The 5 points are dynamically adjustable (CV) in real-time
Besides, the Flexshaper can process adequately bipolar and unipolar Eurorack signals, even changing them one another.

Dimensions
6 HP
21 mm deep

Current Draw
6 mA +12V
7 mA -12V
32 mA 5V

Notes: Programmable Volt/Octave CV calibrator and transposer

Clever four-channel utility module designed to make it easier to achieve perfect oscillator tracking and transpose CV signals. Also includes some neat quantising and portamento features.

The CalTrans solves issues encountered when playing tonal music with a modular system: tracking problems, curves unrelated to Volt per octave ratio, limited octave range, cumbersome transpose, ...

The CalTrans corrects and expands the range of troublesome VCOs and brings V/Oct tracking to anything that oscillates.

Besides calibration, the CalTrans offers live play features. Each channel can be quantized and any combination of them transposed jointly.

A pair of rotary encoders with detent allow an precise selection of octaves and semitones.

VCOs whose tracking doesn't go high enough to follow the leader will see their pitch repositioned in their highest possible octave so that the global harmony is unaffected.

You can add a pinch of portamento and glissando to each channel and save the whole in user presets.

Firmware 1.17 offers:
* User editable input scaling to match sources that don't generate perfect 1V per octave signals.
* Complete rewrite of the main processing with higher precision.
* ... and the unavoidable fixes and tweaks ;-)

The updated user manual 1.4 is much expanded with operations described in exquisite details :-)
.. and a version 1.5 corrects a mistake in the input calibration description and eases the reading elsewhere.

Dimensions
6 HP
36 mm deep

Current Draw
44 mA +12V
8 mA -12V
0 mA 5V

Notes: Clever four-channel utility module designed to make it easier to achieve perfect oscillator tracking and transpose CV signals. Also includes some neat quantising and portamento features.

Supplier notes:
The CalTrans solves issues encountered when playing tonal music with a modular system: tracking problems, curves unrelated to Volt per octave ratio, limited octave range, cumbersome transpose, ...

The CalTrans corrects and expands the range of troublesome VCOs and brings V/Oct tracking to anything that oscillates.

Besides calibration, the CalTrans offers live play features. Each channel can be quantized and any combination of them transposed jointly.

A pair of rotary encoders with detent allow an precise selection of octaves and semitones.

VCOs whose tracking doesn't go high enough to follow the leader will see their pitch repositioned in their highest possible octave so that the global harmony is unaffected.

You can add a pinch of portamento and glissando to each channel and save the whole in user presets.

Notes: You must absolutely own Skippy to use this module; it cannot operate independently.

The firmware version 2.21 or higher must be installed on your Skippy.

Additional features:
1 CV gate or trig input for Reset
1 CV gate or trig input for Play/stop
1 Reset button
1 Play/stop button
1 Live mode on/off button
16 function potentiometers distributed over 4 rows: you can freely choose a function (BPM, STEP, BEGIN, END, GAUSS, GATE, PROBA, CHAOS, SWING, WAY) for each row.
1 row of 4 algorithm potentiometers: you can freely choose an algorithm (Euclid, Jazzy, PolyR, Tiles) for each potentiometer.
The Save function takes into account the settings used in Skippy Live.
The selected parameters for Skippy Live are automatically saved.

Technical specifications:
10 HP
Depth: 25 mm
Power consumption:
+12 V 0 mA
-12 V 0 mA
+5 V 15 mA
Comes with a connector to Skippy and Knurlies.

Notes: Random rhythm generator

Joey is a Eurorack module that generates random gate sequences. It is the offspring of Skippy (Kaona's polyrhythmic sequencer), without simply copying it: it's a very straightforward module that provides unexpected yet controllable sequences.

It offers three main modes:

Random

For random triggers controlled by an internal speed or an external clock.

Fractal

A unique algorithm sprinkled with 5% chaos, creating evolving and surprising patterns.

Euclid

Generates four different Euclidean patterns for complex and evolving rhythms.

Each mode has three adjustable parameters set via a clickable encoder: speed, a mode-specific parameter (probability, fractal root, or Euclidean pattern), and gate length. An external gate input can take over to synchronize speed. A PLAY/STOP button instantly suspends or restarts the gates.

Specifications

Width: 6 HP

Power Consumption:
+12 V: 50 mA
-12 V: 0 mA
+5 V: 0 mA

Depth: 28 mm

Supplied with power cable and Knurlies

Notes: Simple but effective output module, converts stereo instrument-level signal to balanced XLR outs. Ideal for live use but just as good for avoiding unwanted hum in the studio.

Supplier's notes:
Whether it's in the studio or on a live stage, keeping audio interconnections free from unwanted hum and interference can be a challenge. Balanced lines are the proven solution to this problem.

Conventional balanced output solutions often rely on transformers providing galvanic isolation to mitigate the effects of ground loops. Unfortunately, these components are bulky, expensive and colour the sound (often unfavourably, especially in the low end).

Instead, Transmit 2 (or TX2 for short) takes a fully solid-state approach. Offering a stereo pair of XLR balanced outputs, it ensures that the sonic clarity of your carefully planned modular system is not lost in its interface to the outside world.

Engineered to provide massive headroom while retaining extremely low noise and distortion, Transmit 2's circuitry incorporates low-impedance design practices, radio-frequency (RF) filtering and premium balanced drivers to provide transformer-like interconnect performance in a compact and affordable module. And thanks to the electrostatic (ESD) and phantom power discharge protection, it's rugged enough to survive the rigours of performing on the road.

Adjusting the main output level is a breeze thanks to the dual peak-responding LED meters. A high-end headphone amplifier is included as well, controlled by a separate level knob. It can deliver the voltage and current required to power practically any headphones, regardless of the impedance or driver technology. This 3.5 mm stereo socket can function as an auxiliary stereo line output or even drive small passive speakers, making Transmit 2 an all-round flexible answer to all your output needs.

Notes: While modular synthesisers are most often used as stand-alone instruments, they also present exciting opportunities for processing external signals. Anything from an electric guitar to an effects send on a studio mixing desk can benefit from the unique sonic capabilities of even a modest Eurorack system.

However, patching in an external source usually requires an adapter cable and plenty of clean gain to bring the signal to Eurorack level. If the signal source is balanced, a balanced input is required as well to provide the best possible interference rejection.

Receive 2 (or RX2 for short) provides a convenient all-in-one solution. It offers two universal external inputs, which accept both balanced or single-ended signals via XLR or 6.35 mm jack connectors.

The circuit incorporates low-impedance design practices, radio-frequency (RF) filtering and premium balanced receivers to provide transformer-like interconnect performance in a compact and affordable module. And thanks to the electrostatic discharge (ESD) protection, it’s rugged enough to survive the rigours of performing on the road.

The very clean integrated pre-amps feature variable gain, ranging from unity to +40 dB on each channel. As a result, Receive 2 can handle just about any signal source you may encounter, including electric instruments, piezoelectric pickups and many dynamic microphones.

Adjusting the gains is a breeze thanks to the dual peak-responding LED meters. A mix output is included as well, so external signals can be easily mixed directly in the module.

Notes: Make quick changes to signal routing manually or with CV control. Any audio or CV signal can be routed via two outputs in series, parallel or reverse series. Quick, clever and easy to use.

Supplier's Notes:
Signal flow is an essential concept in modular synthesis: the path taken by audio or control voltages (CVs) may be long or short, branching or linear, intuitive or highly complex.

While the patch programmability of a modular system is its greatest strength, it can also be a weakness: quick experimentation is often hampered by the need to repatch the synthesiser to change the signal flow.

Pivot 2 offers a unique solution: a compact, fully voltage controlled variable signal router. At the turn of a single knob, any signal can be routed through two external modules in series, parallel or reverse series, as well as any combination in between.

Experiment with patching wavefolders before, after or alongside filters, shuffle multiple delay lines, precisely dial in two-stage audio compression or easily control intricate feedback patches.

Looking beyond the basic signal routing application, Pivot 2 will also function as a complementary pair of counter-acting linear voltage controlled amplifiers (VCAs), a voltage controlled crossfader or a voltage controlled panner.

Analogue voltage controlled send/return router.
Seamless transitions from series, through parallel on to reverse series effect routing.
Also functions as a complementary VCA pair, voltage controlled crossfader or panner.
Impedance-compensated outputs with dual-colour LEDs.
Premium mounting hardware: black screws, black nylon washers and matching hex key.
High-quality components and assembly; designed and made in Belgium.

4 HP | +12: 60 mA, -12: 60 mA

Notes: Designed with versatility in mind, the Fold 6 is a six-stage wavefolder with simultaneous series and parallel outputs, dual signal inputs and voltage-controlled folding and overdrive shaping.

Supplier's Notes:
Often considered to be the opposite of filters within a modular system, wavefolders are designed to fold a signal over itself multiple times. This generates additional harmonics, resulting in rich timbres.

While there is a bewildering array of filter types within the synthesiser world, most wavefolders fall within only a few categories. Diode wavefolders in particular come in just two variants: series and parallel circuit topologies. Choosing a specific folder also means being limited to specific sounds and capabilities.

For the first time, Fold 6 puts forward a 6-stage hybrid series/parallel topology, yielding a greater sonic palette than ever in just 4 HP. Having both main (series) and alternate (parallel) outputs means a single module now gives access to just about all wavefolding tones imaginable.

To take things even further, an integrated symmetrical soft clipper limits the output signals to approximately 10 Vpp, keeping the amplitude within typical Eurorack levels and making it easier to create overdriven sounds at high fold ratios. This clipping stage can be driven continuously using the shape parameter, smoothly transforming the folded waveforms into pulse waves for even more harmonic content.

Two signal inputs are included, to mix audio signals or add in a DC voltage for asymmetric folding. The symmetry can also be manually controlled using the dedicated knob. Of course, both fold and shape parameters feature voltage control, to enable continuous timbral modulation.

Moving beyond simple signal processing, Fold 6 also lends itself perfectly for feedback patching, CV folding or frequency multiplication; its modest size belies the sonic capabilities within.
