Modulate filter cutoffs, VCA amplitudes, and other parameters to shape your sound dynamically.

Audio & Low Frequency Oscillator

VCO Mode. Use the cycle switch to convert the function generator into a voltage-controlled oscillator for audio-rate signals.

LFO Mode. Generate low-frequency modulation signals to control parameters such as pitch, filter frequency, or amplitude.

Create vibrato, tremolo, and rhythmic modulation patterns.

Slew Limiter & Waveform Modulation

Slew Limiter. Smooth out abrupt changes in CV signals to create portamento effects or gradual transitions.

Waveform Modulation. Adjust Rise and Fall shapes to create logarithmic, linear, or exponential waveforms, adding character to your modulation.

Glide between notes, shape modulation curves for more organic sounds.

Logic Section

AND, OR. Combine signals using logic operations to create new, complex modulation sources.

Generate gate signals based on multiple inputs, create rhythmic patterns, and trigger events.
Comparator (X > Y). Compare two signals and generate a logic output when one exceeds the other.

Create gate signals from modulation sources, detect signal thresholds, and trigger events based on signal levels.

Specifications

Dimensions 24HP - 120×128,5mm
Current +12V 150mA / +5V 0mA / -12V 130mA
Input & Output Signals + / -10V
Min. time for Attack & Decay 0.5ms
Max. time for Attack & Decay 7 minutes
Impedance Input 10k - Output 10k
Materials PCB and Panel - FR4 1,6mm
Depth 40mm including connectors (Skiff friendly)
