Tags: Analogue synthesisers

Notes: Mono Lancet '15 might be small-sized device, despite it is a bona fide analogue synthesizer.

Two oscillators and a noise generator are the foundation for its sound. Together with the musical lowpass filter and VCA it's capable of producing warm and precious sounds full of character.

Beside its audio qualities Mono Lancet '15 has a dead simple and intuitive user interface. Each parameter has its own control. We are absolutely convinced that you will quickly learn how to realize your sounds with Mono Lancet '15 without thinking about what you do.

Expandable with Modular Dock:
Mono Lancet '15's functionality can even be enhanced using the optional Modular Dock eurorack module. It offers various in- and out-connections to the individual sections of the synthesizer. With just a few additional modules you can multiply the strong sound base of Mono Lancet '15.

Mono Lancet '15 is manufactured in our Elektroakustischen Manufaktur in historical Vogtland. For us it is not only a piece of high-quality analogue technology but rather a musical instrument, handmade with love and passion.

Ships with UK 3-pin power supply.

For audio demos, please visit - http://www.vermona.com/en/products/synthesizer/product/mono-lancet-15/

Notes: Vintage FM synthesis meets analogue character in the TWISTfm. Eight-voice polyphonic sound engine with superb versatility thanks to 15 filter modes including Heat saturation and adjustable resonance.

Supplier's Notes:
Unleash the full potential of FM synthesis with TWISTfm, a cutting-edge polyphonic synthesiser that blends vintage FM synthesis with advanced analogue filtering and modern control. Designed to offer a rich, dynamic sound palette, TWISTfm is the perfect tool for musicians and sound designers looking to push the boundaries of sonic creativity.

At the core of TWISTfm are two legendary Yamaha OPL-3 YMF262 FM chips paired with dual YAC512 stereo DACs, providing 8 discrete voices. Each voice is equipped with its own analog multimode filter for an unparalleled range of sound design possibilities.

With HEAT and Dual Resonance Modes: Featuring 8 individual analogue filters, inspired by the iconic designs of Mutable Instruments, TWISTfm gives you precise control over sound shaping with 15 filter modes, including low-pass, high-pass, band-pass, phaser, notch, and more. The HEAT parameter adds anything from warm, subtle saturation to harsh analog distortion, allowing you to push the filters to their limit. Additionally, you can switch between two resonance flavors-LIQUID, for smooth and subtle resonance, and MS20, for more aggressive, cutting tones. With digital control over resonance and cutoff, the filters offer flexible modulation and the ability to store settings with presets.

TWISTfm's MPE mode fully supports three dimensions of control-pitch (X), timbre (Y via CC74), and pressure (Z)-offering precise per-note modulation for unparalleled expressiveness and depth in your sound.

Whether you're composing in the studio or performing live, TWISTfm's robust feature set and intuitive design make it a powerful addition to any setup. Its combination of vintage FM tones and modern control capabilities offers a unique, versatile sound engine capable of producing everything from smooth ambient pads to aggressive basses and leads.

Notes: Brilliantly unusual synth based on eight analogue tone generators, functioning more like an electric organ or FM synth than a conventional subtractive architecture. Unique sound.

Supplier notes:
Welcome to the world of sound of LYRA-8, the unique organismic analogue synthesizer designed by Vlad Kreimer. "Organismic" means that LYRA uses some principles that lie in the base of living organisms. The way how LYRA's modules interacting between each other and the behaviour of the instrument resembles a live conversation.

LYRA-8 is based on eight generators, which will be referred to as voices. Their design is not like a traditional subtractive synthesis VCO. Instead of having a linear or logarithmic dependency on control voltage, they resemble the tone generators in old electric organs. Hence the use of the term "voices" instead of VCOs. Lyra uses non-linearity a lot, and the voices are constructed in such a way that allows for non-linearity to express itself.

The voices are divided into four pairs (12, 34, 56, 78). All the pairs are divided in two groups, with two pairs in each (1234, 5678), creating tree-like structure.

The voices can function either in an electric organ mode or in an FM synthesis mode with each of the voices and its envelope acting as a separate FM operator. The voice's impact on FM synthesis will decrease along with the decay of its envelope.

LYRA-8 also has the next blocks:

The HYPER LFO is a complex low-frequency generator, whose waveform is synthesized from two simple LFOs by summation or multiplication of their frequencies. It also has a sync mode. The LFO can modulate the selected pairs of voices and the MOD DELAY.

The MOD DELAY consists of two lines of delay with cross-feedback and a special architecture that enables resonance between the two lines. Each line's delay time can be individually modulated from various sources, including external ones. The delay has a unique possibility of self-modulation where the output signal modulates the delay sample rate, creating cool effects.

The DISTORTION is last in the chain, after the delay. It enables the delay to also influence the distortion.

For all its experimental character, LYRA is a professional instrument. Its output dynamics and frequency response are balanced and ready for a live performance or studio recording without any additional processing.

Specifications:

Max output voltage: 2 v 0-to-peak
Output connector: mono 6.3 mm TS or TRS (balanced) jack
Output resistance: 100 Ohm
EXT IN: 1 v 0-to-peak
EXT IN connector: 6.3 mm TS jack
HOLD GATE: full HOLD volume +5 V
HOLD GATE connector: 6.3 mm TS jack
CV DELAY : unipolar, range of 0 to +5 volt
CV DELAY connector: 6.3 mm TS jack
CV VOICES: unipolar, range of 0 to +5 volt
CV VOICES connector: 6.3 mm TS jack
Power supply: stabilised, +12 V, 0.2 A, centre positive
Power Consumption: 2 watt
Dimensions: 266 x 266 x 62 mm
Weight (without power supply and packaging): 2.5 kg

Notes: Welcome to the world of sound of LYRA-8, the unique organismic analogue synthesiser designed by Vlad Kreimer. "Organismic" means that LYRA uses some principles that lie in the base of living organisms. The way how LYRA's modules interacting between each other and the behaviour of the instrument resembles a live conversation.

LYRA-8 is based on eight generators, which will be referred to as voices. Their design is not like a traditional subtractive synthesis VCO. Instead of having a linear or logarithmic dependency on control voltage, they resemble the tone generators in old electric organs. Hence the use of the term "voices" instead of "VCOs". Lyra uses non-linearity a lot, and the voices are constructed in such a way that allows for non-linearity to express itself.

The voices are divided into four pairs (12, 34, 56, 78). All the pairs are divided in two groups, with two pairs in each (1234, 5678), creating tree-like structure.

The voices can function either in an electric organ mode or in an FM synthesis mode with each of the voices and its envelope acting as a separate FM operator. The voice's impact on FM synthesis will decrease along with the decay of its envelope.

LYRA-8 also has the next blocks:

The HYPER LFO is a complex low-frequency generator, whose waveform is synthesized from two simple LFOs by summation or multiplication of their frequencies. It also has a sync mode. The LFO can modulate the selected pairs of voices and the MOD DELAY.

The MOD DELAY consists of two lines of delay with cross-feedback and a special architecture that enables resonance between the two lines. Each line's delay time can be individually modulated from various sources, including external ones. The delay has a unique possibility of self-modulation where the output signal modulates the delay sample rate, creating cool effects.

The DISTORTION is last in the chain, after the delay. It enables the delay to also influence the distortion.

For all its experimental character, LYRA is a professional instrument. Its output dynamics and frequency response are balanced and ready for a live performance or studio recording without any additional processing.

Notes: Pink version of Soma's excellent Lyra-8. Brilliantly unusual synth based on eight analogue tone generators, functioning more like an electric organ or FM synth than a conventional subtractive architecture. Unique sound.

Supplier's Notes:
Welcome to the world of sound of LYRA-8, the unique organismic analogue synthesiser designed by Vlad Kreimer. "Organismic" means that LYRA uses some principles that lie in the base of living organisms. The way how LYRA's modules interacting between each other and the behaviour of the instrument resembles a live conversation.

LYRA-8 is based on eight generators, which will be referred to as voices. Their design is not like a traditional subtractive synthesis VCO. Instead of having a linear or logarithmic dependency on control voltage, they resemble the tone generators in old electric organs. Hence the use of the term "voices" instead of "VCOs". Lyra uses non-linearity a lot, and the voices are constructed in such a way that allows for non-linearity to express itself.

The voices are divided into four pairs (12, 34, 56, 78). All the pairs are divided in two groups, with two pairs in each (1234, 5678), creating tree-like structure.

The voices can function either in an electric organ mode or in an FM synthesis mode with each of the voices and its envelope acting as a separate FM operator. The voice's impact on FM synthesis will decrease along with the decay of its envelope.

LYRA-8 also has the next blocks:

The HYPER LFO is a complex low-frequency generator, whose waveform is synthesized from two simple LFOs by summation or multiplication of their frequencies. It also has a sync mode. The LFO can modulate the selected pairs of voices and the MOD DELAY.

The MOD DELAY consists of two lines of delay with cross-feedback and a special architecture that enables resonance between the two lines. Each line's delay time can be individually modulated from various sources, including external ones. The delay has a unique possibility of self-modulation where the output signal modulates the delay sample rate, creating cool effects.

The DISTORTION is last in the chain, after the delay. It enables the delay to also influence the distortion.

For all its experimental character, LYRA is a professional instrument. Its output dynamics and frequency response are balanced and ready for a live performance or studio recording without any additional processing.

Notes: Welcome to the world of sound of LYRA-8, the unique organismic analogue synthesiser designed by Vlad Kreimer. "Organismic" means that LYRA uses some principles that lie in the base of living organisms. The way how LYRA's modules interacting between each other and the behaviour of the instrument resembles a live conversation.

LYRA-8 is based on eight generators, which will be referred to as voices. Their design is not like a traditional subtractive synthesis VCO. Instead of having a linear or logarithmic dependency on control voltage, they resemble the tone generators in old electric organs. Hence the use of the term "voices" instead of "VCOs". Lyra uses non-linearity a lot, and the voices are constructed in such a way that allows for non-linearity to express itself.

The voices are divided into four pairs (12, 34, 56, 78). All the pairs are divided in two groups, with two pairs in each (1234, 5678), creating tree-like structure.

The voices can function either in an electric organ mode or in an FM synthesis mode with each of the voices and its envelope acting as a separate FM operator. The voice's impact on FM synthesis will decrease along with the decay of its envelope.

LYRA-8 also has the next blocks:

The HYPER LFO is a complex low-frequency generator, whose waveform is synthesized from two simple LFOs by summation or multiplication of their frequencies. It also has a sync mode. The LFO can modulate the selected pairs of voices and the MOD DELAY.

The MOD DELAY consists of two lines of delay with cross-feedback and a special architecture that enables resonance between the two lines. Each line's delay time can be individually modulated from various sources, including external ones. The delay has a unique possibility of self-modulation where the output signal modulates the delay sample rate, creating cool effects.

The DISTORTION is last in the chain, after the delay. It enables the delay to also influence the distortion.

For all its experimental character, LYRA is a professional instrument. Its output dynamics and frequency response are balanced and ready for a live performance or studio recording without any additional processing.

Specifications:

Max output voltage: 2 v 0-to-peak
Output connector: mono 6.3 mm TS or TRS (balanced) jack
Output resistance: 100 Ohm
EXT IN: 1 v 0-to-peak
EXT IN connector: 6.3 mm TS jack
HOLD GATE: full HOLD volume +5 V
HOLD GATE connector: 6.3 mm TS jack
CV DELAY : unipolar, range of 0 to +5 volt
CV DELAY connector: 6.3 mm TS jack
CV VOICES: unipolar, range of 0 to +5 volt
CV VOICES connector: 6.3 mm TS jack
Power supply: stabilised, +12 V, 0.2 A, centre positive
Power Consumption: 2 watt
Dimensions: 266 x 266 x 62 mm
Weight (without power supply and packaging): 2.5 kg

Notes: Welcome to the world of sound of LYRA-8, the unique organismic analogue synthesizer designed by Vlad Kreimer. "Organismic" means that LYRA uses some principles that lie in the base of living organisms. The way how LYRA's modules interacting between each other and the behaviour of the instrument resembles a live conversation.

LYRA-8 is based on eight generators, which will be referred to as voices. Their design is not like a traditional subtractive synthesis VCO. Instead of having a linear or logarithmic dependency on control voltage, they resemble the tone generators in old electric organs. Hence the use of the term "voices" instead of "VCOs". Lyra uses non-linearity a lot, and the voices are constructed in such a way that allows for non-linearity to express itself.

The voices are divided into four pairs (12, 34, 56, 78). All the pairs are divided in two groups, with two pairs in each (1234, 5678), creating tree-like structure.

The voices can function either in an electric organ mode or in an FM synthesis mode with each of the voices and its envelope acting as a separate FM operator. The voice's impact on FM synthesis will decrease along with the decay of its envelope.

LYRA-8 also has the next blocks:

The HYPER LFO is a complex low-frequency generator, whose waveform is synthesized from two simple LFOs by summation or multiplication of their frequencies. It also has a sync mode. The LFO can modulate the selected pairs of voices and the MOD DELAY.

The MOD DELAY consists of two lines of delay with cross-feedback and a special architecture that enables resonance between the two lines. Each line's delay time can be individually modulated from various sources, including external ones. The delay has a unique possibility of self-modulation where the output signal modulates the delay sample rate, creating cool effects.

The DISTORTION is last in the chain, after the delay. It enables the delay to also influence the distortion.

For all its experimental character, LYRA is a professional instrument. Its output dynamics and frequency response are balanced and ready for a live performance or studio recording without any additional processing.

Notes: Brilliantly unusual synth based on eight analogue tone generators, functioning more like an electric organ or FM synth than a conventional subtractive architecture. Unique sound.

Supplier notes:
Welcome to the world of sound of LYRA-8, the unique organismic analogue synthesizer designed by Vlad Kreimer. "Organismic" means that LYRA uses some principles that lie in the base of living organisms. The way how LYRA's modules interacting between each other and the behaviour of the instrument resembles a live conversation.

LYRA-8 is based on eight generators, which will be referred to as voices. Their design is not like a traditional subtractive synthesis VCO. Instead of having a linear or logarithmic dependency on control voltage, they resemble the tone generators in old electric organs. Hence the use of the term "voices" instead of VCOs. Lyra uses non-linearity a lot, and the voices are constructed in such a way that allows for non-linearity to express itself.

The voices are divided into four pairs (12, 34, 56, 78). All the pairs are divided in two groups, with two pairs in each (1234, 5678), creating tree-like structure.

The voices can function either in an electric organ mode or in an FM synthesis mode with each of the voices and its envelope acting as a separate FM operator. The voice's impact on FM synthesis will decrease along with the decay of its envelope.

LYRA-8 also has the next blocks:

The HYPER LFO is a complex low-frequency generator, whose waveform is synthesized from two simple LFOs by summation or multiplication of their frequencies. It also has a sync mode. The LFO can modulate the selected pairs of voices and the MOD DELAY.

The MOD DELAY consists of two lines of delay with cross-feedback and a special architecture that enables resonance between the two lines. Each line's delay time can be individually modulated from various sources, including external ones. The delay has a unique possibility of self-modulation where the output signal modulates the delay sample rate, creating cool effects.

The DISTORTION is last in the chain, after the delay. It enables the delay to also influence the distortion.

For all its experimental character, LYRA is a professional instrument. Its output dynamics and frequency response are balanced and ready for a live performance or studio recording without any additional processing.

Notes: Derived from the excellent Lyra-8, the Lyra-4 features a similar 'organismic' approach to synthesis. Four-voice non-linear architecture offers unique tones in a compact, portable format.

Supplier's Notes:
Introducing the revived version of LYRA-4 organismic synthesiser, the younger sister of the famous LYRA-8. "Organismic" means that LYRA uses some principles that lie in the base of living organisms. The way how LYRA's modules interacting between each other and the behaviour of the instrument resembles a live conversation. It's smaller and weighs less but is equally rugged in design, and still packs a lot of punch. This makes it easy to fit in a backpack and perfect for taking the LYRA sound on the road. And playing two LYRA-4s can actually sound very different than just one LYRA-8.

LYRA-4 is based on four generators, which will be referred to as voices. Their design is not like a traditional subtractive synthesis VCO. Instead of having a linear or logarithmic dependency on control voltage, they resemble the tone generators in old electric organs. Hence the use of the term "voices" instead of "VCOs". Lyra uses non-linearity a lot, and the voices are constructed in such a way that allows for non-linearity to express itself.

The voices are divided into two pairs (12, 34), creating tree-like structure.

The voices can function either in an electric organ mode or in an FM synthesis mode with each of the voices and its envelope acting as a separate FM operator. The voice's impact on FM synthesis will decrease along with the decay of its envelope.

LYRA-4 also has the next blocks:

The HYPER LFO is a complex low-frequency generator, whose waveform is synthesized from two simple LFOs by summation or multiplication of their frequencies. It also has a sync mode. The LFO can modulate the selected pairs of voices and the MOD DELAY.

The MOD DELAY consists of delay with feedback. The delay has a unique possibility of self-modulation where the output signal modulates the delay sample rate, creating cool effects.

The DISTORTION is last in the chain, after the delay. It enables the delay to also influence the distortion.

For all its experimental character, LYRA is a professional instrument. Its output dynamics and frequency response are balanced and ready for a live performance or studio recording without any additional processing.

Specifications

Max output voltage: 2 v 0-to-peak
Output connector: mono 6.3 mm TS jack
Output resistance: 10 KOhm
CV DELAY: unipolar, range of 0 to +5 volt
CV DELAY: 6.3 mm TS jack
CV VOICES: unipolar, range of 0 to +5 volt
CV VOICES connector: 6.3 mm TS jack
Power supply stabilised, +12 V, 0.2 A, centre positive
Power Consumption: 1.2 watt
Headphones resistance: 6-64 Ohm
Power supply stabilised, +12 V, 0.2 A, centre positive
Dimensions: 241 x 203 x 62 mm
Weight (without power supply and packaging): 1.2 kg

What's included:

LYRA-4 - 1 pc
Power supply - 1 pc

Notes: Cracking value in this brutalist beauty manufactured by Bristol's Future Sound Systems. Interesting features like wave-shaping VCOs and Sallen-Key filter make it the ideal starting point for a bigger modular setup.

Supplier's Notes:
Malevolent has been designed by Paul Whittington in collaboration with Bristol based synth manufacturer Future Sound Systems who have provided the analogue circuitry, and Ben Supper who developed the control interface:

Paul has a had a long career in developing products for some of the biggest names in the industry and is now using his expertise to build instruments, bringing in talents from friends he's made during his tenure in development.

Future Sound Systems are a renowned Bristol based synthesizer manufacturer, who are responsible for some of most forward-thinking designs on the market, they specialize in modular and semi-modular synthesizers & their design prowess is very apparent in Malevolent.

Despite its diminutive size, Malevolent sounds big, aggressive and is capable of everything from soaring leads, huge bass sounds, percussive phrases, weird sound FX and more.

It's form factor, user interface and price point make it a great option for those taking their first step in the modular domain, but it's unique sound, extensive modulation capabilities and the options for integrating seamlessly with other synthesizers, makes it a great option for experienced user who's looking for something a little different.

Modular Pure Analogue Synthesiser

Pure Analogue signal path designed by Future Sound Systems
Pure VCOs

19 Outputs and 19 Inputs for 3.5mm mono jack cable patching
Normalised signal path for immediate sound Malevolence
Additional rear panel line out
Additional headphone out


2 Voltage Controlled Oscillators
Saw / Triangle / Pulse outputs plus Mix for each oscillator
1V/Oct pitch control input
Shape control / pulse width modulation input
2x Frequency Modulation inputs
Coarse / Fine tune control
Shape mod amount control
FM1 and 2 mod amount controls
Shape control
Selectable waveforms for the mix output
Individual osc level control


LFO (Low Frequency Oscillator)
Triangle / Square wave outputs
Rate control

2x Envelopes
Individual ADSR controls for each envelope
Individual gate inputs
Individual envelope outputs


Multi-mode 2 pole VCF (Voltage Controlled Filter)
Low pass / Band pass / High Pass individual inputs
2x Frequency Modulation inputs with amount controls
Filter cutoff
Filter resonance


Mixer
Noise w/level control
Aux input w/level control


VCA (Voltage Controlled Amplifier) with overdrive control
Compatible with Eurorack standard 1V/Oct gear
Monophonic and patchable allowing individual pitch control of each VCO and gate control of each envelope
USB bus-powered
MIDI In / Out
Headphone out
Line out
Analogue clock in & out


USB-MIDI to 1V/Oct CV & gate conversion
All pitch and gate control is fully analogue
Analogue clock In / Out


Multi-function Joystick control
Left / right for pitch bend
Performable portamento
Performable vibrato
This is in addition to the analogue LFO
Latching hold mode


Arpeggiator
6 arpeggiator types
Up, Down, Up/Down 1, Up/Down 2, Played & Random
Auto clock sync
Detects analogue / MIDI or USB-MIDI clock and synchronises the arpeggiator automatically
Selectable sync rates when clock detected
Rate / sync control
Latch
6 Octave range
Analogue / MIDI / USB-MIDI Clock output when arpeggiator is running


Keyboard Control
32 Velocity-sensitive mini-keys
Octave shift +/- 4 octaves
Pitch output
Velocity output
Gate output
Local Off mode for DAW use


Includes:
5 Patch cables

Power Supply (9V 600mA)
USB C lead

Getting Started Guide


Weights and Dimensions:

Product (unboxed):
490 x 250 x 80 mm
2.61 kg

Product (boxed with contents):
690 x 320 x 160 mm
3.70 kg

Notes: A beautifully realised instrument drawing on West coast and East coast synthesis concepts to create something new and beguiling. Three oscillators, smooth filter and Buchla-style dynamics controller.

Supplier's Notes:
Taiga Paraphonic Modular Synthesizer

Taiga is a complete, modern, modular instrument that allows us to explore beyond the boundaries of a traditional analog synthesizer. The sound of Taiga can be attributed to three uniquely Pittsburgh innovations. A trio of huge analog oscillators, the unmistakably smooth sound of the Pittsburgh Filter, and the warmth of the unique Dynamics Controller. These enable you to not only create sounds that would be traditionally expected from an analog synthesizer, but also to explore new sonic textures and performance possibilities.

Taiga oscillators

Waveforms generated by the three Taiga oscillators stretch beyond the basic geometric shapes and sounds associated with analog synthesis. Taiga waveforms pass through up to three proprietary, cascading waveshapers designed to precisely manipulate their symmetry and harmonic content. In addition, each oscillator includes a robust six-stage wave folder to add even more complexity and depth to the diverse sonic palate of Taiga.

The Pittsburgh Filter

The Pittsburgh filter has defined the sound of Pittsburgh Modular from the moment it was introduced. A signature gummy and relaxed sound with no dead spots that has been tweaked to perfection. It offers a warm, smooth sweep through the full frequency range and a sweet resonance that does not roll off the low end. This generation of the Pittsburgh filter is specifically designed to ensure a remarkable interplay with Taiga's oscillators.

Pittsburgh Dynamics Controller

Pittsburgh's new Dynamics technology imparts Taiga with a uniquely organic depth and presence. By simultaneously managing both amplitude and harmonic content, the Pittsburgh Dynamics Controller expands beyond the one-dimensional VCA found in other synthesizers. It does this by utilizing new advancements from traditional low pass gates to add additional definition and dimension to the voice of Taiga.

When used in low pass gate mode, sounds shed harmonic content and become warmer as they decrease in volume. This mimics how sound waves react to their environment. Because of this connection, the Taiga sounds more natural or complex compared to other instruments.

Analogue Echoes

Echos is a beautifully dark analog delay tuned to enhance the source material by repeating it over and over. Echos utilize a pair of bucket brigade delay chips to produce a classic voltage-controllable analog delay effect that helps to place the sounds of Taiga in a simulated environment.

Open Architecture

Taiga has an internally defined signal path. Patch cables are not necessary to begin exploring. Attach a midi keyboard and plug the output into a speaker or DAW and Taiga is ready to go with a robust but familiar workflow. When your ideas grow beyond the pre-defined signal path, a 60 point patch bay opens up a fully modular instrument with access to an even deeper set of features and tools.

Complete Set of Modular Tools

Taiga includes a host of fully modular, analog, and digital synthesis tools to support and enhance its core functionality. Analog tools include a flexible dual mixer, a pair of plucky four-stage envelope generators, noise, and sample and hold. Digital tools cover external MIDI, arpeggiator, clock sync'd modulation tools, and a robust collection of random generators. The Taiga toolset is deep enough for any type of sonic exploration.

Taiga features and other info:

Paraphonic synthesizer with unique additive elements

Fully patchable - use Taiga's components as separate modules with external devices or reroute its internal patching.
Controllable via MIDI, CV, and integrated pseudo random sequencing mode
Clock-synced arpeggiator
3x Pittsburgh Modular Synthesizer developed 100% analog oscillators
Oscillator waveforms - sine, triangle, and saw - Waveforms can be combined
3x Pittsburgh Modular Synthesizer 6 stage wave folder/shaper circuit - folds inputted waves back onto themselves to increase harmonic content
Oscillators include frequency modulation (FM)
Noise generator - pitched somewhere between pure white and pink noise. Perfect for percussion or adding a bit of edge to a sound.
Variable state, multi-mode "Pittsburgh No-Dead-Spots" filter (lowpass, bandpass, highpass, modes can be combined)
Sample & Hold circuit
2x Analog ADSR / envelope generators
Pittsburgh dynamics section - an alternative to an envelope generator and a VCA, the dynamics controller is a Pittsburgh Modular invention that adds a dimension of control over a vactrol-less lowpass gate circuit, adding release time. (read more on this in the user guide)
Dual range analog LFO with square and triangle wave outputs.
LFO Range High: 2 Hz to 500 Hz Low: 41 seconds to 5 Hz
Dual Channel Mixer - 2 channel mixer and a 3 channel mixer joined together, capable of mixing both audio or control voltages.

Notes: The Mother-32 is a distinctive analog instrument that brings raw sound, step-sequencing and extensive interconnectivity to any electronic or modular ecosystem. This expansive live performance and production synthesizer is designed to provide experimental musicians and synthesists with a diverse array of creative tools to inspire new ideas, unique sound and endless sonic exploration.

Drive synchronized sound with Mother 32's powerful step sequencer while utilizing its modular patchbay and assignable output to spawn a living, breathing organism with dynamic and modifiable sound processing. Patch multiple control and sound sources into Mother-32's voltage controlled mixers and truly unlock the vast potential of this powerful instrument, or pull all of the patch cables, plug in a MIDI cable and simply drive your Mother-32 from any MIDI-equipped device.

The Mother-32 is secured in an extruded aluminum enclosure with wood sides, but can also easily be relocated to almost any Eurorack enclosure.

During the prototype phase, Moog worked with 3 unique synthesists: Erika (Interdimensional Transmissions), Max Ravitz (Ghostly International), and Bana Haffar to produce a video that explores Mother-32's vast capabilities. Through performance and sound design, each artist displays the extensive vocabulary found within Mother-32. All patches were performed live, with no overdubs.

Specs

Sound Engine: Analogue
Polyphony: Monophonic
Keypad: 13 Note
Step sequencer: 32-Step with 64 Sequence Locations, Keyboard and Step Edit Modes
Sequencer panel controls: Tempo, Swing, Run/Stop, Hold, and Reset
Sound sources: 1 Oscillator With Pulse and Saw Waveforms, 1 White Noise Generator, 1 External Audio Input
Oscillator range: 8Hz-8KHz (16KHz max with LFO/CV)

Notes: The Subsequent 37 is a (2-note) paraphonic analogue synthesizer that builds upon the award-winning design of the ultra-powerful Sub 37 Tribute Edition. Its control panel is home to 40 knobs and 74 switches, placing a vast array of analogue sound-design tools and onboard sequencing options immediately at your command. The Subsequent 37 improves upon its source through the implementation of a number of user-requested sonic and functional enhancements. Each enhancement maintains the magic and character of its predecessor while also providing access to new dimensions of sound and improved playability.

The SUBSEQUENT 37 mixer section has double the headroom of that in the Sub 37 Tribute Edition. This provides access to a new range of classic clean tones in both mono and duo performance modes. Leveraging the mixer's newfound flexibility, gain-staging in the Ladder filter has been reshaped to boost harmonic saturation and analogue compression, resulting in an overall richer low end. Completing the sonic evolution of the SUBSEQUENT 37 is a re-tuned Multidrive circuit that extends well beyond the grit and growl of the original Sub 37.

"We are really excited to incorporate community feedback into the evolution of an instrument. Adding CV interconnectivity was the starting point, but we have also increased the headroom in the mixer and significantly extended the range of Multidrive, giving the Subsequent 37 CV expanded sonic capability and modular control." - Cyril Lance, Moog Chief Engineer

In addition to the sound engine augmentation, each SUBSEQUENT 37 comes with an upgraded keybed for improved playability, a high-powered headphone amplifier strong enough to drive the most demanding headphones, and a software plugin/editor for both Windows and Mac platforms.

Specifications

Sound engine: Analogue
Polyphony: Selectable monophonic or paraphonic (can be poly-chained)
Keybed: 37 note semi-weighted with after pressure
LCD: 128 x 64 pixel LCD with white backlight
Controllers: Pitch bend, mod wheel, after pressure, velocity
Sound sources: 2 variable waveshape oscillators, 1 square wave sub oscillator, 1 analogue noise generator, 1 external input/filter feedback
Oscillator calibration range: 22hz-6.8khz. Note range at 8' = 18 - 116
Glide module: Assign to osc1/osc2/both. Type - LCR, LCT, EXP, gated, legato

Notes: Originally released in 1970, Minimoog Model D was the world's first portable synthesizer and served as the archetype for all electronic keyboards that followed. The all-analog instrument gained acclaim for combining the colossal sound of the 1960s Moog modular synthesizers with the accessibility of pre-wired modulesimeaning that it could be played instantly and intuitively with no patch cables required. It was quickly embraced by a diverse roster of performers, with artists like Herbie Hancock, Kraftwerk, Rick Wakeman, Sun Ra, Piero Umiliani, Giorgio Moroder, Bernie Worrell, and Gary Numan all shaping unique sounds and forging new musical genres using the instrument.

More than a half-century since its invention, Minimoog Model D is back in production at the Moog factory in Asheville, North Carolina. An exceptional sonic tool and one of the most beloved and iconic synthesizers ever designed, it returns to the hands of synthesists of all kinds and serves as inspiration for the next generation of electronic musicians.

The three-oscillator, monophonic, analog synthesizer is securely housed in a locally sourced Appalachian cherry cabinet and hand-finished aluminum chassis. Sounding as vibrant and deep as ever, its legendary low-pass ladder filter, powerful oscillators, and rich saturating mixer retain the exact component placement and through-hole design of a 1970s-era Minimoog Model D.

While no changes have been made to the original sound engine or audio signal path, the 2022 Minimoog Model D includes a series of popular functional modifications that expand this legendary instrument's sonic capabilities. These modifications include a dedicated analog LFO with triangle and square waveshapes, a premium Fatar keybed with velocity and after pressure available via top panel CV jacks with onboard trimpots, MIDI integration, and a mixer feedback modification which allows the Minimoog Model D to overdrive and scream with the turn of a knob. And, for the first time in its history, the Minimoog Model D now features a spring-loaded pitch wheel with center deadband, allowing for improved playability and wild performance flourishes. This newest edition also includes updates to the MIDI functionality, allowing for improved modern studio integration.

SPECS
NUMBER OF KEYS
44
KEYBOARD RANGE
F0 to C4
KEYBOARD ACTION
Synthesizer (Spring)
NOTE PRIORITY
(Low, High, Last): User Selectable
SOUND SOURCES
3x Oscillators, Noise Generator and External Audio Input
OSCILLATOR FREQUENCY RANGE
0.1 to 20 kHz (In Six Overlapping Ranges)
OSCILLATOR STABILITY
(short term) > 0.25 %
OSCILLATOR WAVEFORMS
Triangle, Triangle-Sawtooth (Oscillator-1, Oscillator-2), Reverse Sawtooth (Oscillator-3), Sawtooth, Rectangle, Wide Pulse and Narrow Pulse.

Notes: An exact replica of the legendary Pearl SY-1 Syncussion drum machine, featuring expanded I/O board. Classic analogue sound with individual trigger inputs, two voices and six different oscillator modes per voice.

Supplier's Notes:
The Michigan Synth Works SY-1 Drum synth is a full size, exact replica of the Pearl SY-1 Syncussion. Every detail has been replicated from the original board layouts to the mechanical construction. The assembled version has been modernized to use current manufacturing processes while still using the original board layouts and all parts have been carefully chosen to match the behaviour of the original. Case, boards, and I/O Boards are all interchangeable with the original Pearl device.

Assembled versions come with the METAL back standard, the wood case is available as a DIY kit separately.

The Syncussion:

The Syncussion is a 2 voice drum synthesizer with two oscillators per voice and six different modes. Five modes mix and modulate the oscillators plus a noise channel. Each voice has controls for TUNE, DECAY, SWEEP amount, SWEEP Speed, Sweep up/off/down, LFO amount, and LFO speed, LFO Shape (Tri or Square), and sample and hold.

OSC Modes:

A: One oscillator sound, at this position the regular drum synthesizer sweep can be effected.

B. Sound of one oscillator adjusting the other oscillator frequency; produces a metallic sound.

C. Sound of a mix of two oscillator outputs; sound is similar to that of a vibraphone.

D. Sound of mix of two oscillator outputs; produces a low to high sweep and is done by hitting pad softly or hard; there is no connection to SWEEP SPEED and SWEEP RANGE

E. Sound of one oscillator adjusting the other oscillator frequency with a mix of noise; produces a sound similar to hitting thin metal.

F. Sound of only noise

Triggering:

The SY-1 is designed to be triggered via drum triggers which output a very low pulse signal. Modern 5V trigger signals (v-trig) can be used, how it i recommended experimenting with simple audio samples or more dynamic triggers. One of the more interesting features of the Syncussion is the dynamic response to the drum triggers and just sending a straight pulse which maxes out the trigger inputs does not do the device justice.

Tuning:

The original SY-1 uses a tune pedal to adjust the pitch of both oscillators while playing. This functionality has been retained in the original configuration but is of limited use without the pedal. The expanded version DOES have per voice CV control (1v/Oct) as well as the MIDI.

The inputs and outputs use 1/4" Stereo to 1/4" (3 included) to greatly expand the capabilities of the device. The Mod input is prewired to VCF freq but can easily be switched to decay via jumper on the voice cards.

The SY-1 ships with a metal base panel but the DIY wood case can be used instead. It is provided UNFINISHED and sold separately.

Whats included:

SY-1 Synthesiser

Universal Power adapter (100-240V, 12V DC out, Tip Positive)

Expanded I/O: 3x 1.5m TRS 1/4" Phone to 2x TS 1/4" Phone

Notes: The Korg Monotron Duo is capable of creating even stranger, extreme and diverse sounds. The combination of 2 oscillators in unison provide thick, rich analogue tones, while tuning them to different intervals can create classic solo synth sounds and powerful effects. Korg have utilized their X-Mod (cross modulation taken from their classic Mono/Poly synths) circuitry in the Monontron Duo, enabling you to generate the mildest of sounds, to vibrant vibrato, to sharp, fm style abrasive synth sounds.

The Monotron Duo features Korg's fantastic enhanced ribbon controller keyboard and now features the same scale function as used on the Kaossilator, chromatic, major, minor or off scales are available, allowing your music juices to flow freely over any music. The distinctive tone of an analog filter (VCF) can dramatically alter and enrich the sound. The Monotron Duo uses the same highly acclaimed VCF circuit as Korg's classic MS-10 and MS-20 semi modular synthesizers. Originally released over 30 years ago, these instruments are still coveted today for their aggressive, dynamic filters. The VCF Cutoff knob sets the frequency or tone of the filter; the VCF Peak knob adds emphasis. A powerful filter is an essential aspect of any analog synthesizer, applying dramatic tonal changes to the sound, and projecting an intense personality that will stand out in any live performance.

The input jack (AUX input) built into the Monotron Duo's compact body allow you to place any audio source into the Monotron Duo's signal path, directly before the analog filter. This provides a great way to connect a Kaossilator, a guitar, or a digital audio player to the Monotron and enjoy tone-bending filter effects.

A miniature speaker is built into the Monotron Duo. Along with the battery operation and compact size, this feature allows you to enjoy the share the Monotron Duo's analog synthesis sound with your friends, anywhere, at any time. There's also a headphone output that you can use when practicing in private, creating sounds at home, recording, or for connecting to an amplifier or PA system.

http://www.youtube.com/watch?v=wWLOxRSll5Q

Notes: A good delay was an essential part of the classic analog synthesizer sound. More often than not, that delay came from a tape-style echo machine until affordable digital delays were created. The Monotron Delay is an analog synthesizer optimized for sound effects. In addition to its analog oscillator, filter and LFO, it also provides a space delay that's indispensible for swooping, cosmic sounds. The monotron Delay even reproduces the pitch changes that occur when you vary the delay time, just as though you were using an analog tape echo. This fat and warm delay will add an authentic edge to your analog sounds.

It also features Korg's class VCF filter for full control over your sounds. The distinctive tone of an analog filter (VCF) can dramatically alter and enrich the sound. The Monotron Delay uses the same highly acclaimed VCF circuit as Korg's classic MS-10 and MS-20 semi modular synthesizers. Originally released over 30 years ago, these instruments are still coveted today for their aggressive, dynamic filters. The VCF Cutoff knob sets the frequency or tone of the filter; the VCF Peak knob adds emphasis. A powerful filter is an essential aspect of any analog synthesizer, applying dramatic tonal changes to the sound, and projecting an intense personality that will stand out in any live performance.

Create classic sounding analogue tape delays to add warms and new dimensions to your synth sounds. Also included is Korg's fantastic enhanced ribbon controller keyboard, while a mini jack input also allows you to run any external audio, such as a Kaossilator, digital piano or guitar, through the Monotron Duo. As standard, the Monotron range comes with a powerful built-in speakers and is battery operated for the ultimate portable experience.

The Low Frequency Oscillator (LFO) waveform used to modulate the pitch now offers a choice of waveshapes, which is a new square wave plus the traditional triangle wave. Both the rate (speed) and the intensity (depth) can be adjusted independently. In addition, a trimpot on the back panel can continuously adjust the shape/direction of the triangle wave or the pulse-width of the square wave to deliver even more versatility. Used in conjunction with the delay, the LFO can create dazzling effects and provide unique possibilities for embellishing your songs.

The Monotron Delay's ribbon controller keyboard features a wide, 4-octave range. This design allows the pitch to be controlled even more aggressively and dynamically, making the Monotron Delay a great weapon for a DJ to get the floor moving with irresistible sound. The reversed white keys and body adornments glows under black light illumination, making the monotron Delay ideal for delivering a striking visual impact in nearly any club environment.

The input jack (AUX input) built into the Monotron Delay's compact body allow you to place any audio source into the Monotron Delay's signal path, directly before the analog filter and delay circuit. This provides a great way to connect a Kaossilator, a guitar, or a digital audio player to the Monotron and enjoy tone-bending filter and delay effect.

A miniature speaker is built into the Monotron Delay. Along with the battery operation and compact size, this feature allows you to enjoy the share the Monotron Delay's analog synthesis sound with your friends, anywhere, at any time. There's also a headphone output that you can use when practicing in private, creating sounds at home, recording, or for connecting to an amplifier or PA system.

Notes: The Korg Monotron Duo is capable of creating even stranger, extreme and diverse sounds. The combination of 2 oscillators in unison provide thick, rich analogue tones, while tuning them to different intervals can create classic solo synth sounds and powerful effects. Korg have utilized their X-Mod (cross modulation taken from their classic Mono/Poly synths) circuitry in the Monontron Duo, enabling you to generate the mildest of sounds, to vibrant vibrato, to sharp, fm style abrasive synth sounds.

The Monotron Duo features Korg's fantastic enhanced ribbon controller keyboard and now features the same scale function as used on the Kaossilator, chromatic, major, minor or off scales are available, allowing your music juices to flow freely over any music. The distinctive tone of an analog filter (VCF) can dramatically alter and enrich the sound. The Monotron Duo uses the same highly acclaimed VCF circuit as Korg's classic MS-10 and MS-20 semi modular synthesizers. Originally released over 30 years ago, these instruments are still coveted today for their aggressive, dynamic filters. The VCF Cutoff knob sets the frequency or tone of the filter; the VCF Peak knob adds emphasis. A powerful filter is an essential aspect of any analog synthesizer, applying dramatic tonal changes to the sound, and projecting an intense personality that will stand out in any live performance.

The input jack (AUX input) built into the Monotron Duo's compact body allow you to place any audio source into the Monotron Duo's signal path, directly before the analog filter. This provides a great way to connect a Kaossilator, a guitar, or a digital audio player to the Monotron and enjoy tone-bending filter effects.

A miniature speaker is built into the Monotron Duo. Along with the battery operation and compact size, this feature allows you to enjoy the share the Monotron Duo's analog synthesis sound with your friends, anywhere, at any time. There's also a headphone output that you can use when practicing in private, creating sounds at home, recording, or for connecting to an amplifier or PA system.

http://www.youtube.com/watch?v=wWLOxRSll5Q

Notes: State-of-the-art analog modelling and multi-band vocoding are finally available in a compact, portable instrument. With 37 keys and 128 user-rewritable programs, the microKORG synthesizer/vocoder is perfect for the performer, producer, computer musician or beginner looking for an affordable synthesizer. The new microKORG delivers the quality sounds and features you expect from Korg at a price that will astound you.

The microKORG boasts the same dual-oscillator DSP synthesis engine found in Korg's critically acclaimed MS2000 and offers a wider selection of waveforms than any other modelled synth. Oscillator 1 features a total of 71 waveforms. These include traditional analog waves like saw, pulse, sine and noise, plus more unique choices like Vox wave and cross wave. Together they provide a cool selection that can be modulated to produce an extensive range of timbres. In addition, 64 exclusive DWGS waveforms from Korg's classic DW-8000 enable the microKORG to reproduce a broad collection of imitative sounds. Sounds like bells, electric pianos, guitars, basses and more that would be difficult reproduce on an analog synthesizer. You can also apply Ring and Sync modulation from Oscillator 2 to create the kind of complex timbres that are the true sign of an advanced synthesizer.

4 filter modes are available, offering -12 dB (2-pole) low pass, high pass and band pass configurations plus an extra steep -24 dB (4-pole) low pass setting. All include resonance. 2 classic ADSR envelope generators and two MIDI-syncable LFOs provide the power to shape your sounds. Add a virtual patch matrix that lets you create advanced modulation settings U routing the mod wheel to control filter cutoff or pulse width, using an LFO to control panning or amp level, etc. U and you have performance that is unheard of from a synthesizer in this price range.

The microKORG includes an 8-band vocoder with many advanced features. You can capture and freeze the formants of your voice, and then play it across the keyboard, or shift the formant frequency to make your voice sound male, female, like a child or just plain wacky! Best of all, the microKORG comes with its own microphone so you can start having fun right away.

3 types of modulation effects (chorus/flanger, phaser, ensemble), 3 types of delay effects (stereo, cross, L/R) and a 2-band equalizer add the finishing touch to the microKORG. The delays can be synchronized with the arpeggiator or to an external MIDI clock U a great feature for live performances or for laying down tracks. All effects can be edited to create your own, unique sounds.

Korg have used all of the microKORG's synthesis power in the creation of 128 great-sounding presets. They cover a wide range of the latest musical styles plus many vintage favourites. Sixteen vocoder Programs are also included. The pitch bend wheel, modulation wheel and 5 other knobs provide flexible realtime control over filter cutoff, attack, release and other important parameters. The edit mode allows you to fully edit the existing sounds, or to create your own new ones.

6 types of arpeggio patterns (UP, DOWN, ALT1/2, Random, Trigger) are built in, with control over tempo, gate time, swing, and up to a 4-octave range. You can turn individual steps on or off within a pattern, providing the feel and functionality of a step sequencer.

2 external audio input jacks are provided, so you can run other instruments, CDs and more through the microKORG's filter and effects, allowing you to process sounds in truly creative ways.

The microKORG's compact size is perfect for the musician or DJ looking to add a synth to his or her setup when space is tight. It's also a great choice for use in a computer-based music setup. The five realtime knobs on the front panel can transmit MIDI messages (control changes), so they can be used as controllers for software synthesizers. Use the 37-note velocity-sensitive mini-keyboard for controlling other gear or for recording and editing with your sequencer. And thanks to battery-power, the microKORG is the ultimate portable controller when used with a laptop computer!

There's no complex menu structure - all parameters are located on the panel for easy access to any function. A large dial and LED illuminated buttons provide easy program selection even on a dark stage. With its beige-gold body, wooden side panels and retro-influenced design, the microKORG has a look that's both vintage and funky.

Notes: The Korg Volca Keys is an ideal introductory synthesizer, with a simple, yet powerful polyphonic analog sound engine and loop sequencer.

The Volca Keys is a long awaited synthesizer that adds a new chapter to the long and storied history of Korg's analog synthesizers. This 27 key analog lead synth delivers unbelievably powerful sound in a compact body. Starting with a filter section that uses the circuitry of the legendary miniKORG700S (1974), it delivers astonishing sound that takes full advantage of Korg's half-century of know-how in circuit design.

With a simple structure that includes delay effect and a sequencer, it's also an ideal choice for a first analog synth. It offers the richly expressive sounds that are distinctive of analog, providing the enjoyment of simple yet deep sound-creation. The possibilities are endless; you can use the three oscillators to play chords, use them in unison with detune to produce solid lead lines, or apply ring modulation to create far-out metallic sounds.

The Voicing function makes it easy to specify how the three oscillators will be combined. Choose between poly, unison, octave, fifth, unison ring or poly ring simply by turning a dial. Easy for those taking thier first steps into synthesisers, the Volca's simple design makes it easy to obtain a wide variety of sounds.

Record phrases as you play them with the Volca Keys using the loop sequencer. With up to 16 steps, it's easy to create phrases as they come to mind. Use the overdub recording function to produce complex loops, with up to 8 sequence patterns able to be stored in internal memory. Craft your loops with the motion seqence function, apply time varying changes to your sound to enhance loops and add originality to your life performances.

Skip a step during sequence playback with active step, a function that creates effects similar to a short loop or unexpectedly irregular rhythms. This allows you to create a dynamic performance just as though you were performing the sequence itself. Flux function lets you play back the phrase without quantizing the steps, producing a loop with a distinctive sense of groove.

A useful self-tuning function constantly tunes the oscillators, so you never need to tune during a performance or wait for the pitch to stabilise after turning the power on.

Connect the Volca Keys with the rest of the Volca Series or a Monotribe using the sync jack. A MIDI in connector lets you synchronise with other devices, play the Volca from any MIDI keyboard and send note messages from your DAW.

The Volca Keys analogue loop synth has a compact size and a built-in speaker, easily playable anytime, anywhere. The ideal starter-synth.

http://www.youtube.com/watch?feature=player_embedded&v=7rbcYJ326EI

Notes: A whooooole lot of synth power for the money, building on the original Minilogue's analogue platform with a load of added digital features. Hard to think of many more versatile synth modules.

Supplier notes:
Minilogue XD module is the new desktop module version of Minilogue XD, the four-voice polyphonic analogue synthesiser with a customizable digital multi-engine and built-in stereo digital effects.

The desktop module is equipped with the same controllers as the keyboard version, making it a great choice not only as an additional sound module for your keyboard or DAW but also providing excellent performability, giving you an easy way to include an analogue polyphonic synth in your setup. It's also equipped with a poly-chain function that lets you connect it with another Minilogue XD or Minilogue XD module so that the two units can operate as a polysynth with a total of up to eight voices in your studio or on stage.

Add the sounds of the Minilogue XD to your setup or system!

Equipped with an analogue synthesiser circuit and a digital multi-engine:

Voice structure of Minilogue XD is 2VCO + MULTI ENGINE, 1VCF, 2EG, 1VCA, and 1LFO. In addition to the distinctive circuits found in the series, such as wave shaping to shape the overtones of the oscillator and a sync/ring switch, there's also cross modulation, a two-pole filter that can be both sharp and fat, and a drive switch that adds thickness and drives signal into Minilogue XD's filter. Every parameter has been tuned in detail based on what musicians want out of their synth. The sounds range from the warm pads typical of analogue to fat basses and crisp lead sounds, covering every situation.

The additional sound design possibilities of digital sound are delivered by the multi-engine: the third oscillator in addition to the two analogue VCOs. This engine, which is equipped with three different types of sound generator (noise, VPM, and open-source user oscillators) lets you take advantage of a sonic character that's different than analogue, and use it at the same time as the analogue engine, infinitely expanding XD module's potential through hybrid sound design.

High-quality digital effects:

Minilogue XD's high-quality digital effects use 32-bit floating point DSP processing, adding a finishing touch to its deep sound design platform. The three types (modulation effects, reverb, and delay) can be used simultaneously, letting you choose from a wide range of variations including chorus, ensemble, warm tape delay, and a diverse variety of reverb. The user effect slots allow you to load your own effect programs that you've created.

User customization brings out infinite potential:

The Minilogue XD features a customizable open-source environment. The unit comes with 16 user oscillator slots and 16 user effect slots that you can customize. Oscillators and user programs that you've created with the SDK (Software Development Kit) can be loaded into the Minilogue XD via the dedicated librarian software, as well as oscillators other users share online.

What sounds can you create using the fusion of expanded digital oscillators with analogue synthesis? Create original programs, share code, and participate in the user community. KORG even provides sample code to get you started.

Polyphonic Step Sequencer:

One of the major features of the Minilogue XD series is its 16-step step sequencer. Each of the factory-preset programs has an embedded sequence pattern created with performance in mind.

The step sequencer provides 16 steps, and supports both realtime recording and step recording. You can use the 16 step buttons to select a step directly, allowing quick editing to replace the pitch of a step or to mute it, or even improvisatory performances. Motion sequence lets you record the movements of up to four knobs, adding time-varying change to the sound, and you can record not only smooth changes in value but also values that change precisely at each step. You can use this to have different parameter values at each step; for example, you might create a drum pattern or sound effect from just a single program. This allows countless ideas to be unleashed.

Poly chain support:

The Minilogue XD module can be used in conjunction with another unit in the Minilogue XD series for poly assignment settings. Specify one unit as the master and the other as the slave, and they will play as an eight-voice polyphonic synthesiser. This supports a variety of uses, such as a voice-expansion module for the Minilogue XD or as a sound module for a DAW-based production system.

Free bundle of music software:

The Minilogue XD module comes with a diverse variety of music software from Izotope including "Ozone Elements" which lets you not only create songs but also master them using AI, "Skoove" which will help you improve your keyboard playing skills, "Reason Lite" DAW software, as well as software synths from KORG and other brands.

Notes: Killer value for money here. Korg's budget synth brings proper analogue polyphony to a crazy price point. Amazingly versatile with sound to match synths two or three times the price.

Supplier's notes:
Meet minilogue; the stylish, innovative, 37 slim-key fully programmable analog polyphonic synthesizer:
minilogue's newly developed analog synthesizer circuit delivers polyphony and full programmability at a great price --- exactly what today's musician needs. With the minilogue, you can get your hands on the powerful sound that's only possible with real analog, and find inspiration with features including a polyphonic step and motion sequencer, on board tape-style delay, multiple sound shaping and filter options, and an oscilloscope display. All of these seamlessly integrated features make minilogue as fun and easy to use as it is powerful. It's the next-generation analog synthesizer for musicians of all types.

True analog sound:
The synth circuits for minilogue are all new ground up designs, delivering a synthesizer experience like no other. Unprecedented in this class, it's a four-voice polyphonic true-analog synth with an interface that's designed for accessibility. Whether you're performing live or producing in the studio, the minilogue is the fastest way for the user to explore and implement real analog synthesis in any situation.
The structure consists of 2VCO, 1VCF, 2EG, 1VCA, and 1LFO. The minilogue's unique wave shape capability lets you fine tune the oscillators' harmonics, creating the most divine sounds and compositions. The minilogue is also equipped with a variety of powerful types of modulation including cross modulation, oscillator sync, and ring modulator, as well as a delay with a high-pass filter. Powerful sound creation and rich variety are the true hallmarks of an analog synthesizer.

Polyphony and Presets - Perfect:
minilogue goes beyond analog synths in its price range by adding 200 preset locations. Select a program for instant access to great sounds - - ranging from thick basses to deep pads to brilliant polyphonic leads and atmospheric sounds. No need to have deep synthesis knowledge; just choose a sound and tweak - a workflow that is very familiar with musicians today. For those who want to dive deeper into the heart and soul of minilogue's engine, the minilogue hold 200 programs; with 100 editable factory programs included, and 100 locations serving as blank canvases on which to create your next analog masterpiece. Each preset can also hold a step sequence and delay settings along with the sounds you create.

Voice modes:
Selectable voice modes let you freely configure the four voices for performance. The voices can be set to four note polyphony for chords or layered for thick basses and leads. Other modes cover a range of sounds from octave shifted bass explosions to delicately staggered layered triggering.

Eight voice modes:
- POLY - operates as a four-voice polyphonic synthesizer
- DUO - operates as a unison two-voice polyphonic synthesizer
- UNISON - operates as an all-unison mono synthesizer
- MONO - operates as a mono synth with sub-oscillator
- CHORD - produces chords
- DELAY - voices 2--4 sound consecutively at a delay following voice 1
- ARP - an arpeggiator operates with up to four voices
- SIDE CHAIN - when a note sounds, the volume of the preceding voice is lowered

16-step sequencer:
Get creative with the intuitive 16-step sequencer with motion sequence recording capabilities, and make your sound truly come to life. The minilogue provides real-time recording with overdubbing, and step recording that lets you record simply by consecutively specifying notes, giving you a great way to create phrases and performances.

Oscilloscope visualizes the sound:
The OLED display will show the waveform as you sculpt your sound. Visual feedback is both educational and entertaining, and represents a first on a hardware synthesizer.

Build quality:
The uniquely curved, sand-blasted 2mm aluminum front panel, metal shaft potentiometers, solid, chassis-mounted metal shaft potentiometers and rubber-coated knobs give the roadworthy minilogue a standout look and feel to complement its powerful and dynamic sound creation capabilities.

Sync with groove machine:
In addition to the standard MIDI connectors, the minilogue provides a sync connector that can be easily connected to Korg's groove machines. Connect this to a volca series unit, an electribe, or the SQ-1, and experience a session with synchronized sequencer playback.

Notes: A modern classic from Korg's affordable Volca range. Genuine analogue business with a built-in sequencer, ideal for acid house bass. A much more powerful synth than you might expect for the money.

Supplier notes:
The Korg Volca Bass is a powerful analog bass sound creation and an Electribe-inspired sequencer for the ultimate bass lines.

Although simple in structure, the analog sound engine has an unmistakable presence with subtle nuances that cannot be reproduced by a digital simulation; it's a great choice for acid house and many other styles of music. The step sequencer distilled from the Electribe is not only visually intuitive; it's also a powerful way to generate "free form" bass loops that will stimulate your inspiration.

Notes: A year ago, Jomox brought out the Mod FM as a eurorack module.

Now, Jomox present almost the same synth, but as a desktop unit, with its own PSU, Midi, standard 1/4" balanced outputs and analogue volume control.

The Mod FM D has an analogue side chain stereo input that gets routed into the Mod FM D effects, and can be mixed to the synth.

The ratio of synth + input/effects can be controlled via an analogue dry/wet potentiometer.

The Mod FM D is a completely self-contained 8 voice FM synth in desktop format, which can create powerful sounds out of the box without lacking the commonly provided CV modulation possibilities.

It provides 4 Operators and 2 LFOs/VCOs per voice. Additionally, it has 2 analogue filters and analogue VCAs per voice which apply analogue warmth and depth to the Mod FM D, although the FM engine is digital of course.

Each voice has its own CV/Gate inputs and an individual output. There is a mix output which separates even and odd voices. Here you can mix internal effects like delay and reverb to the stereo output signal.

Next to the CV/Gate control, the Mod FM D has Midi in and out and a USB C connector which handles Midi too.

Even without diving too much into complicated setups you can create extremely good sounding and metallic FM sounds, snappy bases but also soft and deep sounding analogue style sounds as tons of crazy weird stuff.

Furthermore, the Mod FM D offers a variety of external cv modulations in order to modulate each operator individually or control the FM envelopes.

The Mod FM D is fully multitimbral, i.e. each voice can play an own sound in Multi Mode which gets stored as a complete multi set (not only vectorized). That is, you can copy a single sound to the desired multi, but edits made on that particular multi get stored along with the multi set.

Hence, we have the biggest advantage of the hybrid approach:

Analogue and modular is great but can be very complex, and you might be trapped in a system where you never reach again the pretty sound of the latest session. Storability certainly helps.

The different sections in more detail:

Matrix FM:

4 operators are arranged in a matrix, in which every operator (= sine oscillator) can be modulated by each one of the other three.

The 16 endless potentiometers of the matrix adjust the modulation amount (FM amt) and the base frequency of the operators.

For each operator you can change the base frequency by the diagonal knobs.

There are several overtone modes that determine if one operator is controlled by the keynote (or CV) = base operator, or if it's locked in as overtone (= overtone operator) to the assigned base operator. For the base operator, the number resembles xxx semitones added to the keynote.

For the overtone operator, the adjusted number is the xxx = Nth overtone or harmonics to the base operator frequency.

The locked overtone operator tracks the base operator and is still able to modulate and being modulated.

Each operator has an ADSR envelope. This envelope can also be used to frequency-modulate the operator.

Algorithm:

The algorithms from the known FM synthesis are actually special cases to the whole matrix.

As it gets pretty quickly uncontrollable if you turn all the knobs due to the feedback, Jomox have decided to implement the algorithms. There are 26 algorithms, that are derived from the DX9 with its 4 operators.

At this menu it's even possible to change the frequency mode of each operator to a fixed frequency that is edited in single Hz and which does not follow the keynote, but only modulation. That makes sense for e.g. percussive sounds.

LFO/VCO:

Each voice has 2 LFOs which can modulate either the frequency (FM) or the amplitude (AM) of an operator. Every LFO addresses 64 different wave forms that are displayed in the right OLED display.

There is another feature: each LFO can be switched into a VCO that covers the whole audio range. You can even mix it into the signal chain and it tracks to the keynote. The former LFO rate parameter turns into a detune parameter. That is, you can create classic sounding rectangle/sawtooth analogue basses or string pads - and much more of course.

Filter:

Each voice contains an analogue filter which is build up with the chip SSI2140 from Sound Semiconductor, which is an improved modern version of the old SSM2040, designed by Dave Rossum, and which had been used in Oberheim synths and the early SCI Prophet-5.

The filter has a classic 24dB output and a 12dB state-variable multimode-filter. The three basic characteristic outputs LP/BP/HP can be cross-faded continuously with one parameter called shape.

Both filter outputs 24dB/12dB can be mixed independently.

The ADSR for the filter is fast and cuts in very quick and directly, the resonance is well adjustable.

The filter section contains an own LFO for the cutoff which is independent from the digital sound engine and has also 64 waveforms.

The ADSR for the filter is fast and cuts in very quick and directly, the resonance is well adjustable.

The filter section contains an own LFO for the cutoff which is independent from the digital sound engine and has also 64 waveforms.

The VCA is a fast transistor-vca which is important for snappy sounds. The same transistor-vca is used in all Jomox drum products. Therefore the ModFM can be used as a rich source for technoid drums and percussions of any kind.

On the analogue voice board there is another sound source: Metal Noise. It can be mixed into the filter independently from the digital engine (= FM synth) and offers again an inexhaustible pool of weird sounds.

FX:

The Mod FM D also has an FX section added: reverb and 2x delay. These only work on the stereo mix output. The delay can be beat-synchronized via midi clock and offers a very short delay time in millisecond range. That gives you flanging and oil-can-like effects.

Specifications

8 voices fully multi timbral FM synth
4 operators per voice
Full modulation matrix / 26 algorithms
2 LFO/VCOs per voice
Balanced stereo 1/4" jack outputs
Stereo Hi-Z 1/4" jack inputs
Analog effects mix
Outputs for each voice plus mix out
CV/Gate per voice
CV modulation inputs per operator
True audio FM modulation inputs
True analogue filters per voice
24db low pass
12dB multimode LP/BP/HP cont. shape
True analogue VCAs per voice
Midi in, out
USB C device
Digital reverb, 2x stereo delay
Full storability, also CV amounts
128 presets, 118 multi sets
2x 128x64px OLED displays

Power consumption: 12V=DC 2A max.

Dimensions:

Width: 318mm
Depth: 180mm
Height front: 44mm
Height back: 72mm

Weight: 1,9kg (4.4 lbs)

Notes: The JMT RVO-3 is an analog noise synthesiser featuring 2 oscillators. 1 main oscillators with 1 sub oscillators paired to it. Each of the oscillators features their own frequency controls, and sync switches for each of the oscillators pairings allowing a wide range of textures. It has a main VCO with a frequency control knob and a push button allowing a short envelope to control the frequency. Additionally, controls for the waveshapes and stability of the VCO and sub frequency VCO allow for further manipulation of timbre.

Notes: Really nice boutique analogue synth from JMT, based around a main oscillator with three sub signals, a frequency-synced resonant filter, noise source and three-speed random trigger.

Supplier's Notes:
DNVO-1 is a handmade, compact analog synthesizer from JMT Synth Its primary oscillator can be synced with three sub oscillators, each with a different range, as well as a noise source and wave generator. The latter source can be manipulated with the 3-speed random trigger for effective fluctuations within a single performance. The primary VCO is routed through a self-oscillating filter, which can sync with the VCO's frequency.

Notes: A massive semi-modular system in a small case with the footprint of a laptop. Cascadia has MIDI in/out/thru/USB, Eurorack compatible signal levels and pro-level audio I/O to interface with the rest of your studio or get your studio started.

Modern Analogue Architecture

Cascadia is packed with a mix of classic East and West Coast synthesizer blocks. Normalized connections let you get straight to the sounds inside. Or, let your imagination run wild and patch any of the modules together however you choose. Make small tweaks to the architecture, or re-route the entire synth to your liking- the choice is yours!

Summary:
Cascadia semi-modular synthesizer.
101 patch points, 34 sliders, 16 knobs, 28 switches, 5 push buttons, and 36 leds.
14 Patch cables - 4×10cm, 4×15cm, 4×30cm, 2×45cm.
USB-C to A cable.
International AC Adaptor.
Intellijel cable tie.

Two Precision Analogue VCOs
VCO A is Thru-zero FM-ready with a dedicated Index VCA, Sub Oscillator, PWM and Soft/hard sync.
VCO B is a combo VCO/LFO with 4 simultaneous outputs
Six Channel Waveform Mixer
Two patchable (normalled) inputs
Noise generator with multiple algorithms.
Optional asymmetric soft clipping on the mix output.
Liquid-Sounding, Cascaded 4-Pole Multimode Filter
Eight Modes: LP1, LP2, LP4, BP2, BP4, HP4, NT2, Phazor.
Additional dedicated outputs for LP4 and HP4.
Input Level Knob for fine control of filter input and resonance balance and added drive.
Multiple FM inputs and a QM input, all with attenuators.
Wavefolder Circuit
West Coast-style parallel wavefolder.
Normalled into the auxiliary input on the VCA in parallel with the filter.
Dual Digital Envelopes
ENV A is a versatile east coast style ADSR / AHDSR envelope generator with a hold function and dynamic level/time control. Normalled to the VCA to instantly shape your sound.
ENV B is a complex, multimode function generator with a West Coast style AR/ASR/Cycling AR, a beat syncable LFO, Burst generator modes, and the Entropic Sequence Generator (added in 1.3). Normalled to the filter for instant FM without patching.
VCA A and Output Path
VCA A is a linear VCA with auxiliary input.
Global Output Mixer with overdrive circuit and bypassable asymmetric soft clipping.

Expansive Utilities Sections
Cascadia also features a whole host of utilities for getting the most out of your patches.

The Utility Row
Sample and hold circuit with white noise normalled to the input.
Slew/Envelope follower.
Attenuverter/Mixer with multiple outputs.
Triple triangle LFO with rate control, rate input and divided outputs.
Triple buffered multiple.
Precision adder.
Signal inverter.
Bi-polar > Unity level shifter.
Expression level control for modulation the TRS expression input on an FX pedal.
Ring Modulator.
VCA B / LPF (LPG) - Auxiliary VCA and 4-Pole Diode Ladder VCF combination for additional dynamics.
The Top Row
Easy to access Pitch, Gate, and Velocity CV inputs.
Pedal Send and Return FX loop with Wet/Dry control, phase inverter and Line/Pedal level switches.
Output Mixer with Overdrive.
Eurorack Level Main output with level control for interfacing with other modular gear.

The Outside world - MIDI, Pedal and Audio I/O
Cascadia is equipped with a ton of I/O to get it connected to the rest of your gear.

Rear Panel

1/4" Stereo Headphone jack.
1/4" Balanced Output Jack.
1/4" Balanced Input routed to a slider and output on the main panel for patching anywhere into Cascadia.
1/4" TS Pedal FX Send Return and 14" TRS Expression Out.
MIDI DIN In/Out/Thru and USB-MIDI all routed to the MIDI > CV Interface on the top panel.
MIDI > CV Interface
Deeper MIDI configuration is available with the Intelljel Config App (link below). MPE Support has been added in v1.4 and supports the Ableton Live 12 Tuning systems. Dual Mono mode (added in 1.3) allows an additional channel to send its own Pitch/Gate signal on the CC/MOD outputs. All modes support MIDI Portamento.

MIDI Pitch / Velocity Outputs and Learn Button
MIDI Gate / Trig Outputs
MIDI CC / Mod - Learnable and assignable to any CC or Channel Pressure
MIDI LFO - Multimode LFO synced with MIDI or Tap Clock
MIDI CLK - Dividable MIDI clock with alternate Tap Clock functionality.
Cascadia comes ready to play.

The normalization behind the panel allows for a ton of exploration without ever adding a patch cable; there is years of material to explore in Cascadia and years more when you start patching. There is everything you need to get started: 14 assorted patch cables, USB-A to USB-C cable, and an international power supply.

Expand and Customize

In addition to additional patch cables, there are additional options for swapping the wooden cheeks for metal side cheeks or a rackmount kit with a storage tray - great for an effects pedal or patch cables.

Specs

In the Box: Cascadia Semi-modular Synthesizer
14 Patch cables - 4×10cm, 4×15cm, 4×30cm, 2×45cm
USB-C to A cable
Intellijel cable tie
15V/1.2A AC Adaptor (Euro/American prongs included)

Height: 66mm (from rubber foot to top of knobs)
Width: 348mm (including wood end cheeks)
Depth: 246mm (front to rear jacks).
Power: 15V DC/1.0 A (minimum), centre-pin-positive.

Notes: White fog version of Intellijel's brilliant Cascadia, one of our favourite synths of recent years. A huge range of semi-modular circuits combine to create a hands-on instrument with its own distinctive character.

Supplier's Notes:
A massive semi-modular system in a small case with the footprint of a laptop. Cascadia has MIDI in/out/thru/USB, Eurorack compatible signal levels and pro-level audio I/O to interface with the rest of your studio or get your studio started.

Modern Analogue Architecture

Cascadia is packed with a mix of classic East and West Coast synthesizer blocks. Normalized connections let you get straight to the sounds inside. Or, let your imagination run wild and patch any of the modules together however you choose. Make small tweaks to the architecture, or re-route the entire synth to your liking- the choice is yours!

Two Precision Analogue VCOs
VCO A is Thru-zero FM-ready with a dedicated Index VCA, Sub Oscillator, PWM and Soft/hard sync.
VCO B is a combo VCO/LFO with 4 simultaneous outputs
Six Channel Waveform Mixer
Two patchable (normalled) inputs
Noise generator with multiple algorithms.
Optional asymmetric soft clipping on the mix output.
Liquid-Sounding, Cascaded 4-Pole Multimode Filter
Eight Modes: LP1, LP2, LP4, BP2, BP4, HP4, NT2, Phazor.
Additional dedicated outputs for LP4 and HP4.
Input Level Knob for fine control of filter input and resonance balance and added drive.
Multiple FM inputs and a QM input, all with attenuators.

Wavefolder Circuit

West Coast-style parallel wavefolder.

Normalled into the auxiliary input on the VCA in parallel with the filter.

Dual Digital Envelopes

ENV A is a versatile east coast style ADSR / AHDSR envelope generator with a hold function and dynamic level/time control. Normalled to the VCA to instantly shape your sound.

ENV B is a complex, multimode function generator with a West Coast style AR/ASR/Cycling AR, a beat syncable LFO, Burst generator modes, and the Entropic Sequence Generator (added in 1.3). Normalled to the filter for instant FM without patching.

VCA A and Output Path

VCA A is a linear VCA with auxiliary input.
Global Output Mixer with overdrive circuit and bypassable asymmetric soft clipping.

Expansive Utilities Sections
Cascadia also features a whole host of utilities for getting the most out of your patches.

The Utility Row
Sample and hold circuit with white noise normalled to the input.

Slew/Envelope follower.
Attenuverter/Mixer with multiple outputs.

Triple triangle LFO with rate control, rate input and divided outputs.
Triple buffered multiple.

Precision adder.

Signal inverter.

Bi-polar > Unity level shifter.
Expression level control for modulation the TRS expression input on an FX pedal.

Ring Modulator.
VCA B / LPF (LPG) - Auxiliary VCA and 4-Pole Diode Ladder VCF combination for additional dynamics.

The Top Row
Easy to access Pitch, Gate, and Velocity CV inputs.
Pedal Send and Return FX loop with Wet/Dry control, phase inverter and Line/Pedal level switches.

Output Mixer with Overdrive.
Eurorack Level Main output with level control for interfacing with other modular gear.

The Outside world i MIDI, Pedal and Audio I/O
Cascadia is equipped with a ton of I/O to get it connected to the rest of your gear.

Rear Panel

1/4" Stereo Headphone jack.
1/4" Balanced Output Jack.
1/4" Balanced Input routed to a slider and output on the main panel for patching anywhere into Cascadia.
1/4" TS Pedal FX Send Return and 14" TRS Expression Out.
MIDI DIN In/Out/Thru and USB-MIDI all routed to the MIDI > CV Interface on the top panel.
MIDI > CV Interface
Deeper MIDI configuration is available with the Intelljel Config App. MPE Support has been added in v1.4 and supports the Ableton Live 12 Tuning systems. Dual Mono mode (added in 1.3) allows an additional channel to send it's own Pitch/Gate signal on the CC/MOD outputs. All modes support MIDI Portamento.

MIDI Pitch / Velocity Outputs and Learn Button
MIDI Gate / Trig Outputs
MIDI CC / Mod - Learnable and assignable to any CC or Channel Pressure
MIDI LFO - Multimode LFO synced with MIDI or Tap Clock
MIDI CLK - Dividable MIDI clock with alternate Tap Clock functionality.
Cascadia comes ready to play.
The normalization behind the panel allows for a ton of exploration without ever adding a patch cable; there is years of material to explore in Cascadia and years more when you start patching. Everything you need to get started is included: 14 assorted patch cables, USB-A to USB-C cable, and an international power supply.

Expand and Customize
In addition to additional patch cables, there are great additional options for swapping the wooden cheeks for metal side cheeks or a rackmount kit with a storage tray- great for an effects pedal or patch cables.

Specs

In the Box: Cascadia Semi-modular Synthesizer
14 Patch cables - 4×10cm, 4×15cm, 4×30cm, 2×45cm
USB-C to A cable
Intellijel cable tie
15V/1.2A AC Adaptor (Euro/American prongs included)

Height: 66mm (from rubber foot to top of knobs)
Width: 348mm (including wood end cheeks)
Depth: 246mm (front to rear jacks).
Power: 15V DC/1.0 A (minimum), centre-pin-positive.

Notes: This is a special one. Seven-voice, four-part multitimbral analogue goodness from this boutique Argentinian brand. Stunning sound and depth, combining vintage fatness with contemporary precision.

Supplier's Notes:
The GS e7 is a subtractive synthesis polyphonic analogue synthesizer. The sound generation is carried out in a total analogue way. Each voice has two voltage controlled oscillators (VCO), a noise source, a mixer, a voltage controlled filter (VCF) and a voltage controlled amplifier (VCA). The control signals are digitally generated by a microcontroller, which is capable of processing three low frequency oscillators (LFO) and two envelopes (EG) of the ADSR type. In addition, it incorporates an effects processor with chorus and delay.

The GS e7 interface was designed to be simple and intuitive.

It also has MIDI connections, USB, balanced stereo audio outputs, headphone output and CV inputs.

*** Please note: This synthesiser comes with a US type A mains lead with UK plug adapter. ***

Specs

Polyphony: 7
Multitimbral: 4 parts
Oscillators: 2 voltage controlled analog oscillators (VCO) with sub-oscillators. Hard sync.
Oscillator Waveforms: Triangular, Saw-Tri, Sawtooth, Pulse with PWM. It is possible to mix the pulse with the other waveforms.
Filter (VCF): 24dB / Oct low pass filter (4 poles) with resonance control.
Envelopes: 2 (Attack, Decay, Sustain, Release), Velocity to Attack
LFO: 3
LFO waveforms: Triangular, Ascending ramp, Descending ramp, Square, Sample and Hold
Effects: Chorus, Delay
Presets: 512 programmes, 128 multi
Conennections: MIDI IN, MIDI OUT, MIDI Thru, USB, Pitch CV, Cutoff CV, Gain CV, Ext input, Audio Out (L/Mono, R, 1/4" TRS balanced), Headphones
Power supply: DC 12V 3A
Dimensions: 520mm x 190mm x 108mm
Dimensions (with packaging): 620mm x 290mm x 230mm
Weight: 4.6 kg (estimated)

Notes: This is a special one. Seven-voice, four-part multitimbral analogue goodness from this boutique Argentinian brand. Stunning sound and depth, combining vintage fatness with contemporary precision.

Supplier's Notes:
The GS e7 is a subtractive synthesis polyphonic analogue synthesizer. The sound generation is carried out in a total analogue way. Each voice has two voltage controlled oscillators (VCO), a noise source, a mixer, a voltage controlled filter (VCF) and a voltage controlled amplifier (VCA). The control signals are digitally generated by a microcontroller, which is capable of processing three low frequency oscillators (LFO) and two envelopes (EG) of the ADSR type. In addition, it incorporates an effects processor with chorus and delay.

The GS e7 interface was designed to be simple and intuitive.

It also has MIDI connections, USB, balanced stereo audio outputs, headphone output and CV inputs.

*** Please note: This synthesiser comes with a US type A mains lead with UK plug adapter. ***

Signal path

The signal path is completely analog, featuring two VCO per voice, a white noise source, a mixer, a 4-pole low pass VCF and a VCA. The control voltages are digitally generated, including 3 LFO, 2 ADSR-type envelope generators. Finally, it has a stereo digital effects processor with Delay and Chorus. LFO 1, LFO2 and the delay can be synced with the MIDI clock using a user selectable subdivision.

Oscillators

It features two VCO plus sub oscillator per voice. Each oscillator has 3 different waveforms: triangle, sawtooth and saw-tri (triangle+sawtooth). There is a fine-tuning adjustment and a transpose option, allowing tune adjustment up to +/- 2 octaves. Tuning can also be modulated with any of the three LFOs and EG1

Furthermore, each oscillator has a pulse wave that can be turned on or off, which is mixed with the other waveforms. Its pulse width can be modulated with LFO1 and/or EG1.

Oscillators can be hard synced, with oscillator 1 being the master and oscillator 2 the slave.

The autotuning algorithm takes about 2 seconds to complete. All the voices are tuned in parallel, making a lot faster than usual.

Mixer

The mixer can control the levels and mix the two oscillators, the suboscillators and the white noise or the external input (when the external input is connected, the white noise is disabled).

Filter

The filter is a 4-pole ladder-type low-pass filter with resonance control. It can be modulated with EG1, this modulation an also be affected by velocity. It can also be modulated with any of the 3 LFOs. On the other hand, it features keyboard tracking and it can be controlled by the modulation wheel or aftertouch.

Chorus

There are two types of chorus available: basic and ensemble. The Basic algorithm is subtle and allows you to add some spatiality tothe resulting sound, while the Ensemble algorithm adds a different dimension to the sound, simulating a string or vocal ensemble. The Basic algorithm uses two delay lines, while the Ensemble uses 4 delay lines. Each delay line has its own internal LFO. There are controls for rate, depth and mix.

Delay

The delay can be a stereo delay or a ping pong delay, with its maximum delay time being as long as 1.35s. It is possible to sync the delay to the MIDI clock too. If the delay is synced, the delay time knob controls the time division instead of the delay time. There are controls for the feedback and mix too.

LFOs

There are three LFOs available. LFO 1 and 2 have 5 waveshapes: triangle, ramp up, ramp down, square and random with sample and hold. LFO 3 has the first 4 waveforms and is activated with the modulation wheel and/or aftertouch.
LFO frequencies go from 0.1Hz to 100Hz. Additionally, LFO 1 and 2 have different modes:

Monophonic: The LFO is in phase for all of the voices.

Polyphonic: The LFO is generated to a slightly different frequency for all of the keys pressed. This allows an interaction of the phases, generating more complex modulations.

Keyboard Tracking (KB Tracking): The LFO frequency varies according to the note played following the chromatic scale.

Keyboard Sync (KB Sync): The LFO is restarted when a key is pressed. Each voice has its independent LFO.

Clock Sync: The frequency of the LFO is synced to the MIDI clock signal. The e7 automatically detects the BPM of the clock signal. It can be configured to generate different rhythmic figures.

Keyboard + Clock Sync: The LFO frequency will be a sub-division of the MIDI clock signal. Also, the LFO will be restarted each time a key is pressed.

Envelope generators

There are two ADSR-type envelope generators. There are controls for attack, decay, sustain and release. Attack and release can be modified by velocity and the envelope times have keyboard tracking.

Stereo

By default, the voices have a stereo panning from left to right. By adjusting the stereo spread, it is possible to set all voices to the center or set them from right to left. There is also a stereo motion option that allows this stereo spread to be adjusted by an LFO.

Presets

The synth can store up to 640 presets, 128 of them being multitimbral presets.

Multitimbral

The synth can have up to 4 multitimbral parts. Each part has its complete sound configuration, assignable MIDI channel, keyboard zone, velocity zone, transpose setting and MIDI filter. Additionally, each part can have different voice assignments and/or share some voices.
MIDI Polyphonic expression

MIDI Polyphonic expression is supported by the GS-e7. It was tested using GeoShred, allowing independent pitch control and cutoff for each voice.


Specs

Polyphony: 7
Multitimbral: 4 parts
Oscillators: 2 voltage controlled analog oscillators (VCO) with sub-oscillators. Hard sync.
Oscillator Waveforms: Triangular, Saw-Tri, Sawtooth, Pulse with PWM. It is possible to mix the pulse with the other waveforms.
Filter (VCF): 24dB / Oct low pass filter (4 poles) with resonance control.
Envelopes: 2 (Attack, Decay, Sustain, Release), Velocity to Attack
LFO: 3
LFO waveforms: Triangular, Ascending ramp, Descending ramp, Square, Sample and Hold
Effects: Chorus, Delay
Presets: 512 programmes, 128 multi
Conennections: MIDI IN, MIDI OUT, MIDI Thru, USB, Pitch CV, Cutoff CV, Gain CV, Ext input, Audio Out (L/Mono, R, 1/4" TRS balanced), Headphones
Power supply: DC 12V 3A
Dimensions: 520mm x 190mm x 108mm
Dimensions (with packaging): 620mm x 290mm x 230mm
Weight: 4.6 kg (estimated)

Notes: Blue version of the Bree6, GS Music's fully analogue six-voice synth module. Huge sonic power from the classic single-oscillator design, brought up to date with modern touches like balanced stereo outputs and USB control.

Supplier's Notes:
The Bree6 is a polyphonic analog synthesizer that features a fully analog sound generation. It offers six voices of polyphony, each equipped with a single voltagecontrolled oscillator (VCO), and a sub oscillator. The signal path includes a mixer, a 4-pole low-pass voltage-controlled ladder filter (VCF), and a voltage-controlled amplifier (VCA). The control signals are digitally generated, incorporating one low-frequency oscillator (LFO) and two ADSR-type envelope generators. Additionally, the Bree6 integrates an effects processor with chorus and delay.


The Bree6 interface is engineered for straightforward and intuitive use, featuring one knob per function and ensuring ease of access to its robust features, including MIDI connections, USB, balanced stereo audio outputs, headphone output, and CV inputs.

The signal path in the Bree6 is entirely analog, including a single VCO per voice, a sub oscillator, a mixer, a 4-pole low-pass ladder VCF, and a VCA. The control voltages are digitally generated, comprising one LFO and two ADSR-type envelope generators. It also features a stereo digital effects processor with Delay and Chorus.

The Bree6 features a single VCO plus a sub oscillator per voice. The oscillator includes sawtooth and pulse waveforms, with pulse width modulation control that can be modulated by the LFO. The oscillator tuning can be adjusted, and modulation can be applied from the LFO. The sub oscillator generates a square wave one octave below the main oscillator.

The Bree6's filter is a 4-pole ladder-type low-pass filter with resonance control. It can be modulated by EG1, with velocity affecting the modulation depth, and can also be modulated by the LFO. It can also be controlled by the modulation wheel and aftertouch.

The synthesizer offers a stereo ensemble type chorus effect. It simulates a string or vocal ensemble using multiple delay lines modulated by their dedicated LFOs. The stereo delay can reach a maximum delay time of up to 1 second.

The Bree6 contains one LFO with selectable waveforms (triangle, ramp up, ramp down, square, and random with sample and hold). The LFO's frequency can be set from 0.1Hz to 100Hz, and modulation can be applied to the VCO, VCF, and VCA.

There are two ADSR-type envelope generators in the Bree6, designed for precise control over the dynamics of both the filter and the amplifier.

The synthesizer supports MIDI Polyphonic Expression (MPE), facilitating detailed performance dynamics when used with compatible MPE controllers. The Bree6 has been carefully tested with Osmose, Linnstrument and Geoshred.

Notes: GS Music's fully analogue six-voice synth module. Huge sonic power from the classic single-oscillator design, brought up to date with modern touches like balanced stereo outputs and USB control. Also available in blue.

Supplier's Notes:
The JHS Pedals 3 SerieThe Bree6 is a polyphonic analog synthesizer that features a fully analog sound generation. It offers six voices of polyphony, each equipped with a single voltage controlled oscillator (VCO), and a sub oscillator. The signal path includes a mixer, a 4-pole low-pass voltage-controlled ladder filter (VCF), and a voltage-controlled amplifier (VCA). The control signals are digitally generated, incorporating one low-frequency oscillator (LFO) and two ADSR-type envelope generators. Additionally, the Bree6 integrates an effects processor with chorus and delay.

The Bree6 interface is engineered for straightforward and intuitive use, featuring one knob per function and ensuring ease of access to its robust features, including MIDI connections, USB, balanced stereo audio outputs, headphone output, and CV inputs.

The signal path in the Bree6 is entirely analog, including a single VCO per voice, a sub oscillator, a mixer, a 4-pole low-pass ladder VCF, and a VCA. The control voltages are digitally generated, comprising one LFO and two ADSR-type envelope generators. It also features a stereo digital effects processor with Delay and Chorus.

The Bree6 features a single VCO plus a sub oscillator per voice. The oscillator includes sawtooth and pulse waveforms, with pulse width modulation control that can be modulated by the LFO. The oscillator tuning can be adjusted, and modulation can be applied from the LFO. The sub oscillator generates a square wave one octave below the main oscillator.

The Bree6's filter is a 4-pole ladder-type low-pass filter with resonance control. It can be modulated by EG1, with velocity affecting the modulation depth, and can also be modulated by the LFO. It can also be controlled by the modulation wheel and aftertouch.

The synthesizer offers a stereo ensemble type chorus effect. It simulates a string or vocal ensemble using multiple delay lines modulated by their dedicated LFOs. The stereo delay can reach a maximum delay time of up to 1 second.

The Bree6 contains one LFO with selectable waveforms (triangle, ramp up, ramp down, square, and random with sample and hold). The LFO's frequency can be set from 0.1Hz to 100Hz, and modulation can be applied to the VCO, VCF, and VCA.

There are two ADSR-type envelope generators in the Bree6, designed for precise control over the dynamics of both the filter and the amplifier.

The synthesizer supports MIDI Polyphonic Expression (MPE), facilitating detailed performance dynamics when used with compatible MPE controllers. The Bree6 has been carefully tested with Osmose, Linnstrument and Geoshred.

Notes: Updated version of Erica's superb EMS-inspired synth, featuring a powerful dual oscillator synth architecture, piano roll sequencer, modulation matrix and recordable joystick.

Supplier's Notes:
Based on lessons learned from the SYNTRX, Erica Synths decided to create an instrument that would integrate even deeper into contemporary electronic and experimental music setups and cover sonic territory from daunting drones to powerful basslines and glitched noisescapes - the SYNTRX II is a new dark horse for experimental sonic rides.

The SYNTRX II is the culmination of Erica Synths' analogue sound design circuits - two perfectly stable main oscillators with waveshapers, a modulation oscillator with 1V/oct tracking, a versatile multimode filter, supercharged external instrument inputs with an envelope follower, a unique, great-sounding ring modulator, a recordable joystick, built-in piano roll sequencer and stepped modulation sources, all arranged around Erica Synths' signature matrix mixer and topped off with powerful FX on their new DSP platform.

"The SYNTRX 2 is awesome, a very different instrument from V1. My first synths were the VCS3 and the AKS and are still among my favorites today. The Syntrx 2 is pushing the boundaries of possibilities & experimentations much beyond the original analogue version. The Syntrx 2 is an instant classic". - Jean Michel Jarre

Features

Two perfectly stable main oscillators with CV-controlled waveforms
Modulation oscillator with variable waveforms
Highpass and Lowpass filters in series
Free running or gate synced sample and hold circuit
Multi-colour noise generator
DC coupled instrument inputs with signal inversion and envelope follower
Ring modulator of unique design
Looping trapezoid envelope generator and VCA
Two output VCAs
Signal meter with a dedicated audio/CV output
FX section with great sounding Delay and Reverb developed in collaboration with 112db.com
Recordable Joystick
Analogue patch matrix with 3 attenuation levels in each patch point
254 patch memory
Piano roll sequencer and two stepper modulation sources
DIN5 MIDI Input and MIDI Thru
Two assignable outputs
Headphone output
Dimensions: 309mm x 457mm x 115mm (with the joystick in centre position)
Weight: 3.9 kg

Notes: A collaborative effort between the techno icon and one of the best synth brands around, the Bullfrog is designed to encourage newcomers to analogue synths while secretly packing killer sound and some innovative features.

Supplier's Notes:
Introducing Erica Synths X Richie Hawtin Bullfrog

Learn. Produce. Perform

Created by Erica Synths & Richie Hawtin, Bullfrog is an educational electronic music instrument designed to captivate and inspire both youth and professionals alike. Bullfrog invites you to unlock musicality while combining the thrill of electronic music production with a comprehensive learning experience.
Bullfrog is a classical subtractive synthesiser - it consists of several "modules" for sound generation - VCO, NOISE GENERATOR - and treatment - VCF, VCA/DELAY, as well as "modules" that generate control and modulation signals to control them - ENVELOPE GENERATORS and SAMPLE & HOLD. The Bullfrog will not make the sound on its own unless it is patched - using eurorack patch cables to interconnect the "modules" or by inserting voice cards that create internal connections between the "modules" in a specific way and add extra functionality, like sampler/looper, sequencer, groovebox, etc. This approach better helps to understand functionality of a subtractive synthesizer and the principles of sound design with instruments like these.

In order to provide a well rounded understanding of the functionality of this synthesizer and sound synthesis in general, a comprehensive user manual is created to accompany the learning process.

Electronic music with its rich traditions and innate sense of exploration at core is ever popular, with artists and fans stretching around the globe. For me, one of the most exciting parts of creating electronic music is the playful exploration that leads one deep into their own imagination. Whether the intention to create completely imagined or real-life inspired sounds, the route one takes to create is always personal and often surprising. It is within these experiments where the beauty of synthesis really comes alive and which often unlocks a new sense of creativity and purpose.

Whether someone's experience with Bullfrog points them down a career in electronic music or not, the goal is to both nurture the love for electronically produced sounds and promote the accessibility of learning and understanding the basics of sound synthesis.

Erica Synths believe that the hands-on approach and problem solving that is innate to synthesis on a semi-modular synth like the Bullfrog, contains life lessons that go beyond what we can hear.

Bullfrog encapsulates the foundations of synthesis and is built with an immediate, intuitive design and a unique expandable architecture that grows and expands together with the user's imagination. This instrument feels at home anywhere - as an educational tool in music and physics classes, as an addition to your basement studio or even as a tool for performance on a stage.

What's included:

BULLFROG synthesizer
Universal 12VDC wall wart adapter
User manual
10 patch notes stencils
10 patch cables
3 pre-patched voice cards
3 DIY voice cards with adjustable offset
Delay effect with adjustable delay time and feedback amount
Two looping attack-sustain-release envelope generators (EG)
Sample & Hold circuit with an individual clock
Manual gate button
Voicecard slot
Built in speaker
DIN5 MIDI input
USB connector

What's included

BULLFROG synthesizer
Universal 12VDC wall wart adapter
User manual
10 patch notes stencils
10 patch cables
3 pre-patched voice cards
3 DIY voice cards

Notes: SOLAR 42F is a unique experimental electro-music instrument, an analogue microtonal ambient drone machine. It will inspire you to find a new and spontaneous approach to composing music. It gives you the ability to create a multi-layered, massive sound. The instrument is oriented for live performances, creating film soundtracks, theatre soundtracks, atmospheric sounds, microtonal and background music.

It is an improved version of the older SOLAR 50 model. The instrument was inspired by early electronic musical instruments of the 1920s and 1950s, notably Leo Theremin's "Harmonium" instrument, as well as science fiction film soundtracks.

The new version of the Solar 42F has added a LIN/EXP CV switch, sub oscillators in volt octave voices and a band pass and stereo distortion mode to the filter. Other quality of life improvements include modified graphics - inputs have been labeled in black and outputs in red for convenience - bypasses for each channel of the effector and a LED indication in the joystick unit.

Notes: Reissued version of one of Dreadbox's back catalogue synths, the Erebus is a paraphonic design with two VCOs, a characterful low-pass filter, built-in delay and updated snappy envelopes.

Supplier's Notes:
Dreadbox's most unique sounding analogue synthesizer is finally back, warmer and snappier than ever!

All you synth lovers, the time has come to dive into the Erebus...

All Analogue Paraphonic Synthesizer
Faithful Reproduction of the Erebus V1
2 Oscillators with 2 Waveforms each
Separate Glide controls and Hard Sync function
2-pole Low Pass pre-fed Filter
1 ADSR envelope and a AR Amp Envelope
Snappier than the V1

OTA VCA
Lo-Fi Delay effect
Wide Range LFO
15 patch points for an astonishing and spectacular modular experience
Compact, USB powered, Eurorack Format (42HP)

Ethereal & Dreamy

Warm sounding Oscillators
Classic Dreadbox Filter
Snappy Envelope Generators
Lo-Fi Delay effect to expand your sound
CV outputs: Envelope, LFO, Mod Wheel, Gate, CV1, CV2
CV inputs: Osc1, Osc2, Echo, Cutoff, CV, Gate, LFO Rate, PW, VCA

Specifications & Connections

USB powered (1.5 Watts)
50 Playing hours with 20,000mA portable power bank
MIDI IN via DIN5
14 MONO TS Jack Out

Dimensions: 21.5 x 13 x 6.5 cm
Weight: 1 kg

Requirements:

USB-A Adapter (5v) with 1000mA or more
MIDI device or keyboard that is equipped with DIN5 midi output
Monitor, Amp or Headphones

Included in the box:

Erebus Eurorack module
42 HP case
1x DIN5 to 3.5mm adapter
1x Ribbon cable

Notes: Dreadbox go back to their roots with this reissued analogue beast. Simple but effective single-oscillator monophonic design with a three-pole resonant filter and analogue distortion.

Supplier's Notes:
Dreadbox's highly anticipated Bass Synthesizer is finally back.

Its Deep and Dark sound is here to haunt you ...

All Analogue Bass Synthesizer
Faithful Reproduction of the 2016 Hades
1 Oscillators with 2 Sub Octaves and 2 Waveforms with PW control
3-pole Resonating Low Pass Filter
1 AD/RS envelope and a AR Amp Envelope

OTA VCA
OTA Distortion
Wide Range Triangle LFO
11 patch points for an astonishing spectacular modular experience
Compact, USB powered, Eurorack Format (42HP)

Monophonic Epicness
Super Fat Oscillator
2x Sub Octaves for extra headroom
Special Internal Bass Boost Circuit
Warm Filter
Drive effect for aggressive sounds
CV outputs: Envelope, LFO, Mod Wheel, 1v/oct
CV inputs: PW, Cutoff, VCA, CV, Gate

Specifications & Connections

USB powered (1.5 Watts)
50 Playing hours with 20,000mA portable power bank
MIDI IN via DIN5
14 MONO TS Jack Out

Dimensions: 21.5 x 13 x 6.5 cm
Weight: 0.9 kg

Requirements

USB-A Adapter (5v) with 1000mA or more
MIDI device or keyboard that is equipped with DIN5 midi output
Monitor, Amp or Headphones

Included in the box

Hades Eurorack module
42 HP case
1x DIN5 to 3.5mm adapter (specs as found at midi.org)
1x Ribbon cable

Notes: Boutique analogue goodness inspired by chthonic demi-goddesses. Obviously. Six-voice synth engine with fully analogue signal path plus digital reverb. Compact and powerful with a lush, distinctive sound.

Supplier's Notes:
Nymph(e)s are chthonic demi-goddesses who not only personify nature but are regularly associated with the wild.

They inhabit rivers, springs, woods, groves, fields, caves, mountains and valleys.

They preside over fountains, sacred wells and fresh water.

The Polyphonic Synthesizer N Y M P H E S was developed during the obscure pandemic times and we really hope that it will bring a pinch of happiness on your face. Dreadbox have attempted to condense an ambitious idea in a small and compact box, without any compromise in the quality of the final instrument.
The result is stunning and ethereal ...

Features per Voice

1x VCO with Wave Forming
1x Sub Oscillator
Noise generator
1x LFO per voice with: Key track, Fade In and Fade out, 5 waveforms and wide frequency (into the FM range)
2x Envelope Generators
24dB/octave Low Pass Resonant Filter with accurate tracking
6dB/octave High Pass Non-Resonant Filter

Common

Voice Features

1x common LFO (named LFO2) that can target any and multiple parameters with different amount to each one at the same time , with: Key track, Fade In and Fade out, 5 waveforms and Wide Frequency (into the FM range)
7x active Chords that you can edit, modulate and store on each preset
Modulation wheel, Velocity and Aftertouch (monophonic) can target any and multiple parameters with different amount to each one at the same time

Specifications & Connections:

USB powered (1.5 Watts)
50 Playing hours with 20,000mA portable power bank
MIDI IN via USB or DIN5
1/4 MONO TS Jack Out
1/8 Headphones Out

Dimensions: 24 x 12.5 x 3.8 cm
Weight: 0.85 kg

Requirements

USB-A Adapter (5v) with 1000mA or more
MIDI device or keyboard that is equipped with either USB HOST or DIN5 midi output
Monitor, Amp or Headphones

Included in the box

USB cable (A to B)
DIN5 to 3.5mm adapter (specs as found at midi.org)
Quick Start Guide
Menu Map

IMPORTANT NOTE:
True power consumption is at 310mA. Some computers cannot deliver that much current. Please make sure that your device has sufficient current for Nymphes before connecting it- otherwise if you want to connect it with a computer, you will need a USB splitter or a powered USB hub.
When using a USB adapter, always make sure it can deliver 1000mA or more.

Notes: A standalone instrument to get you into the world of analogue synthesis. Hand-built, simple to use and capable of some excellent drones and tones. Just add headphones.

Supplier's Notes:
OVUM is where you start: a standalone all-analogue tool for exploratory sound synthesis - all you need to start creating is headphones.

OVUM is designed for exploring pure tones, drones, and microtonal sound textures. Five independently controlled triangle-core oscillators give you five lush voices to layer and evolve. Each voice has a separate control for volume, pitch, and tone, and can be switched between a bright square wave and a crisp triangle wave.

OVUM is hand-built from 100% analogue circuitry, with no digital components, screens, quantization, or key-combinations to memorize - everything is immediate and at your fingertips.

OVUM is enclosed in a beautiful and sturdy wood and aluminum case that feels as good in your hands as it looks on your tabletop.

OVUM has a USB-C port for power, and a single 3.5mm audio output jack for headphones or line-out to connect to an amplifier, audio interface, or effects.

To reduce waste, by default OVUM comes with just the instrument and a USB to USB-C power cable. If you don't have a spare USB power supply, they can be added to your purchase at checkout. OVUM is portable, but does not contain a battery. It can be powered by any USB powerbank.

Notes: Amazing value from this little Eurorack-compatible analogue synth. Loosely Moog-inspired semi-modular East Coast subtractive design with MIDI control and great sound.

Supplier's Notes:
East Beast

Fully analogue East Coast style semi-modular synthesizer

What's the first thing you think of when you hear the word "synthesiser"? Close your eyes and think about.

Anyway, for a lot of people, the word synthesiser invokes visions of big filter cutoff knobs, envelope generators, and importantly, big fat-sounding voltage-controlled oscillators. These are the hallmarks of East Coast-style synthesis.

East Beast is a fresh take on these old-school concepts with a few beastly twists thrown in here and there.

Furthermore, you can pop East Beast out of its included enclosure and it transforms right into a 40HP eurorack module
East Beast's oscillator, designed in partnership with Pittsburgh Modular Synthesizers, is a part of their 5th generation of analogue oscillators stemming from a super-serious 10 years of continued research into analogue oscillator development.

Its circuitry is not a clone or based on any outside designs. It is made with 100% modern components. This keeps it very stable, and giving it a super rich, and unique sound.

Most of the filters you are used to hearing are transistor ladder filters or copies of transistor ladder filters. East Beast's filter is not one of those. Pittsburgh's whole goal of making this filter for East Beast was to create a filter that's creamy smooth with no dead spots, a very common phenomenon in all filters, but check it out. This one's got no dead spots. From nasally to biting and elsewhere, it's all one large sweet spot.

East Beast's filter is a multi-mode filter, meaning it can be used as a low pass filter, high pass filter, bandpass filter, or a combination of the three for an even wider sonic palate.
Shape the beast in your own image
To further sculpt the sounds Cre8audio has included an envelope generator & LFO. The custom envelope circuit creates a snappy, percussive attack for expressive performance. The dual range LFO opens up a wide range of LFO and audio rate modulation possibilities.

Get patched.
Semi-modular means that the East Beast will work without any patch cables or anything. But what fun is that? Who doesn't want to have their own personal spaghetti mess of cables sticking out of their synthesizer to get wacky with?
East Beast has basically 9 different patchable modules (Oscillator, filter, envelope, VCA, LFO, multi-mod tool, sequencer, MIDI to CV converter, and button keyboard) with a whopping 18 Eurorack compatible patch points to plug into itself and your other gear. All for your patching pleasure.

As well as this, East Beast has MIDI in and a fancy MIDI thru so you can chain multiple MIDI monstrosities together- you can plug in a MIDI controller into East Beast and do as you wish.

But wait, there's more! East Beast includes quite a few additional performance features. You can dive in and dive in with its built-in tap tempo clock, arpeggiator, and sequencer. There's a lot of opportunities to inject in some randomness too.

Specifications for when used as a eurorack module

Width when used as a module = 40hp
Depth when used as a module = 25mm
213mA power draw when running +12V rail
151mA power draw when running -12V

Input voltage range of oscillator = 0-10V

Included in the box - 1x East Beast, 1x East Beast wall-wart power supply, 5x Amazing Nazca Noodles Patch Cables, 1x 3.5mm to 5 pin MIDI Din pigtail, and love (love's presence likely, but not guaranteed)

Notes: Latest incarnation of Buchla's legendary modular synth. Massively creative with incredible sound and history stretching all the way back to the 1960s.

Supplier notes:
The evolution of the legendary modular analog synthesizer by Don Buchla. The Buchla Easel Command is the newly updated 208C in a standalone desktop form with MIDI and CV control.

Buchla's own Joel Davel led the charge to create a new version of the legendary Music Easel instrument with more modular flexibility and independence, while also providing the means to easily interface with more devices, such as the various DAWs like Ableton and MIDI controllers, including the very expressive Sensel Morph. It's still fully analog in its default configuration and provides the unique and exquisite Buchla experience with greater functionality at a lower cost.

Notes: Celebrating the 50th anniversary of this truly iconic synth, the 'modern' take on the classic Buchla Music Easel doesn't mess with a winning formula, paring the 208C sound source with 218e touch-sensitive keyboard.

Supplier's Notes:
The Buchla Music Easel was one of the first truly portable electronic music instruments. Fifty years ago, in 1973, only a few dozen were made. Unlike many iconic technologies, the influence was not grown through force of scale, but rather the force of the ideas. The Music Easel made available virtually every musical dimension: timbre, melody, rhythm, and time; how these dimensions intersected was no longer the court of acoustics and material, but signals and voltage. The 208 Stored Program Sound Source engendered "a new functional organization [with a] particularly rapid system of patching and program storage via plug-in cards."

Taking cues from the then-recent discipline of cybernetics, the 218 touch plate was for "real-time communication" to help realize the "potential vocabulary" of the Easel, rather than exploiting existing modes of musical virtuosity. The Stored Program Cards ensured rapid repeatability and repertoire on its own terms. The battery terminals made sure the music was as portable as any acoustic instrument. And the name let you know it was designed for art rather than science.

Buchla is ecstatic to revive the Music Easel for its third run in 50 years. Buchla first released the updated 208 Stored Program Sound Source, dubbed the Easel Command, with expanded MIDI and USB capability. Next came the update of the Easel Program Manager - a complete kit for storing and recalling sounds sources, even more rapidly than imagined in 1973. The new 218 Touch Activated Voltage Source provides the optimal input facility, as originally envisioned. It is now all together in a rugged case and the advanced EMBIO module that unifies all the audio and control inputs and outputs for integration with the rest of your musical world.

More than a retro novelty, the Music Easel still speaks to a future we strive for. A technology that invites conversation, not chats, and controls that engage expression, not work. There are many new worlds to explore in this instrument created at the crossroads of the jazz and computer ages. Designed as "an integrated assemblage of functions", rather than a collection of modules, the Music Easel's colour coding, comfortable access to controls, and solid patch connections allow for satisfying sessions of sonic discovery.

The Music Easel is available for pre-order starting June 16 at Buchla.com and your favourite Buchla Dealer. Delivery of the Music Easel (modern) is expected fall 2023.

Stored Program Sound Source Model 208C

The sound source of the Music Easel is the 208C, which includes a complex oscillator and a modulation oscillator (which can also serve as another voice), each with independent switchable waveforms, as well as a noise generator, allowing for rich and intricate sound design. The 208C also features a five-stage sequencer, envelope generator, pulser and modulation source - with switchable triggers - allowing for complex patterns and evolving textures. The dual low pass gate provides dynamic control over the tone and amplitude of the sound, as well as natural-sounding decay and sustain. The 208C has a number of modulation sources, including a random voltage generator, the envelope generator, modulation oscillator, and an envelope detector. These sources can be used to modulate various parameters via the extensive patchfield - creating movement, texture, and complexity. The 208C also includes a mixer section with spring reverb.

Touch Activated Voltage Source Model 218e (v3)

The first design appeared in the 1973 release of the Buchla Music Easel and named for the spacecraft that delivered astronauts to the moon. Providing the familiar piano key layout for this early mobile music machine, the additional controls and capabilities were an interface for exploring uncharted musical territory. With the new version 3, it's been elevated with a new foundation of stable, modern electronics with incredible sensitivity and accuracy - the lightest touch will produce triggers and control voltages. The adjustable sensor has the dynamic range and durability to handle your playing. The new texture not only improves the sensing, but provides a satisfying tactile experience. As always, pressure is an expressive output, adding an extra dimension to the control. MIDI outputs velocity and polyphony, as well as channel pressure, making the 218e a uniquely expressive controller. The 218e includes portamento and an arpeggiator, which can be driven by external inputs and are allowed to interact with the automated notes to make patterns more complex. Additional controls allow you to blend different patterns and randomness to easily change from the expected to the surprising. The classic preset voltage knobs offer several possible ways to shift your sounds into new territory. Not only can the knobs be used for quick access to voltages for your patch, they can control arpeggiation modes and octave shifting. Pads output pulses for additional control. The 218e also gives you a unique interface to playing your existing MIDI gear and soft synths. Each touch outputs note name, channel pressure, and velocity for every note, along with sustain controls from a pedal. Polyphonic MIDI mode lets you play chords. The touchstrip can act as a pitch bend control, or as a mod wheel for additional expressive control. Easily configured using the front panel controls, you can send notes and controls on any MIDI channel.

Electric Music Box Input/Output (EMBIO)

Maintaining the spirit, sound, and process from the original, the new Music Easel adds a variety of new features. Buchla's latest renditions of the Stored Program Sound Source and Touch Activated Voltage Source are tied together with the Electric Music Box Input/Output (EMBIO) module. This of course provides MIDI out (mini jack and USB) and CV out from the 218, MIDI in to the 208, and the audio out from the 208C. Additional creative control comes from the Audio Mixer, for integration with other Buchla modules and systems, and the CV conditioners and controls. The slew control can turn your sequencer into a wavy modulator, or soften up a square LFO. The attenuator and crossfader gives you the opportunity to find new levels and combinations of voltages from existing ones. The pulse converter offers new rhythms to trigger. And a simple LFO provides another valuable modulator when you just can't quite let yourself flip that Mod Osc switch from "high" to "low."

Notes: Celebrating the 50th anniversary of this truly iconic synth, the 'modern' take on the classic Buchla Music Easel doesn't mess with a winning formula, paring the 208C sound source with 218e touch-sensitive keyboard.

Supplier's Notes:
The Buchla Music Easel was one of the first truly portable electronic music instruments. Fifty years ago, in 1973, only a few dozen were made. Unlike many iconic technologies, the influence was not grown through force of scale, but rather the force of the ideas. The Music Easel made available virtually every musical dimension: timbre, melody, rhythm, and time; how these dimensions intersected was no longer the court of acoustics and material, but signals and voltage. The 208 Stored Program Sound Source engendered "a new functional organization [with a] particularly rapid system of patching and program storage via plug-in cards."

Taking cues from the then-recent discipline of cybernetics, the 218 touch plate was for "real-time communication" to help realize the "potential vocabulary" of the Easel, rather than exploiting existing modes of musical virtuosity. The Stored Program Cards ensured rapid repeatability and repertoire on its own terms. The battery terminals made sure the music was as portable as any acoustic instrument. And the name let you know it was designed for art rather than science.

Buchla is ecstatic to revive the Music Easel for its third run in 50 years. Buchla first released the updated 208 Stored Program Sound Source, dubbed the Easel Command, with expanded MIDI and USB capability. Next came the update of the Easel Program Manager - a complete kit for storing and recalling sounds sources, even more rapidly than imagined in 1973. The new 218 Touch Activated Voltage Source provides the optimal input facility, as originally envisioned. It is now all together in a rugged case and the advanced EMBIO module that unifies all the audio and control inputs and outputs for integration with the rest of your musical world.

More than a retro novelty, the Music Easel still speaks to a future we strive for. A technology that invites conversation, not chats, and controls that engage expression, not work. There are many new worlds to explore in this instrument created at the crossroads of the jazz and computer ages. Designed as "an integrated assemblage of functions", rather than a collection of modules, the Music Easel's colour coding, comfortable access to controls, and solid patch connections allow for satisfying sessions of sonic discovery.

The Music Easel (retro) is available for pre-order starting in June 16 at Buchla.com and your favorite Buchla Dealer with delivery expected in winter 2023.

Stored Program Sound Source Model 208C

The sound source of the Music Easel is the 208C, which includes a complex oscillator and a modulation oscillator (which can also serve as another voice), each with independent switchable waveforms, as well as a noise generator, allowing for rich and intricate sound design. The 208C also features a five-stage sequencer, envelope generator, pulser and modulation source - with switchable triggers - allowing for complex patterns and evolving textures. The dual low pass gate provides dynamic control over the tone and amplitude of the sound, as well as natural-sounding decay and sustain. The 208C has a number of modulation sources, including a random voltage generator, the envelope generator, modulation oscillator, and an envelope detector. These sources can be used to modulate various parameters via the extensive patchfield - creating movement, texture, and complexity. The 208C also includes a mixer section with spring reverb.

Touch Activated Voltage Source Model 218e (v3)

The first design appeared in the 1973 release of the Buchla Music Easel and named for the spacecraft that delivered astronauts to the moon. Providing the familiar piano key layout for this early mobile music machine, the additional controls and capabilities were an interface for exploring uncharted musical territory. With the new version 3, it's been elevated with a new foundation of stable, modern electronics with incredible sensitivity and accuracy - the lightest touch will produce triggers and control voltages. The adjustable sensor has the dynamic range and durability to handle your playing. The new texture not only improves the sensing, but provides a satisfying tactile experience. As always, pressure is an expressive output, adding an extra dimension to the control. MIDI outputs velocity and polyphony, as well as channel pressure, making the 218e a uniquely expressive controller. The 218e includes portamento and an arpeggiator, which can be driven by external inputs and are allowed to interact with the automated notes to make patterns more complex. Additional controls allow you to blend different patterns and randomness to easily change from the expected to the surprising. The classic preset voltage knobs offer several possible ways to shift your sounds into new territory. Not only can the knobs be used for quick access to voltages for your patch, they can control arpeggiation modes and octave shifting. Pads output pulses for additional control. The 218e also gives you a unique interface to playing your existing MIDI gear and soft synths. Each touch outputs note name, channel pressure, and velocity for every note, along with sustain controls from a pedal. Polyphonic MIDI mode lets you play chords. The touchstrip can act as a pitch bend control, or as a mod wheel for additional expressive control. Easily configured using the front panel controls, you can send notes and controls on any MIDI channel.

Electric Music Box Input/Output (EMBIO)

Maintaining the spirit, sound, and process from the original, the new Music Easel adds a variety of new features. Buchla's latest renditions of the Stored Program Sound Source and Touch Activated Voltage Source are tied together with the Electric Music Box Input/Output (EMBIO) module. This of course provides MIDI out (mini jack and USB) and CV out from the 218, MIDI in to the 208, and the audio out from the 208C. Additional creative control comes from the Audio Mixer, for integration with other Buchla modules and systems, and the CV conditioners and controls. The slew control can turn your sequencer into a wavy modulator, or soften up a square LFO. The attenuator and crossfader gives you the opportunity to find new levels and combinations of voltages from existing ones. The pulse converter offers new rhythms to trigger. And a simple LFO provides another valuable modulator when you just can't quite let yourself flip that Mod Osc switch from "high" to "low."

Notes: Somewhere between an analogue drum synth and a dub siren, the DS71 is a uniquely creative little box. Properly versatile, experimental stuff.

Supplier's Notes:
The DS71 is a synthesizer designed to easily create many different dub siren tones at your fingertips. It combines analog synth voicing circuitry with a powerful digital LFO that allows for quick access to different sounds at the press of a button. Inspired by the classic analog drum-synth modules and re-interpreted as dub siren.

Audio output: impedance balanced 1/4" TRS Jack

Trigger input: impedance balanced 1/4" TRS Jack

DC Input: 12VDC, 500mA, centre positive, 2.1mm x 5,5mm barrel type connector

Dimensions: 145mm x 130mm x 60mm

12VDC 1A power supply included.

Notes: Synth meets sequencer in this limited-edition Noir version of Arturia's excellent MiniBrute. Semi-modular design and extensive patch bay offer a wide variety of sound design options.

Supplier's Notes:
The MiniBrute 2S Noir Edition is a thrilling hybrid synthesizer enhanced for the modern musician. Combining raw analog power, an intuitive triple-layered step sequencer, a modular-worthy patch bay, and a stealthy black exterior, MiniBrute 2S Noir delivers the Brute Factor, and then some.

Pure synth power

A powerful standalone instrument, MiniBrute 2S Noir has massive synth potential that's intuitive, accessible, and fun to use. Whether you're a seasoned pro or new to the world of synthesis, you'll find its layout easy to understand, quick to master, and hugely inspiring. Thanks to its analog semi-modular architecture, you have hands-on control of every parameter, so you can sculpt your oscillators, sweep your filters, sync your LFOs, and control your envelopes on the fly to create a sound that's uniquely yours, bound only by your imagination.

Discover the modular world

Open up exciting new possibilities by rerouting MiniBrute 2S' signal with the modular patch bay. Better still, patch it to your existing Eurorack system and explore new connections, then sequence and shape with MiniBrute 2S' myriad of controls. With this synth at your command, your creative workspace will become a experimental sound laboratory.

Step in line

Featuring an awesomely powerful, triple layered step-sequencer, multi-mode arpeggiator, and high-quality performance pads, MiniBrute 2S Noir perfectly suits adventurous electronic musicians who want to take their creations further than ever before.

The Brute Noir Editions

Unique analog instruments, where vintage synthesis and cutting-edge technology collides in the name of creative freedom and controlled sonic chaos, decorated with stealthy black exteriors. These are the Brute Noir Editions, the darker side of analog.

Included Software:
Arturia MIDI Control Center

Notes: One of the best synths money can buy. Hugely expressive PolyBrute engine expands to 12 voices with the same beguiling combination of FullTouch keyboard, Morphee control and ribbon strip. Immense

Supplier's Notes:
Unleashing the full power of PolyBrute

Continuing the legacy of its predecessor as one of the most powerful and expressive analogue synths ever made, PolyBrute 12 goes a step further.

A multi-faceted tool for musical expression, PolyBrute 12 lets you seamlessly evolve and control any parameters while playing. The input-perfect sensitivity of the keyboard, the bi-timbral morphing presets, the multi-axis Morphee controller, the Ribbon controller - all work in perfect harmony so you can breathe vitality and intricate dynamics into your sound.

PolyBrute's in-the-moment sonic display would not be possible without the raw energy of its Brute oscillators and dual enhanced classic filters. This, combined with its intuitive interface, elegant modulation Matrix and advanced software companion make PolyBrute 12 a synth for the ages - a matrimony of Brute force and human touch.

Full touch, full control

Discover a next-generation keybed and new aftertouch modes that bring you into a direct and tactile connection with your sound.

PolyBrute's patented FullTouch keyboard provides the exact position of every key across the entire range of movement. This not only allows for precise and dynamic aftertouch expression but it also puts versatility at PolyBrute's core - allowing you to go from regular playing modes to exceptional aftertouch and envelope control at the touch of a button.

You can also use PolyBrute 12 to control any MPE-compatible VST. If you don't have a MPE compatible DAW, you can still record expressively using MIDI 1.0, although at a lower resolution.

Mono Aftertouch

In this mode, the note is triggered by regular keyboard velocity and the classic aftertouch area corresponds to an assignable aftertouch signal, where all the voices receive the same level and amount of expression. Great for applying a unified modulation effect to a chord or phrase.

Morph between sonic worlds

Seamlessly blend from one patch to another and find that perfect middle ground

Each preset is made up of two sonic states, A & B. A dedicated Morph knob lets you seamlessly explore a continuum of sound between them. This, combined with the Morphee controller and PolyBrute's keyboard, paves the way for endless patch evolution and expressivity.

Analogue heart, seismic sound

PolyBrute's sound begins with two analogue VCOs sharing much of the same sonic architecture that has made the Brute family renowned.

Each oscillator generates sawtooth, triangle and square waves simultaneously, and you can mix between them to shape just the right signal source and timbre.

Dial in VCO 1's Metalizer wavefolding to escalate from pure to punchy. Bring in VCO 2's sub-oscillator to add an extra lower octave and some added rumble.

Dial in edgy FM effects by modulating VCO 1's frequency with VCO 2, or subtly alter a continuous range of harmonics with soft or hard sync.

1 VCF 1 Steiner

A 2-pole 12db/octave Steiner filter design with continuous sweepable slope types, as seen across the Brute range. The addition of the proprietary Brute Factor feedback control lets you add anything from subtle warmth to a electrified growl.

2 VCF 1 Ladder

Inspired by Dr. Bob Moog's legendary 4-pole 24db/octave ladder design. A low-pass classic, with added gain compensation and asymmetrical distortion to add upfront grit to your polyphonic patches.

Modern modulation sources

Modulation has always been essential in animating synth sounds.

PolyBrute weaves a web of envelopes and LFOs that's intricate and unpredictable in equal measure - a dynamic display of sonic motion.

Three Envelope Generators

PolyBrute's VCF and VCA have velocity-sensitive ADSR envelopes hardwired outside the Matrix for instant gratification. The third Envelope Generator features a delay stage (DADSR) and can be assigned to sculpt any Matrix modulation targets. Use the various repeat and loop modes to add complex movement to your patches.

Three Envelope Generators

PolyBrute's VCF and VCA have velocity-sensitive ADSR envelopes hardwired outside the Matrix for instant gratification. The third Envelope Generator features a delay stage (DADSR) and can be assigned to sculpt any Matrix modulation targets. Use the various repeat and loop modes to add complex movement to your patches.

Three LFOs

PolyBrute's three syncable LFOs span an extremely wide range - facilitating anything from beautiful evolving soundscapes to clangorous audio-range modulation. Options for waveshaping, polarity and retriggering let you take your sound way outside the box. Experiment with Matrix routing and tempo/MIDI sync for hyper-rhythmic effects.

Enter the matrix

The flexibility of modular patching combined with digital precision and analogue richness makes for a transcendent polysynth experience.

32 target parameters, 64 connections in total. Rearrange PolyBrute's signal chain with the touch of a single button. Dial in positive or negative amounts, intuitively assign one or more destinations via any relevant controls, instantly route PolyBrute's array of performance controllers and advanced modulation sources to influence just about anything in the instrument's chain - all without a convoluted array of wires.

But the Matrix doesn't just take care of PolyBrute's all-encompassing modulation routing - it's the centrepiece of every aspect of its architecture. In Presets mode, use the Matrix to select any of the 768 patch memory locations. Morph mode accesses advanced morph state editing. Sequencer mode transforms the Matrix into an intuitive visual pattern editor.

Main Features

61-keys with FullTouchr MPE Technology keyboard
Pitch Bend, Mod Wheel, Ribbon controllers
Morphee touch and pressure sensitive 3D controller
Osc and Noise Mixer with Filter routing
12dB/Oct Steiner Parker Filter

Continuous LP>Notch>HP>BP morphing
Cutoff, Resonance, Brute Factor

24dB/Oct Ladder Filter with Distortion
Three Envelopes
Looping capability
Two ADSR
One DADSR
Three stereo digital effects
Modulation FX : Chorus, Phaser, Flanger, Ring Modulation
Delay : 9 algorithms including BBD, Digital delay
Reverb : 9 algorithms including Hall, Plate, Spring, Shimmer
Distortions : Subtle Tape, Classic Distortion, Soft Clip, Worn Out Tape, Germanium, BitCrusher, DownSampler
Arpeggiator, Matrix Arpeggiator, Sequencer
Stereo audio output
2 expression and 1 sustain pedal inputs
Two Analogue VCO's
Saw
Triangle + Metalizer
Square + Pulse Width
Sub
Linear FM
Hard Sync
Noise Generator
Continuous tone from rumble noise to white noise
Three LFOs
LFO1 and LFO2 with waveform selection
LFO3 with waveform shaping using Shape and Symmetry
Rate control & Tempo Sync
Various retrig options
480 presets and 768 preset slots
12x32 Modulation Matrix
Notes, Accent, Slide per step
3 tracks of automation
MIDI and USB I/O + analogue clock I/O

Platform specifications

Windows
Win 10+ (64bit)
4 GB RAM
4 cores CPU, 3.4 GHz (4.0 GHz Turbo-boost)
3GB free hard disk space
OpenGL 2.0 compatible GPU
ARM processors not supported on Windows

Apple
Mac OS 11+
4 GB RAM
4 cores CPU, 3.4 GHz (4.0 GHz Turbo-boost) or M1 CPU
3GB free hard disk space
OpenGL 2.0 compatible GPU

Required configuration
Works in Standalone, VST, AAX, Audio Unit.

Work with ASC
An elegant and simple solution to help you install, activate, and update your Arturia software instruments.

What's in the box

Box content

PolyBrute 12 Unit
Power Cord
User Manual
Registration Card

Instrument dimensions
Size : 38.3 x 17.1 x 6.1 inches (972 x 435 x 156mm)
Weight : 50.7lbs (23kg)

Notes: The ARP 2600 is arguably the most iconic and recognizable synthesizer of all time. Having been used in countless records, film scores, TV shows and game soundtracks since its appearance from the 70's through to today, the ARP 2600's sound remains an essential part of the music world.

The new ARP 2600 M delivers the sound admired around the world, in a more compact and portable format and including added features that make it the ideal incarnation of this historic synth.

When the ARP 2600 FS was announced in January 2020, it quickly became a phenomenal success with musicians all over the world recognizing the faithfulness to the original ARP 2600.

The ARP 2600 M is around 60% the original size, making it lighter, more portable and easier to place and use in a studio. It integrates the same analogue circuitry and components as the ARP 2600 FS, thus faithfully reproducing the characteristic ARP sound.

The ARP 2600 M is built in Japan with the same care and extraordinary quality standard as the ARP 2600 FS, and uses the same analogue components to accurately reproduce the sound and feel of the original.

The Spring Reverb has been re-engineered and adapted to the new size body to the same lush effect.

The ARP 2600 M comes with a dedicated Carry Case that not only protects your instrument, but also makes it easier to transport, thanks to its custom casters with special anti-shock damping technology.

There is also enough space to carry other gear together, like your favourite volca, SQ-64 or MIDI controller!

It is not by chance that the ARP 2600 has been so extremely popular to this day.

More than a synthesizer, the ARP 2600 M is a complete sound design studio. Even today, the ARP 2600 stands as a bridge between the individual elements of modular synthesis and the immediacy of a production / performance instrument. Included are an ample supply of oscillators, envelopes, a filter and amplifier - all of the building blocks of analogue synthesis. But the ARP 2600 M goes even further, with a spring reverb tank and even a pair of built-in monitor speakers. Also present is much of the versatility of a vintage modular system, including a ring modulation, lag and voltage processors, an envelope follower, audio preamp, a clock-able switch, noise source, a sample-and-hold module, signal inverters, an auxiliary mixer, and even a set of parallel-wired/multi jacks.

The new ARP 2600 M is not only faithful to the original, it also includes an array of added features that will make it even easier to use:

Plug and play: Connect any class compliant MIDI controller such as a KORG microKeys, nanokeys or SQ-64 to one of the ARP 2600 M's USB ports (USB-A and USB-B) and automatically get full control of your instrument!

Resized: The new size makes it easier to visualize your patch and also allows you to use shorter patch cables

Filter Choice: Two types of filters from two versions of the original ARP 2600(4012 type, 4072 type)

More MIDI: 5-Pin DIN plug MIDI IN added

Modern Control: Pitch-bend, Modulation, Portamento ON/OFF and Portamento ON/OFF can be controlled through MIDI CC messages (USB/DIN MIDI)

Normalized voltage: The threshold of the trigger signal required to activate the ADSR through the S/H GATE JACK has been reduced from 10V to 5V, making it much easier to use in combination with other gear such as volcas or Eurorack modules

Tweaked Parameters: Improved Attack and Release time ratios

Easy Connections: L/R Stereo Output Jack (instead of XLR)

Speakers turn automatically off when using headphones- improved, smoother sliders

Celebrating the rebirth of this iconic synth, the first 1000 units will come with a special colour road case, as well as a KORG microKEY2-37 so you can start playing right away!

The ARP 2600 FS comes with a diverse variety of music software from Izotope including "Ozone Elements" which lets you not only create songs but also master them using AI, "Skoove" which will help you improve your keyboard playing skills, "Reason Lite" DAW software, as well as software synths from KORG and other brands.

In other words, the moment you get your hands on this synthesizer you'll have a variety of tools to help you take your music to the next level.

Notes: Like a greatest hits of recent Analogue Solutions synths, the Ample combines sound elements from the Fusebox with jack patch points, a patch pin matrix, plus sequencer and CV touch pads from the Generator, creating something new and unique.

Supplier's Notes:
Ample combines the best elements of several of Analogue Solutions' recent products.

The sound elements of Fusebox
Jack patch points of Concussor Eurorack
Patch pin matrix of Vostok
Echo from Dr Strangelove
Sequencer and CV touch pads of Generator

It shares all this yet still has its own sound!

Ample can be as complex or as simple as you want it to be

This synth has been given a large and diverse number of controls, that along side the patch sockets, will give even the best and experienced synthesist endless possibilities.

This synth presents the controls in a user friendly and familiar synth layout that, together with this manual and other resources, enable even the new guy to get great sounds.

Synth - Percussion - Audio Processor

Ample is a compact analogue synthesizer. Analogue - as in really analogue. Aside from the MIDI chip (which has to be digital), everything else is totally analogue using real transistors and op-amps. There are no CPU stabilised and quantised circuits, no DCOs, no digital LFOs and no digital EGs, as found on other so called analogue synths. The circuitry is based on designs dating back to the mid-1970s. So Ample has a genuine old sound.

Circuits included

3x Analogue Oscillators

There are three analogue VCOs - each providing a wealth of features and modulation choices. VCO3 can easily be utilised as a LFO.

2x Analogue Low Frequency Oscillator

LFO2(/Sync) has a triangle wave output. VCO3 can be used as an LFO and has Saw, Triangle and Square wave modulation signals.

Analogue Filter

Ample uses a four pole 24bB per octave low pass filter.

Analogue Amplifier

The VCA can be set to THRU so it is always 'open'. This allows Ample to be used as an effects processor.

2x Analogue Envelopes

There are two EGs - each having full control over ATTACK, DECAY, SUSTAIN, and RELEASE.

Modulation

Great thought has been placed into modulation route choices, allowing a wide range of sounds to be produced, including percussion and 'modular' sounds further extended by patching with the jack sockets and pin matrix.

MIDI

MIDI is intentionally kept simple - so you can concentrate on making new sounds and making music - not getting tied up with SYSEX programming.

You get the all important control over filter cut-off using MIDI Velocity.

Patchable External CV Control Sockets

Ample has many input and output audio and CV sockets - to allow the synth to be effectively re-wired to make new sounds.

The sockets also enable it to be easily used with Eurorack and other modular systems. They can be patched together.

Sequencer

Ample has a vintage style 16 step sequencer.

Touch Keys

There are 6 touch keys that each output a set voltage. Use this to play the pitch or as modulation signals. A great tool for inspiration!

Pin Matrix

A neat way to patch the synth.

Echo

Nice lo-fi echo / delay.
