Notes: A neat button module with long-lasting 4x4 tactile buttons that provide instant access to triggering samples, launching clips, controlling playback, or just simply drumming.

Set them to momentary, 2 or 3-step toggle action to enjoy playful experimentation. Can be used with other Grid controllers used as a HID macro controller or for MIDI programming in your creative environment.

Equipped with customisable multi-coloured LED lights to enable labelling in dark environments. Facilitate differentiating each potmeter by changing the colour of each indicator LED, adjusting brightness levels individually or adding pulsing animations.

Thanks to its compact and lightweight structure, the BU16 is a fully ergonomic parameter controller with easily mappable push buttons.

It is recommended that Grid is connected directly to the computer with a USB-C cable (this is not included). Some USB hubs may not work with Grid, due to issues with how the various class compliant communication methods establish connection through a hub with the host computer.

Most digital audio workstations can identify Grid as a MIDI controller and appear as a MIDI mappable device. When multiple modules are interconnected, Grid is identified as a single control surface. If the interconnected controllers are plugged in separately into the same Host, they appear as Grid #1, Grid #2 MIDI devices and so forth.

By default, through the Host's MIDI learn functionality, all of the control elements can be mapped. Grid's default firmware uses a unique dynamic assignment, so a 10 module Grid control surface will have unique Channel, Command and CC/Note assignments on each control element.

Grid controllers are shipped with firmware default configuration. To modify the configurations of the controllers, the Grid Editor cross-platform application can be used. Through the Grid Editor, suggested manufacturer profiles and community profiles are also available. Grid has an event driven architecture, where every interaction with the controller triggers an event. The triggered event runs the configured actions, like setting LED colours and intensity.

Events on Grid available for configuration:
Init - when a page is initialized
Potmeter - fader or potentiometer change event
Encoder - rotation of endless encoders
Button - switch button or encoder interaction
Utility - side button
Midi rx - MIDI processing incoming to Grid
Timer - delayed message triggers

Grids are created to suit distinguished workflows. Whether it comes to controlling outboard hardware gear like synthesizers, guitar pedals, and effect boxes, or inboard software such as DAWs, Lightning, and VSTs, a Grid controller is an ideal choice.

Get started with Grid in an instant: just plug in, snap together and play. There is no need for a brain module or any additional software components.

Tech specs

Weight: ~ 175 grams (~ 0,38 lb)
Size: 106 mm x 106 mm (4.19 x 4.19 inches) Eurorack-sized modules
16 white tactile buttons with 1.27i0.49 N operating force
Customizable multi-coloured LED lights for easy labelling in dark environments

Materials

Black aluminium front panel with a metallic, rugged finish
Plastic push buttons in white
Injection moulded plastic base
Golden spring-loaded connector pins
Strong N52 neodymium magnets
Silicone feet on the back for extra stability

Compatibility

Class compliant MIDI device with simple PnP (Plug and Play) experience
USB HID keyboard class
Compatible with Mac OS (intel & arm), Windows, Linux and mobile platforms with support provided

Powering options (USB cable not included)

Single USB cable to power up to 8 modules
High speed USB 2.0
Draws ~250mA

Notes: A great solution for highly customisable control, the EN16 Grid module offers 16 velocity-sensitive rotary encoders, with configurable push button modes, multi-coloured LEDs and programmable range.

Supplier's Notes:
EN16 is made for fine-tuning enthusiasts: this Grid module offers 16 velocity sensitive incremental encoders with infinite rotation and mappable push functionality.

Create separate actions by left and right rotation or add distinguished commands with push rotation. Map banks to the same control or switch immediately from one command to another in just a second using only one module. Unlock potential through the Grid Editor with coarse or fine settings.

Equipped with customisable multi-coloured LED lights to enable labelling in dark environments. Facilitate differentiating each potmeter by changing the colour of each indicator LED, adjusting brightness levels individually or adding pulsing animations.

It is recommended that, Grid is connected directly to the computer with the supplied Intech Studio USB-C cable. Some USB hubs may not work with Grid, due to issues with how the various class compliant communication methods establish connection through a hub with the host computer.

Most digital audio workstations can identify Grid as a MIDI controller and appear as a MIDI mappable device. When multiple modules are interconnected, Grid is identified as a single control surface. If the interconnected controllers are plugged in separately into the same Host, they appear as Grid #1, Grid #2 MIDI devices and so forth.

By default, through the Host's MIDI learn functionality, all of the control elements can be mapped. Grid's default firmware uses a unique dynamic assignment, so a 10 module Grid control surface will have unique Channel, Command and CC/Note assignments on each control element.

Grid controllers are shipped with firmware default configuration. To modify the configurations of the controllers, the Grid Editor cross-platform application can be used. Through the Grid Editor, suggested manufacturer profiles and community profiles are also available. Grid has an event driven architecture, where every interaction with the controller triggers an event. The triggered event runs the configured actions, like setting LED colours and intensity.

Events on Grid available for configuration:
Init - when a page is initialized
Potmeter - fader or potentiometer change event
Encoder - rotation of endless encoders
Button - switch button or encoder interaction
Utility - side button
Midi rx - MIDI processing incoming to Grid
Timer - delayed message triggers

Grids are created to suit distinguished workflows. Whether it comes to controlling outboard hardware gear like synthesizers, guitar pedals, and effect boxes, or inboard software such as DAWs, Lightning, and VSTs, a Grid controller is an ideal choice.

Get started with Grid in an instant: just plug in, snap together and play. There is no need for a brain module or any additional software components.

Tech specs

Weight: ~ 175 grams (~ 0,38 lb)
Size: 106 mm x 106 mm (4.19 x 4.19 inches) Eurorack-sized modules
16 velocity sensitive incremental encoders with 360- rotation and mappable push functionality
Customizable multi-coloured LED lights for easy labelling in dark environments

Materials

Black aluminium front panel with a metallic, rugged finish
Ergonomic plastic encoders in black
Injection moulded plastic base
Golden spring-loaded connector pins
Strong N52 neodymium magnets
Silicone feet on the back for extra stability

Compatibility

Class compliant MIDI device with simple PnP (Plug and Play) experience
USB HID keyboard class
Compatible with Mac OS (intel & arm), Windows, Linux and mobile platforms with support provided

Powering options

Single USB cable to power up to 8 modules
High speed USB 2.0
Draws ~250mA

Notes: Knot is your compact and versatile USB MIDI host Knot is the perfect solution for musicians looking to bridge the gap between old-school MIDI gear like synthesizers, guitar pedals and USB-MIDI devices. With Knot, you can directly control your MIDI devices using Grid or other USB controllers.

Compatibility

Knot is equipped with two 3.5mm TRS jacks for sending and receiving MIDI data (both A and B TRS MIDI standards are supported). The jacks combined with the HOST port on the front ensure compatibility with countless setups.

Size & weight

Measuring just 60mm x 60mm x 10mm and weighing approximately 120 grams, Knot is a palm-sized device that is designed with portability in mind.

Firmware

Knot receives regular firmware updates with new features and other improvements. Updating is snappy and straightforward using the Grid Editor software. Knot is an open hardware project, and all source files are available on GitHub.

Powering

Knot got you covered with its wide range of powering options. Whether you are a guitarist with an extensive collection of pedals and chargers, or someone who keeps spare DC adapters just in case, Knot is an ideal choice with its extensive DC charging options. The device features an automatic polarity checking mechanism, allowing you to use chargers with either positive or negative tip without any issue. Power Knot with a USB-C cable, your trusty old guitar pedal power supply or with a power adapter from the MIDI Essentials Pack.

Usage Instructions:

Knot hosting Intech Studio's Grid

Using Knot as a USB MIDI Host for connecting Grid with your hardware MIDI devices is straightforward. You'll need the following things to get started:

Knot
1x Grid module of your choice (-or more of course!) and its respective USB-C cable for power and data
1x MIDI cable, for connecting Knot with the MIDI hardware device (either a 3.5mm TRS cable or a 5-pin DIN MIDI cable with a TRS adapter)


To connect the devices together:
Knot plugged into a power source either through the "USB-C" port or the "DC IN" port
Grid plugged into Knot through the "USB HOST" port
the MIDI hardware device plugged into the "MIDI OUT" of Knot with a MIDI cable

To check if everything's working as it should, look out for the LEDs on the Knot frontplate. When Knot first receives ample power the 3 LEDs will light up in purple for a second. After boot, while a USB device is connected it should be green with the occasional white blip indicating when a message is being sent or received.

Knot hosting other MIDI devices

Using Knot as a USB MIDI Host for connecting Grid with you hardware MIDI devices is straightforward. You'll need the following things to get started:
1x Knot and its respective USB-C cable for power or a DC power adapter
1x USB MIDI Device of your choice
1x MIDI cable, for connecting Knot with the MIDI hardware device (either a 3.5mm TRS cable or a 5-pin DIN MIDI cable with a TRS adapter)

To connect the devices together:

Knot plugged into a power source either through the "USB-C" port or the "DC IN" port
the MIDI device plugged into Knot through the "USB HOST" port
the MIDI hardware device plugged into the "MIDI OUT" of Knot with a MIDI cable

To check if everything's working as it should, look out for the LEDs on the Knot frontplate. When Knot first receives ample power the 3 LEDs will light up in purple for a second. After boot, while a USB device is connected it should be green with the occasional white blip indicating when a message is being sent or received.

Knot TRS MIDI output

For example a synth will usually have one MIDI channel it receives MIDI CC or Note messages on. You can usually set this MIDI channel in the synth's menu.

As a rule of thumb: Devices that can receive MIDI messages, do so by default on MIDI channel 1 or on all channels.

Set this MIDI channel to the same one set in your Hosted Device. In the case of Grid, check the MIDI Action Blocks in Grid Editor and configure them to the same MIDI channel set on your instrument.

TRS MIDI output

The output through the USB Host port will be mirrored (as far as MIDI is concerned) on the TRS MIDI output connector of Knot.

Tech specs

Weight: ~ 120 grams (~ 0,26 lb)
Size: 60mm x 60mm x 10mm (2.36 x 2.36 x 0.39 inches)
Material: black aluminium housing

Portable and lightweight USB MIDI host equipped with:

TRS MIDI input port
TRS MIDI output port
USB-C port for charging and updating the device
Hardware A/B switch for changing the TRS wiring mode
Mode button for updating the firmware
3 indicator LEDs

Notes: The PO16 is a sleek, compact, single-turn rotary potentiometer module for controlling quick motion changes like EQ, filters, or synth parameters.

Equipped with customisable multi-coloured LED lights to enable labelling in dark environments. Facilitate differentiating each potmeter by changing the colour of each indicator LED, adjusting brightness levels individually or adding pulsing animations.

It is recommended that, Grid is connected directly to the computer with the supplied Intech Studio USB-C cable. Some USB hubs may not work with Grid, due to issues with how the various class compliant communication methods establish connection through a hub with the host computer.

Most digital audio workstations can identify Grid as a MIDI controller and appear as a MIDI mappable device. When multiple modules are interconnected, Grid is identified as a single control surface. If the interconnected controllers are plugged in separately into the same Host, they appear as Grid #1, Grid #2 MIDI devices and so forth.

By default, through the Host's MIDI learn functionality, all of the control elements can be mapped. Grid's default firmware uses a unique dynamic assignment, so a 10 module Grid control surface will have unique Channel, Command and CC/Note assignments on each control element.

Grid controllers are shipped with firmware default configuration. To modify the configurations of the controllers, the Grid Editor cross-platform application can be used. Through the Grid Editor, suggested manufacturer profiles and community profiles are also available. Grid has an event driven architecture, where every interaction with the controller triggers an event. The triggered event runs the configured actions, like setting LED colours and intensity.

Events on Grid available for configuration:
Init - when a page is initialized
Potmeter - fader or potentiometer change event
Encoder - rotation of endless encoders
Button - switch button or encoder interaction
Utility - side button
Midi rx - MIDI processing incoming to Grid
Timer - delayed message triggers

Grids are created to suit distinguished workflows. Whether it comes to controlling outboard hardware gear like synthesizers, guitar pedals, and effect boxes, or inboard software such as DAWs, Lightning, and VSTs, a Grid controller is an ideal choice.
Get started with Grid in an instant: just plug in, snap together and play. There is no need for a brain module or any additional software components.

Tech specs

Weight: ~ 175 grams (~ 0,38 lb)
Size: 106 mm x 106 mm Eurorack-sized modules (4.19 x 4.19 inches)
16 linear 300- single-turn conductive plastic potentiometers
Customizable multi-coloured LED lights for easy labelling in dark environments

Materials

Black aluminium front panel with a metallic, rugged finish
Ergonomic potentiometers in black with plastic knobs
Injection moulded plastic base
Golden spring-loaded connector pins
Strong N52 neodymium magnets
Silicone feet on the back for extra stability

Compatibility

Class compliant MIDI device with simple PnP (Plug and Play) experience
USB HID keyboard class
Compatible with Mac OS (intel & arm), Windows, Linux and mobile platforms with support provided

Powering options

Single USB cable to power up to 8 modules
High speed USB 2.0
Draws ~250mA

Notes: BU16 Series 3 is a compact and expressive button module designed for dynamic control in creative environments. It features a 4x4 grid of MX Gateron Hall effect switches, offering velocity and pressure sensitivity for responsive, nuanced input - ideal for triggering samples, launching clips, controlling playback, or finger drumming with more depth.

Each button is backed by an RGB LED, and the default keycaps feature cutouts, ensuring that the LED indicators remain clearly visible during use. The keycaps are interchangeable, making it easy to customize layout, feel, or labeling to fit your workflow.

The fiberglass front panel now has a textured finish, giving the module a solid, durable feel with improved grip for everyday use.

BU16 buttons can be configured for momentary, two-step, or three-step toggles, encouraging playful experimentation in both performance and production setups. Fully compatible with other Grid modules, BU16 can be used as a MIDI controller or HID macro pad, depending on your needs.

All LEDs are configurable via the Grid Editor - adjust individual brightness, assign custom colors, or add pulsing animations to clearly differentiate controls, especially in low-light setups

Use cases include:

- Triggering samples or one-shots in a DAW or standalone sampler

- Launching clips and scenes in software like Ableton Live

- Controlling transport functions (play, stop, record, etc.)

- Finger drumming or live pad performance

- Switching tools or layers in visual/VJ software

Sending macros or shortcuts as a HID controller for creative applications beyond music (e.g., video editing, graphic design)

The Grid Editor enables a highly-customizable controlling solution through in-depth programmability in LUA code.

Compatible with Mac OS, Windows, Linux operating systems and mobile platforms. Grid supports USB native control options like MIDI, HID keyboard, mouse and game control.

Notes: EF44 Series 3 gives you control over performance effects, modulation, panning, and more, now with upgraded hardware and improved tactile options. It features audio-grade linear faders and newly redesigned metal rotary encoders, which are now available in both detent and smooth (non-stepped) variants, so you can choose the feel that best fits your workflow.

The fiberglass front panel with a textured finish adds durability and a more solid grip, making it well-suited for both studio and live use.

EF44 Series 3 supports MIDI CC mapping and integrates easily with your DAW or hardware setup. Each encoder is surrounded by a multicolor LED indicator that you can fully customize: assign colors, tweak brightness levels, or apply pulsing animations - all configurable in the Grid Editor. This makes it easier to navigate and label your controls, especially in darker environments.

As with all Grid modules, EF44 Series 3 features magnetic side connections and golden pins, allowing it to be flexibly expanded and seamlessly paired with other Grid controllers.

The Grid Editor enables a highly-customizable controlling solution through in-depth programmability in LUA code.

Compatible with Mac OS, Windows, Linux operating systems and mobile platforms. Grid supports USB native control options like MIDI, HID keyboard, mouse and game control.

Notes: The EN16 detent version is made for fine-tuning enthusiasts: this Grid module offers 16 velocity sensitive incremental encoders with infinite rotation and mappable push functionality. There are 20 'clicks' as the encoder is turned around the clock.

The Grid Editor enables a highly-customizable controlling solution through in-depth programmability in LUA code.

Compatible with Mac OS, Windows, Linux operating systems and mobile platforms. Grid supports USB native control options like MIDI, HID keyboard, mouse and game control.

Notes: From subtle adjustments to expressive performances, this versatile combination of control elements definitely won't disappoint you. Includes metal shaft faders with medium resistance, smooth-turning metal shaft knobs and Gateron hall effect key switches. Control your most used parameters, like expression, modulation and volume with the PBF4 Grid. Equipped with customisable multicolored LED lights to enable labelling in dark environments. Facilitate differentiating each potmeter by changing the color of each indicator LED, adjusting brightness levels individually or adding pulsing animations. All configurable in the Grid Editor.

The Grid Editor enables a highly-customizable controlling solution through in-depth programmability in LUA code.

Compatible with Mac OS, Windows, Linux operating systems and mobile platforms. Grid supports USB native control options like MIDI, HID keyboard, mouse and game control.

Notes: The PO16 is a sleek, compact, single-turn rotary potentiometer module now built with metal shaft potentiometers. Suitable for controlling quick motion changes like EQ, filters, or synth parameters, which are mapped out as one-knob-per-function. Equipped with customisable multicolored LED lights to enable labelling in dark environments. Facilitate differentiating each control element by changing the color of each indicator LED, adjusting brightness levels individually or adding pulsing animations.

The Grid Editor enables a highly-customizable controlling solution through in-depth programmability in LUA code.

Compatible with Mac OS, Windows, Linux operating systems and mobile platforms. Grid supports USB native control options like MIDI, HID keyboard, mouse and game control.

Notes: TEK2 Series 3 is an updated version of the TEK2 control module, offering improved tactile response, visual feedback, and build quality. It retains the familiar layout of two endless jog wheels and eight buttons, while introducing several key upgrades for more expressive control and better usability.

The buttons now feature MX Gateron Hall effect switches with velocity and pressure sensitivity, allowing for dynamic, responsive input. Each button has an RGB LED underneath, and the default keycaps include cutouts to keep the LED indicators clearly visible. The keycaps are also interchangeable, making it easy to customize the feel, labeling, or layout based on your workflow or preferences.

The jog wheels remain smooth and continuous, with integrated press functionality and 5-point multicolor LED rings for real-time visual feedback. A central 5-bit display provides additional feedback, such as showing centered values or parameter states. The fiberglass front panel now features a textured surface, improving durability and grip.

Possible use cases include:

- Video editing: jog wheel scrubbing, cut/snap/zoom controls in apps like Premiere Pro or Resolve

- Photo editing: brush size, exposure, and tool switching in Photoshop or Lightroom

- Audio production: controlling macros, levels, or clip launching in Ableton Live or Logic

- Live performance or VJ setups: triggering presets, switching layers, or adjusting effects on the fly

- Navigating timelines in video editors like Premiere Pro or DaVinci Resolve

- Adjusting brush size and exposure in photo software like Lightroom or Photoshop

- Controlling macros, FX sends, or clip navigation in audio DAWs like Ableton Live or Logic Pro

- Triggering actions, switching tools, or stepping through presets in VJ or live performance setups

TEK2 Series 3 is designed to be flexible, reliable, and easy to integrate into a wide range of creative workflows.

The Grid Editor enables a highly-customizable controlling solution through in-depth programmability in LUA code.

Compatible with Mac OS, Windows, Linux operating systems and mobile platforms. Grid supports USB native control options like MIDI, HID keyboard, mouse and game control.
