Morphor

Notes: The Morphor Analogue Plectrum (AP-1) module is a fully analogue Eurorack module that can produce plucked string-like sounds. It is a compact all-in-one solution for generating amazing bass, acoustic guitar, percussion and other amazing sounds.

The module is based on the Karplus-Strong principle with a true analog audio path built with an authentic bucket brigade delay (BBD) circuit which is recognizable by its specific timbre. By using carefully chosen high quality components, this module has a rich, warm analogue sound.

Being only 10HP in width, you won't need a lot of space to get going and start creating some incredible sounds!

CONTROLS:

GATE: to pluck the string, simply insert a 5V pulse into the input. Short triggers work great but you can play around with longer pulses to get rougher sounds.
TUNE: change the frequency of the string with a 1V/oct input. Afterwards you can generate vibrato and other effects with a separate CV pitch input (in development).
COLOUR: you can alter the timbre of the string with this control, including a CV input. This way you can get very noisy or dampened sounds.
FILTER BYPASS: the colour parameter is shaped by an internal filter but can be bypassed if you like. Use your own external filter to generate unique sounds. A one pole low pass filter will give the best results but feel free to get creative with this feature. You can insert anything you like into the loop.
FEEDBACK: by adjusting the feedback amount it's possible to change the decay of the sound. Create short plucked sounds or long ringing strings. In some configurations, you might even get some nice oscillations.
OUTPUT: take the output to the rest of your modular system and start experimenting!

Weight: 251 g
Dimensions: 128.5 × 50.8 × 40 mm

Other information:

Frequency range: sub audio range to roughly 800 Hz
10HP width, 3U Eurorack standard
3.5mm patch cables for all jacks
16-pin power socket

Notes: The Morphor Distortion - LED Based module is a compact and characterful analogue clipping distortion module. Loosely based on the legendary MXR distortion circuit this module is perfect for adding some extra crunch to your patches.

With CV-controlled gain setting, three distortion modes and a dry/wet mixing control, this module gives you lots of options to spice up your sound without taking up too much space. Internally the clipping is performed by LEDs which are also shown in the front of the module, so you can see your sound getting destroyed with your own eyes.

Weight: 53 g
Dimensions: 128.5 × 20 × 40 mm
Width: 4 HP

Notes: The Morphor Ensemble is an 8-voice fully analogue chorus effect module. The module can truly upgrade any input audio into a sound with body. Transform your creations into warm and full sounds as if a whole orchestra is playing them.

Morphor Ensemble features extensive control over your effect with number of voices selection, CV-able spread, two full-featured LFOs and control over the amount of dry-add signal. This way it is possible to create a wide range of effects, from subtle broadening or humanisation of your sound up to pitch-bending craziness.

The module features a true analogue audio path based on eight BBD devices, known for their authentic and warm timbre. In summary, the Morphor Ensemble is a high-end, flexible chorus module for every analogue lover.

Weight: 167 g
Dimensions: 128.5 × 60.6 × 40 mm
Width: 12 HP

Notes: The Morphor Mixer - 5 Channel Amplifier is a flexible analogue mixer module that can find a home in every type of Eurorack setup.

Each of the five channels feature an attenuator knob and mute switch to allow for instant playability, for example in live settings.

Input signals can be AC or DC-coupled depending on your preferred setting.

The output stage also features an extra attenuation/gain stage that allows you to double the mixed signal. An additional master mute switch, clipping LED are nice-to-haves that complete this intuitive mixer module.

Weight: 102 g
Dimensions: 128.5 × 40.3 × 30 mm
Width: 8 HP

Notes: A (buffered) mult is an essential item in every rack. This buffered DC-coupled module will fulfill all your audio and CV multiplying needs.

With a little switch on the back the module can be configured in two different modes.
The 1-to-8 mode speaks for itself, offering eight identical copies of your input signal.

The double mode offers a 1-to-4 and 1-to-3 buffered multiple with the first input getting normalised to all output jacks if the second input stays unused.

Weight: 27 g
Dimensions: 128.5 × 9.8 × 30 mm
Width: 2 HP

Notes: The Morphor Plectrum - Analogue BBD Pluck is the successor of Morphor's successful module. Now only 8 HP instead of 10 HP with additional CV-able feedback!

Plectrum is a high quality, fully analogue Eurorack module that can produce plucked string-like sounds. It is a compact all-in-one solution for generating amazing bass, acoustic guitar, percussion and other amazing sounds.

The module is based on the Karplus-Strong principle with a true analog audio path built with an authentic bucket brigade delay (BBD) circuit which is recognizable by its specific timbre. By using carefully chosen high quality components, this module has a rich, warm analogue sound.

Now being only 8 HP in width, you won't need a lot of space to get going and start creating some incredible sounds. If you're looking to fully sculpt the string-like sound, you can extend the internal Karplus-Strong loop by breaking out the signal and adding external modules like filters and/or FX modules to it.

Features

100% analogue
Karplus-Strong principle
Built with classic BBD chip
Break-out BBD loop
Internal/external loop switch
Trigger input
1V/oct input
Tune knob
Pitch modulation CV input
Feedback CV input
Colour CV input (i.e. internal loop LPF cut-off frequency)
Mono output

Specifications

Panel width: 8 HP
Panel height: 3 U
Module depth: 40 mm
Current draw: 12V : 40 mA | -12V : 40 mA | +5V : 0 mA
Dimensions: 128.5 x 40.3 x 40 mm
Weight: 259 g
Frequency Range: sub-audio range to roughly 800 Hz
Power Socket: 16-pin

Notes: The Morphor VCA - Dual Lin/Exp is a compact and complete dual DC-coupled VCA module. This module will definitely come in handy as a general purpose VCA without taking up too much space.

The two separate VCA sections each feature extensive gain control (main knob + attenuated CV jack), an indicator LED and a switch to select Linear or Exponential control. This way, the module can be used both for audio and CV processing. Without a cable plugged in, the first output gets normalled to the second, resulting in a 2-channel mixer output.

Weight: 88 g
Dimensions: 128.5 × 40.6 × 30.5 mm
Width: 6 HP

Notes: The Morphor VCF Multimode is an intuitive, no nonsense 8HP fully analogue filter module. Featuring a dedicated lowpass and highpass filter core.

To shape the sound exactly the way you want, both filter sections have a cutoff frequency control over the whole audible frequency range through a knob and bipolar CV jack. Additionally, resonance control and a switchable pole selection are available.

The second output acts as both a bandpass and highpass output, depending on the position of the BP/HP mixing knob. Combining all these features results in an easy-to-use but flexible module to perform your unique filter needs.

Weight: 110 g
Dimensions: 128.5 × 40.6 × 40 mm
Width: 8 HP
