Six-voice (or three stereo channel) mixer in a small format, the Supamix takes a straightforward but highly effective approach. Swap functions allow for creative approaches to mutes, randomisation and sequencing.

Supplier's Notes:
A compact stereo line mixer created with live performance and space optimisation in mind. This 6-channel stereo mixer has a fully analogue audio path with 2 VCAs per channel controlled by fines tuned analogue envelopes to minimise mute clicks. It also embeds a unique mute swap function with 6 modes allowing you to automate muting.

Supamix is a compact stereo line mixer designed for live performances and space optimization.
This 6-channel stereo mixer features a fully analogue audio path with 2 VCAs per channel and finely
tuned analogue envelopes for vactrol-like muting control minimizing mute clicks.

Supamix also includes a unique mute swap function with six modes, offering versatile
mute automation possibilities.

The mixer is designed with a variety of input options to accommodate different needs while
being compact:

- Inputs 1 / 2 have manual pan controls for placing static sounds within the mix.
- Inputs 3 / 4 have CV pan controls to moving sound sources in the stereo field
- Inputs 5 / 6 are stereo, making it easy to mix modules with stereo outputs (right input is normalized to the left) to mix the growing catalogue of stereo modules.

A header on the back allow you to use the L output as a TRS stereo output. Another header is here to link the Supamix with the O phone / line module.

The Swap functions on the modules are both useful for transitioning between sound scenes or creative applications. To change the swap modes on Supamix, press the Shift button and one of the mutes. If you press the Swap button, it will activate the swap manually. The following are the swap modes available.

1 -> Scene change gate : Reverse the mutes states when a gate is high
2 -> Scene change trig : reverse the mutes state when trigged (or if the swap button is pushed)
3 -> Binary counter : CV input between 0 and 5v will correspond to a 6 bit binary counter. At 0v mutes will be all oo, 5v will be all open. And it will count as follow :100000 010000 110000.....
4 -> Randomizer: Trigg to randomize the mutes. You can change the probability of having the mutes on by using a trigger between 2 and 5v.
5 -> Sequencer: Trig to go one step further. It reverse the current step mute state.
6 -> State rotation: Rotate the mute state 0v there isn't rotation, 5v is a full cycle rotation. This shift the mutes state (last one goes to first one)

Main features:

6 voice mixer
Manual pan on 1 / 2
CV pan on 3 / 4
Stereo inputs on 5 / 6
Unique mute swap functions
Linkable to the O output module

Some applications:

Compact case line mixer
Creative mute switching / sequencing
Feedback R out to one of the cv pan input to cv control feedback distortion

Technical details:

10 hp
Fully Analogue signal patch with 12VCAs with envelopes on each.
Skii friendly
Reverse power protection
