Notes: Whether you're a game developer, filmmaker or musician, virtual reality is the undeniable future of content creation. While 360-video is exploding in popularity, the ability to easily create 360-audio has lagged behind...until now.

The Zoom H3-VR virtual reality audio recorder is the complete solution for capturing and processing spatial audio for VR, AR and mixed-reality content. With a built-in Ambisonic mic, recorder and decoder, the H3-VR puts 360-audio in the palm of your hand.

In the past, capturing VR audio required a dedicated Ambisonic mic, a separate recorder and a computer for encoding the audio from raw Ambisonics A format to VR-ready Ambisonics B format. Now, with the H3-VR, all of the encoding and decoding is done on board, saving time, money and effort at every step.

Ambisonics Audio for VR:

The H3-VR's 4-capsule Ambisonic mic captures precise 360-degree VR audio recordings up to 24 bit/96 kHz. And without ever connecting to a computer, the onboard decoder allows you to export Ambisonics B-format files directly.

Binaural 3D Stereo:

The H3-VR also records stereo binaural WAV files up to 24 bit/48 kHz. Stereo binaural provides a hyper-realistic spatial recording that enhances 2D productions with 3D audio.

Standard Stereo:

The H3-VR even offers standard stereo recording for recordings that will be played out of speakers rather than headphones.

5.1ch Surround for Video:

Free to download, ZOOM Ambisonics Player software can easily convert Ambisonics audio to a 5.1ch surround file that is pre-aligned to the proper speakers, and is exported to your video or audio editor for syncing with standard video.

Live Streaming 360:

The H3-VR also enables you to live stream events in 360 degrees so that wherever your fans are, they'll have access to the best seats in the house.

Notes: With the LiveTrak L-12, you can finally mix, record, and monitor with a single piece of gear. It's the only digital console that lets you mix your live performance and record up to 12 discrete channels - all while providing five individual custom headphone mixes.

Effortless Live Mixing:

LiveTrak's 12 discrete channels (eight mono plus two stereo) have a 3-band mid-parametric EQ and 16 built-in send effects. Its eight mono channels also have a dedicated compressor. With all these controls plus its 12-segment LED metering, the L-12 offers just what you need for intuitive mixing.

Record Everything, Remix Anywhere:

LiveTrak lets you record 12 discrete tracks up to 24-bit/96 kHz WAV audio to an SD card while simultaneously mixing your live show. Tracks are recorded pre-EQ and effects, so they can be transferred to your favourite DAW for further mixing and editing.

Five Custom Monitoring Mixes:

Each of LiveTrak's five monitor outputs provides a unique mix, so every performer can create and save a mix that's tailored to their preferences. Its headphone amplifier delivers volume that stands up in any live environment without the need for a separate headphone monitoring setup.

USB Connectivity for Your DAW:

LiveTrak is also a 14-in/4-out USB audio interface with flexible routing options, offering unlimited possibilities. Class compliant mode, which enables connection with iOS devices, is also supported.

Here's what comes included with the L-12:

- AC adapter (AD-19)
- USB 2.0 cable
- Quick Guide

Notes: The Zoom G1 FOUR features over 60 effects and amp models, looper and drum machine. Plus, access ZOOM Guitar Lab's additional library of downloadable effects. Plug in and be amazed!

Sounds That Inspire:
The pedal has more than 60 traditional and boutique effects, including ring modulator, pitch-shifting delay and even sitar simulation.

Your Favourite Amps & Cabinets:
With 13 classic amps and cabinets like Fender, Marshall, Orange and more, the G1 series brings big stage sound wherever you go.

You'll Love The Free Guitar Lab Software:
With ZOOM Guitar Lab, explore an endless world of artist patches, effects and more. And with its ability to manage and backup all of your patches, you can experiment and create endless combinations.

Drums Included:
Play along with 68 great-sounding rhythm patterns in different time signatures, including 4/4, 3/4 and more.

Stay Looped In:
The built-in looper can record up to 30 seconds of playing, allowing you to create dynamic, multi-part arrangements.

Auto Patch Backup:
Your patches and level settings are instantly backed up when using the Auto Save function, ensuring you never lose your latest creation.

Perform Live:
Seamlessly switch up your sounds during live shows using either of 2 performance modes.

PRESELECT mode lets you jump from patch to patch without affecting the patch your currently playing.

STOMP mode lets you turn individual effects on and off with the tap of your foot.

Off the Floor:
The G1 FOUR control panel is also designed for hands-on, desktop use. Dial in tones and adjust level settings with absolute precision to craft your perfect sound.

Power Options:
The G1 FOUR runs on just four AA batteries. Alternatively, it can be powered using the optional Zoom AD-16 AC adapter or via USB bus power.

Notes: The Zoom G1X FOUR features over 70 effects and amp models, looper and drum machine. Plus, access ZOOM Guitar Lab's additional library of downloadable effects. Plug in and be amazed!

X is for Xpression:
The G1X FOUR comes with ZOOM's expression pedal, which provides control over effects such as volume, wah, delay and pitch.

Sounds That Inspire:
The pedal has more than 60 traditional and boutique effects, including ring modulator, pitch-shifting delay and even sitar simulation.

Your Favourite Amps & Cabinets:
With 13 classic amps and cabinets like Fender, Marshall, Orange and more, the G1 series brings big stage sound wherever you go.

You'll Love The Free Guitar Lab Software:
With ZOOM Guitar Lab, explore an endless world of artist patches, effects and more. And with its ability to manage and backup all of your patches, you can experiment and create endless combinations.

Drums Included:
Play along with 68 great-sounding rhythm patterns in different time signatures, including 4/4, 3/4 and more.

Stay Looped In:
The built-in looper can record up to 30 seconds of playing, allowing you to create dynamic, multi-part arrangements.

Auto Patch Backup:
Your patches and level settings are instantly backed up when using the Auto Save function, ensuring you never lose your latest creation.

Perform Live:
Seamlessly switch up your sounds during live shows using either of 2 performance modes.

PRESELECT mode lets you jump from patch to patch without affecting the patch your currently playing.

STOMP mode lets you turn individual effects on and off with the tap of your foot.

Off the Floor:
The G1X FOUR control panel is also designed for hands-on, desktop use. Dial in tones and adjust level settings with absolute precision to craft your perfect sound.

Power Options:
The G1X FOUR runs on just four AA batteries. Alternatively, it can be powered using the optional Zoom AD-16 AC adapter or via USB bus power.

Notes: Great value multi-effects pedal based on all of Zoom's extensive experience. Chain up to nine effects including amp emulation and cabinet simulation. A proper all-rounder offering a huge range of tones.

Supplier's Notes:
Jaw dropping effects combined with powerful amp modeling, the G6 is in a class of its own.

The culmination of 30 years of Zoom's engineering know-how, passion for audio and love of guitar. The G6 is brimming with some of the best sounds you'll ever hear.

Your sounds may be complex but building them shouldn't be. With easy-to-use, application driven technology, the G6's 4.3-inch color touchscreen lets you drag, drop and swipe your way to new sounds.

All the best amps in amp history are in here (and a few new ones, too), along with 70 pre-loaded, precisely recorded impulse responses (IR) and room to add more than 100 of your own.

The G6 also delivers the ultimate collection of Zoom's legendary guitar effects and tones, including brand new Distortion and Modulation effects.

The G6 has room for 240 patches, including 100 presets so you can build patches for each song in your repertoire and easily cycle through your setlist. Create patches of up to nine effects.

The four Play Modes on the G6 will change the touchscreen and footswitch layout to give you quick access to the controls you need.

In addition to the internal 45-second looper, you can insert an SD card and record a loop up to 2 hours long. Choose the groove you want from 68 internal rhythm patterns, styles and measures.

Portable, versatile, and packed with tonal possibilities, the G6 can be tucked into a guitar bag or backpack, and off you go.

The G6 has a mono input, stereo outputs with output volume control, a mono fx loop, aux in, control in and headphone out. Using the USB port, the G6 also functions as a 2in/2out audio interface for Mac and PC.

Wirelessly connect the G6 directly to the Handy Guitar Lab app via Bluetooth. Using the optional BTA-1 adaptor, you can browse and upload/download an endless assortment of amps, effects and artists patches as provided on Guitar Lab software. Guitar Lab is also available for both PC and Mac.

What's in the Box:

G6 Multi-Effects Processor
Zoom AD-16 AC adapter
Quick guide
Steinberg Cubase LE Software

Optional Accessories:

FP02M Expression Pedal
BTA-1 Bluetooth Adapter

Specs:

MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS: 7
USER PATCHES: 240
SAMPLING FREQUENCY: 44.1 kHz
A/D CONVERSION:24-bit 128x oversampling
D/A CONVERSION: 24-bit 128x oversampling
SIGNAL PROCESSING: 32-bit
FREQUENCY CHARACTERISTICS: 20 Hz - 20kHz (+0.5 db/-0.5 dB) (10k load)
DISPLAY: 4.3" TFT color LCD (480x272)

Notes: For podcasters, videographers, bloggers, journalists and more, the F2 is the perfect audio solution for creators on the move.

The F2 is incredibly small, but its audio quality will amaze you.

The F2 features 32-bit float recording technology, allowing you to record the loudest audio signals without worrying about clipping. It will also record the quietest signals in beautiful detail. And the best part is you don't have to worry about setting the gain. Just plug in the lav and hit record.

Once you start your recording, use the F2's HOLD switch to ensure you don't accidentally stop recording.

Screw-lock connectors keep your lav plugged-in securely no matter the situation.

With the F2 actors can record and playback their lines to perfect their delivery.

The F2 Editor for PC and Mac allows you to adjust settings, format SD cards and more. Simply connect your F2 or F2-BT via a USB cable and launch the editor. The USB connection also makes it easy to transfer files to your computer. See the F2 Editor features here.

Whether a stroll through your garden, or the whispers and shouts of a dramatic reading, the F2 provides crystal clear recordings.

The F2 can record up to 15 hours (14 hours on the F2-BT) with two AAA batteries.

Record on microSD, microSDHC, and microSDXC cards up to 512GB.

The LMF-2 omnidirectional lavalier microphone has a low-profiled design, captures high-quality audio, and includes a windscreen and lapel mic clip.

The F2 Field Recorder gives you the option to choose the recording format that works best for your projects. Choose from 44.1 kHz/32-bit float or 48 kHz/32-bit float mono WAV files.

The F2 Is Perfect For Recording Interviews Anywhere.

Input
Connector: 3,5 mm stereo mini (with screw lock) Supports plug-in power (2.5 V)
Input impedance: 2 kO or more
Maximum input level: -5,5 dBu
Output
Connector: 3,5 mm stereo mini (with screw lock)
Maximum output level: 20 mW + 20 mW (into 32 ? load)
Recording media
Cards compatible with microSD/microSDHC/microSDXC specifications (Class 4 or higher, 512 GB maximum)
Recording formats
WAV, 44.1kHz/32-bit float, 48kHz/32-bit float Mono, BWF format supported WAV
USB
USB Typ-C
Note: Use a USB cable that supports data transfer. USB bus power is supported.
Mass storage operation: USB 2.0 High Speed
PC app operation: USB 2.0 High Speed
Power
2 AAA batteries (alkaline, lithium or rechargeable NiMH batteries)
AC adaptor
Bluetooth
Bluetooth Ver4.2 (F2-BT only)

External dimensions: 57,5 mm (w) x 46,4 mm (D) x 22,4 mm (H)
Weight (main unit only): 32 g

Notes: For podcasters, videographers, bloggers, journalists and more, the F2 is the perfect audio solution for creators on the move.

The F2 is incredibly small, but its audio quality will amaze you.

The F2 features 32-bit float recording technology, allowing you to record the loudest audio signals without worrying about clipping. It will also record the quietest signals in beautiful detail. And the best part is you don't have to worry about setting the gain. Just plug in the lav and hit record.

Once you start your recording, use the F2's HOLD switch to ensure you don't accidentally stop recording.

Screw-lock connectors keep your lav plugged-in securely no matter the situation.

With the F2 actors can record and playback their lines to perfect their delivery.

The F2-BT comes with built-in Bluetooth. And with the free Zoom F2 Control app the F2-BT can wirelessly start/stop recordings, display battery levels, adjust output volume, control lo-cut and more.

You can also pair the F2-BT with a Bluetooth timecode synchronization device to receive and write timecode to recorded files. See Bluetooth Control features here.

The F2 Editor for PC and Mac allows you to adjust settings, format SD cards and more. Simply connect your F2 or F2-BT via a USB cable and launch the editor. The USB connection also makes it easy to transfer files to your computer. See the F2 Editor features here.

Whether a stroll through your garden, or the whispers and shouts of a dramatic reading, the F2 provides crystal clear recordings.

The F2 can record up to 15 hours (14 hours on the F2-BT) with two AAA batteries.

Record on microSD, microSDHC, and microSDXC cards up to 512GB.

The LMF-2 omnidirectional lavalier microphone has a low-profiled design, captures high-quality audio, and includes a windscreen and lapel mic clip.

The F2 Field Recorder gives you the option to choose the recording format that works best for your projects. Choose from 44.1 kHz/32-bit float or 48 kHz/32-bit float mono WAV files.

The F2 Is Perfect For Recording Interviews Anywhere.

TECHNICAL SPECIFICATIONS

LMF-2
Lavalier mic
Connector: 3,5 mm stereo mini (with screw lock)
Directionality: Omnidirectional
Sensitivity: -32 dB/Pa at 1 kHz
Maximum sound pressure input: 115 dB SPL
Cable length: 160 cm

F2 / F2-BT
Input
Connector: 3,5 mm stereo mini (with screw lock) Supports plug-in power (2.5 V)
Input impedance: 2 k? or more
Maximum input level: -5,5 dBu
Output
Connector: 3,5 mm stereo mini (with screw lock)
Maximum output level: 20 mW + 20 mW (into 32 O load)
Recording media
Cards compatible with microSD/microSDHC/microSDXC specifications (Class 4 or higher, 512 GB maximum)
Recording formats
WAV, 44.1kHz/32-bit float, 48kHz/32-bit float Mono, BWF format supported WAV
USB
USB Typ-C
Note: Use a USB cable that supports data transfer. USB bus power is supported.
Mass storage operation: USB 2.0 High Speed
PC app operation: USB 2.0 High Speed
Power
2 AAA batteries (alkaline, lithium or rechargeable NiMH batteries)
AC adaptor
Bluetooth
Bluetooth Ver4.2

The above values are approximate. Continuous battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.

External dimensions: 57,5 mm (w) x 46,4 mm (D) x 22,4 mm (H)
Weight (main unit only): 32 g

Notes: A multi track recorder that redefines 'easy' - With a familiar touchscreen interface, the R20 makes it insanely simple to track, edit and mix your songs, letting you focus on the music.

Musicians, be prepared to get blown away - The R20 has the best preamps and noise floor of any multi track recorder Zoom has ever designed. With six XLR inputs, two combo inputs, and 16 tracks of recording, the R20 is perfect for singer-songwriters to full bands.

Drag, drop, pinch, swipe, create - Navigate and edit with ease, via the R20's 4.3-inch color LCD touchscreen interface.

Colour-coded for clarity - Improve your workflow with color-coded faders, gain dials, and touchscreen track regions, making sure you are always adjusting the correct channel.

Put the pieces together - Cut, copy, combine and loop. The R20's interface provides intuitive editing. You'll immediately feel at home.

Spice things up - Polish your tracks and mixes with professional effects such as EQ, compression, and more.

The R20 provides a full MFX processor compatible with Guitar Lab software.

The rhythm is gonna get ya - 30 genres, 150 rhythm patterns and song form variations, it's hard to find a drummer this versatile

18 built-in synth sounds - Plug in a MIDI keyboard via USB-C or use the touchscreen to add sonic textures with the R20's internal synthesizer.

Backing tracks - The R20 can import and playback standard MIDI files allowing you to import bass lines, melodies, piano parts, and more.

Record to SD - The R20 records directly to SDHC or SDXC cards up to 1 TB, giving you plenty of space to track your next song or album.

Monitor & plyabck - The R20 has a headphone jack for monitoring while recording and dedicated outputs for mixing on your favorite monitors.

Inputs - H1-Z is available on input 1, while 48V phantom power is available on inputs 5-8.

Locking AC Adapter - The new Zoom locking adapter ensures security against accidental unplugging.

Click - Access the fully adjustable click track with just a press of a button.

Wireless control app - Use the optional Zoom BTA-1* Bluetooth Adaptor to control the R20 wirelessly from your iOS device.

*BTA-1 available separately.

** R20 Control App available in 2022

Let's move forward together - accessibility for the Visually Impaired

The first multi-track recorder that allows accessibility for the visually impaired, the R20 Control App features VoiceOver and VoiceOver Gestures.

SPECS

Inputs/Outputs

INPUTS
MIC/LINE (mono): 8
OUTPUTS - Master out: 8 - Phones: 1

INPUTS
MIC/LINE (MONO)
Connectors: XLR/TRS combo jacks × 2 XLR × 6 (XLR: 2 HOT/TRS: TIP HOT)
Input gain: +6 ~ +50 dB
Input impedance: XLR: 3.9 kO TRS: 5.3 kO/1 MO (when Hi-Z is ON, for INPUT 1 only)
Maximum input level: +4 dBu (@0 dBFS)
Phantom power: +48 V (INPUTS 5-8, switchable in pairs)
Equivalent input noise: -121 dBu or less (IHF-A) with +50dB/150O input
Frequency response: -1.0 dB: 20 Hz - 20 kHz

OUTPUTS
MASTER OUT
Connectors: 2 TRS phone jacks (balanced)
Maximum output level: +14 dBu
Output impedance: 200 O

PHONES
Conncetor: 1 standard stereo phone jack
Maximum output level: 20 mW + 20 mW (into 32O load)
Output impedance: 33O

TRACK SETTINGS
EQ: High: 10 kHz, i12 dB, shelving - Middle: 2.5 kHz, i12 dB, peaking - Low: 100 Hz, i12 dB, shelving

RECORDER
Maximum simultaneous recording tracks: 8
Maximum simultaneous playback tracks: 16
Recording format: 44.1kHz, 16/24-bit, mono/stereo WAV
Recording media: 4-32GB cards compatible with the SDHC specification

EFFECTS
Maximum number of simultaneous effects: 3 effects (One insert effect on one channel or one send effect available to all tracks)
Patch memories: 50
Tuner: Chromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGAD

METRONOME
Time signatures: 3/4, 4/4, 6/8
Tempo range: 40.0-250.0 BPM

RHYTHM LOOPS
Polyphony: 8
Sound source format: FM
Number of sound types: 18 + PCM drum kit
Display: 4.3" (480×272) full-color touchscreen LCD

USB
Connector: USB Type-C
Audio interface operation
Stereo mix: USB 2.0 Full Speed, 44.1kHz, 16/24-bit, 2-in/2-out
Multitrack: USB 2.0 High Speed, 44.1 kHz, 16/24-bit, 8-in/4-out

MASS STORAGE OPERATION (Host/Device): USB 2.0 High Speed (5V/500mA power supplied when host)
GUITAR LAB CONNECTION (Host/Device): USB 1.1 Full Speed
USB MIDI KEYBOARD CONNECTION (Host/Device): USB 1.1 Full Speed (5V/500mA power supplied)
DAW CONNECTION (CONTROL SURFACE) FUNCTION: USB 1.1 Full Speed

MISC
REMOTE: Dedicated wireless adapter (ZOOM BTA-1)
POWER: AC adapter (ZOOM ZAD-1220): 12 V/2.0 A
Power consumption: 11 W maximum
External dimensions: 378 mm (W) × 206 mm (D) × 58 mm (H)
Weight (unit only): 1.33 kg

Note: 0 dBu = 0.775 V

What's In The Box?

Zoom R20
ZAD-1220 AC adapter
Quick Tour
Steinberg Cubase LE Software

Notes: A tiny but powerful field recorder capable of recording two channels in extremely high resolution. Records directly to microSD via a pair of mic/line inputs, with up to 8 hours recording time from a pair of AA batteries.

Supplier's Notes:
The small and mighty field recorder

Small design, big sound

With 32-bit float recording, the F3 effortlessly captures the quietest raindrops and the loudest explosions. Its small footprint allows for this recorder to be placed anywhere, as you capture and monitor up to 192 kHz of high-quality audio.

Focus on the scene

When you're working in the field or on set, sound levels can fluctuate often and quickly. The F3 allows you to adapt to your scene without having to set the gain or worry about clipping. In post, you'll be able to work with your capture, regardless of extremely low or high levels.

Award winning audio

Featuring the dual A/D converters and low-noise preamps found in our professional F-Series recorders, the F3 guarantees high-quality recordings in any setting or situation.

Battle tested

The F3 is built with durable side bars, standard tripod mount and slide-resistant rubber feet ensuring that you can mount it on your gear or hide it in any scene. It's sturdy metal casing and locking XLR connectors is designed for use in a variety of environments.

Wav watching

Monitor your recordings with seamless accuracy as the F3 displays your audio as real-time waveforms.

Record & listen

The headphone output allows you to keep an ear on your recordings, plus a line output enables you to go to your camera or other gear.

The F3 is well-equipped for long location shoots or remote fieldwork, with a variety of power options and massive storage.

With two alkaline AA batteries, take advantage of over eight hours of battery life.

Set yourself up for an unlimited charge via the AD-17 AC adapter or USB power supply.

Use a micro SD card up to 1TB to record over 180 hours of audio at the highest possible sample rate/bit-depth.

30' of control

Versatile control options give your production more flexibility than ever. Stay out of the shot and record from a distance of up to 30-feet (10m) using the F3 control app for iOS and Android*.
*F3 control app for Android available Spring 2022.
BTA-1 Bluetooth adapter sold separately.

Audio interface & streaming

Connect your F3 to a computer or iOS device via USB as an audio interface and record or stream up to two channels in crystal-clear 24-bit/96 kHz resolution. The loopback function allows you to combine your computer's audio with the F3 inputs to complete the sound for your stream.
*Available in 32-bit float/ 96 kHz with a firmware update in Spring 2022.

What's in the box

F3 Field Recorder
AA Batteries (x2)
Quick Tour

Specifications

Input and output channels
Inputs - MIC/LINE (mono): 2
Outputs - LINE OUT: 1, PHONE OUT: 1
Inputs
MIC/LINE (MONO)

Connectors: 2 XLR (2: HOT)

Input gain: Adjustment unnecessary (dual AD converter circuits used)
Input impedance: MIC: 3 kO or more, LINE: 3 kO or more
Maximum input level: MIC: +4 dBu,
LINE: +24 dBu

Phantom power: +24/48 V, Combined channel total of 10 mA or less

Equivalent input noise: ?127 dBu or less (IHF-A) when waveform magnification is ×1024 with 150 ? input
Outputs

Line out

Connector: 1 stereo mini jack

Maximum output level: +1 dBu

Output impedance: 100O or less
Phone out
Connector: 1 stereo mini jack
Maximum output level: 50 mW + 50 mW (into 32 O load)

Output impedance: 15O or less
Recorder

Maximum simultaneous recording tracks: 2

Maximum simultaneous playback tracks: 2

Recording format: WAV - 44.1/48/ 88.2/96/192 kHz, , 32-bit float mono/stereo,
BWF and iXML formats supported
Recording media: 4 - 32 GB cards compatible with the microSDHC specification

64 GB - 1 TB cards compatible with the microSDXC specification

Display: LCD with backlight (96×64 resolution)

USB
Connector: USB Type-C - Use a USB cable that supports data transfer. USB bus power is supported.

Audio interface operation:
USB 2.0 High Speed, 44.1/48/88.2/96 kHz, 24-bit, 2-in/2-out
Mass storage operation: USB 2.0 High Speed
Remote

Dedicated wireless adapter (ZOOM BTA-1)

Power:
2 AA batteries (alkaline, NiMH or lithium)
AC adapter (ZOOM AD-17): DC 5 V/1 A
USB bus power is supported

Notes: The H2essential is the only Handy Recorder with three internal microphones. With the ability to select different mic patterns, it gives creators more options than ever before. With two cardioid mics facing front and rear and a bi-directional mic facing side to side, the H2essential allows you to choose the perfect pick-up pattern for every recording.

Set your pickup pattern to 90O or 120O stereo, or choose mono for a hyper directional pickup, reducing background noise. Then choose to record from the front, rear, or activate both sides for surround sound pickup. Record in 32-bit float up to 96kHz ensuring high-quality audio without ever having to set gain.

When connected to a PC, Mac, iOS, or Android device using the USB-C port, the H2essential can be used as a USB microphone while simultaneously recording to the SD card. Connect the H2essential to your mobile device via USB and record professional audio directly onto your phone's video. Perfect for video podcasts and live streams.

Record in MS Raw and adjust the width of the stereo image in post production. This is helpful when you want to control ambient noise. The H2essential has advanced features such as a low cut filter, pre-record, auto record, and playback speed adjustment.

Using the BTA-1* Bluetooth Adapter, pair one or more H2essentials with your iOS device to remotely hit record and sync timecode. The H2essential is designed with Accessibility for the blind and visually impaired. Navigate the menu with audible descriptions through the built-in speaker or headphones. Creators can choose English, Spanish, French, Japanese, German, Italian or Chinese.

The specially designed windscreen for the H2essential provides wind protection when recording outdoors. The custom fit gives access to controls while the windscreen is attached. The 3.5mm input can accommodate audio players, keyboards, and lav mics with plug-in power. You can record with the front mic and the 3.5mm input simultaneously.

Use the mixer to easily adjust each track's audio level. The color LCD screen makes it easy to navigate through the H2essential's simple interface.The real-time waveform display lets you see your audio as it records.

Use the 3.5mm headphone output for headphones or connect directly to a camera. The onboard speaker allows you to listen to your recordings for quick reference as well as utilize the Accessibility functions. The H2essential supports SDXC cards up to 1TB.

The H2essential has a dedicated Marker button to instantly set reference points while recording. The H2essential can be powered by two AA batteries or via the USB-C port. This includes bus-power as well as external USB battery pa

Notes: For Solo Musicians

AMS-22 | 2-In, 2-Out

Perfect for mobile recording or streaming, the AMS-22 includes an XLR/TRS combo input, plus a stereo line in. It also includes a headphone output and 2 TRS outputs for external monitors.

Quick Control

With onboard hardware switches, the AMS-22 is designed to simplify common streaming challenges without the need for additional software.

Onboard Monitoring

Use the Direct Monitor Switch to directly send the input signal to your headphones while routing the same signal to your DAW or streaming software.

Loop It Back

The Loopback Switch combines the input audio with playback from your computer and routes it to your streaming software. This is perfect for adding background music to your stream or singing live with an instrumental track.

Power Options

All three AMS interfaces can be powered from your PC or Mac via USB-C. Use external power when working from a tablet or mobile phone.

Plug it in...

Use the AMS Series on any device thanks to its support for Mac and PC, along with iOS and Android devices.

...And perform

The AMS Series is designed to integrate seamlessly with commonly used software, apps and platforms.

In Streaming mode, connect with your audience by streaming to popular platforms like YouTube, Facebook, Twitch, Instagram and Patreon.

In Music mode, record with software like Adobe Audition, Pro Tools, Cubase and GarageBand.

What's in the box

AMS-22 USB Audio Interface
USB-C Cable
Quick Tour

Technical Specifications

Input and Output Channels

Number of input channels - Mono (MIC/GUITAR): 1
Stereo (LINE IN): 1
Number of output channels - Stereo (TRS): 1
Stereo (PHONES): 1

Connectors

MIC/GUITAR - Type: XLR/TRS combo jack
(XLR: 2 HOT, TRS: TIP HOT)
Input Gain: +8 - +54 dB (MIC) / +8 - +54 dB (GUITAR)
Input impedance: XLR: 2 kO (MIC)
TS: 1 MO (GUITAR)
Maximum input level: XLR: +0.6 dBu (MIC)
TS: +11 dBu (GUITAR)
Phantom power: +48 V

OUTPUT (standard phone jacks - Type: TRS phone jacks (impedance balanced)
Maximum output level: -2 dBu (at 0 dBFS)
Output impedance: 100 O
OUTPUT (headphone jack) - Type: 3.5mm stereo mini jack
20 mW + 20 mW (32 O load)
Output impedance: 10 O
USB: USB Type-C (audio interface function)
Use a USB cable that supports data transfer. USB bus power is supported.
DC 5V: USB Type-C (for power supply)
LINE IN Type: 3.5mm stereo mini jack
Input impedance: 20 kO
Maximum input level: +1.5 dBu
Frequency Response: 44.1 kHz: +0/-2 dB (20 Hz - 20 kHz) - 96 kHz: +0/-3 dB (20 Hz - 40 kHz)
Equivalent Input Noise: -120 dBu or less (IHF-A) at +54dB/150O input

Audio Interface

Input and output channels: Recording: 2 channels
Playback: 2 channels
Sampling frequencies: 96 kHz, 88.2 kHz, 48 kHz, 44.1 kHz
Bit Depth: 24-bit
Interface: USB 2.0
Class: USB Audio Class 2.0

Power: AC adapter (ZOOM AD-17): DC 5 V/1A - USB bus power is supported.
Rated Current: USB bus power / DC 5 V power supply: 170 mA
Power Consumption: 1.8 W maximum
Dimensions: 68.0 mm (W) × 57.7 mm (D) × 46.0 mm (H)
Weight (unit only): 85 g
Note: 0 dBu = 0.775 Vrms

Notes: AMS-24 - For One or More Musicians

Flip the switch

The AMS-24 and AMS-44 feature our innovative Music / Streaming Switch.

When switched to Music mode, you can record into your DAW with expanded input and output routing options.

When switched to Streaming mode, all inputs are combined into a single signal so you can easily stream without needing additional complicated software.

Record & stream with ease

AMS Audio Interfaces are designed for musicians who want to record music with their DAW or easily livestream on platforms like YouTube and Twitch, without all the typical complications.

AMS-24 | 2-In, 4-Out

The AMS-24 is perfect for solo streams and multi-instrument sessions. It features two XLR/TRS combo inputs along with Zoom's low-noise preamps. Also included are two headphone outputs and two TRS outputs for external monitors.

Quick control

With their onboard hardware switches, the AMS-24 and AMS-44 are designed to simplify common streaming challenges without the need for additional software.

Little switch, big streams

Toggle from recording to livestreaming with the Music / Streaming Switch. When in Music mode, each input acts independently with individual gain control. It also sends separate mixes to each headphone output.

When in Streaming mode all inputs are combined into one signal to work seamlessly with your streaming software.

Onboard monitoring

Use the Direct Monitor Switch to send the input signal directly to your headphones while routing the same signal to your DAW or streaming software.

Loop it back

The Loopback Switch combines the input audio with playback from your computer and routes it to your streaming software. This is perfect for adding background music to your stream or singing live with an instrumental track.

Mic/line guitar

Switch Input 1 from mic or line level to guitar level (Hi-Z).

Stereo link

Links two inputs for stereo recording or streaming and allows you to control both inputs with one gain knob.

Phantom power

Provides +48V phantom power for condenser microphones.

Power options

All three AMS interfaces can be powered from your PC or Mac via USB-C. Use external power when working from a tablet or mobile phone.
Additionally, the AMS-24 can also use two AA batteries.

Plug it in...

Use the AMS Series on any device thanks to its support for Mac and PC, along with iOS and Android devices.

...And perform

The AMS Series is designed to integrate seamlessly with commonly used software, apps and platforms.

In Streaming mode, connect with your audience by streaming to popular platforms like YouTube, Facebook, Twitch, Instagram and Patreon.

In Music mode, record with software like Adobe Audition, Pro Tools, Cubase and GarageBand.

What's in the box

AMS-24 USB Audio Interface
USB-C Cable
Quick Tour

Technical Specifications

Input and Output Channels

Number of input channels: Mono (MIC/LINE): 2
Number of output channels: Stereo (TRS): 1
Stereo (PHONES): 2

Connectors

Input 1-2 - Type: XLR/TRS combo jacks
(XLR: 2 HOT, TRS: TIP HOT)
Input gain: -8 - +58 dB / -8 - +50 dB (when set to GUITAR)
Input impedance: XLR: 2.7 kO
TRS: 18 kO / 330 kO (when set to GUITAR)
Maximum input level: XLR: +6 dBu
TRS: +22 dBu / +8.5 dBu (when set to GUITAR)
Phantom: +48 V

OUTPUT A (standard phone jacks)
Type: TRS phone jacks (impedance balanced)
Maximum output level: +10 dBu (at 0 dBFS)
Output impedance: 100 O

OUTPUT A-B (headphone jacks) - Type: 3.5mm stereo mini jacks
30 mW + 30 mW (32 O load)
Output impedance: 10 O

USB: USB Type-C (audio interface function)
Use a USB cable that supports data transfer. USB bus power is supported.
DC 5V - USB Type-C (for power supply)

Frequency Response

44.1 kHz: 1 dB (20 Hz - 20 kHz)
96 kHz: 1.5 dB (20 Hz - 40 kHz)
Equivalent Input Noise: -120 dBu or less (IHF-A) at +58dB/150O input

Audio Interface
Input and output channels
Recording: 2 channels
Playback: 4 channels
Sampling frequencies: 96 kHz, 88.2 kHz, 48 kHz, 44.1 kHz
Bit depth 24-bit
Interface: USB 2.0
Class: USB Audio Class 2.0

Power:
2 AA batteries (alkaline, lithium, or rechargeable NiMH)
AC adapter (ZOOM AD-17): DC 5 V/1A
USB bus power is supported.
Rated Current
USB/AC adapter (5 V): 380 mA
Batteries (2.4 V): 470 mA

Estimated continuous operation time using batteries
44.1 kHz, 48 V off, with 32O headphone load
Alkaline batteries: about 4 hours
NiMH batteries (1900 mAh): about 5.5 hours
Lithium batteries: about 11 hours
The above values are approximate. Continuous battery operation times were determined using in-house testing methods. They could vary greatly according to use conditions.
Power Consumption: 5 W maximum

Dimensions: 94.5 mm (W) × 74.0 mm (D) × 46.0 mm (H)
Weight (unit only): 134 g
Weight (including batteries): 180 g

Notes: Great value little 4-in/4-out interface, designed for portability when making music or streaming. Dual headphone outputs and four XLR/TRS combo inputs with pre-amps give you plenty of versatility.

Supplier's Notes:
AMS-44 For One or More Musicians

AMS-44 | 4-In, 4-Out

Whether you're recording or streaming, the AMS-44 keeps your setup simple. It features four XLR/TRS combo inputs along with Zoom's high-performance, low-noise preamps. The interface also includes two headphone outputs and two TRS outputs for external monitors.

Quick control

With their onboard hardware switches, the AMS-24 and AMS-44 are designed to simplify common streaming challenges without the need for additional software.

Little switch, big Streams

Toggle from recording to livestreaming with the Music / Streaming Switch. When in Music mode, each input acts independently with individual gain control. It also sends separate mixes to each headphone output.

When in Streaming mode all inputs are combined into one signal to work seamlessly with your streaming software.

Onboard monitoring

Use the Direct Monitor Switch to send the input signal directly to your headphones while routing the same signal to your DAW or streaming software.

Loop it back

The Loopback Switch combines the input audio with playback from your computer and routes it to your streaming software. This is perfect for adding background music to your stream or singing live with an instrumental track.

Mic/line guitar

Switch Input 1 from mic or line level to guitar level (Hi-Z).

Stereo link

Links two inputs for stereo recording or streaming and allows you to control both inputs with one gain knob.

Phantom power

Provides +48V phantom power for condenser microphones.

Power options

All three AMS interfaces can be powered from your PC or Mac via USB-C. Use external power when working from a tablet or mobile phone.

Additionally, the AMS-24 and AMS-44 can also use two AA batteries.

Plug it in...

Use the AMS Series on any device thanks to its support for Mac and PC, along with iOS and Android devices.

...And perform

The AMS Series is designed to integrate seamlessly with commonly used software, apps and platforms.

In Streaming mode, connect with your audience by streaming to popular platforms like YouTube, Facebook, Twitch, Instagram and Patreon.

In Music mode, record with software like Adobe Audition, Pro Tools, Cubase and GarageBand.

What's in the box

AMS-44 USB Audio Interface
USB-C Cable
Quick Tour

Technical Specification

Input and Output Channels
Number of input channels: Mono (MIC/LINE): 4
Number of output channels: Stereo (TRS): 1
Stereo (PHONES): 2

Connectors

INPUT 1-4 - Type: XLR/TRS combo jacks
(XLR: 2 HOT, TRS: TIP HOT) Input gain: -8 - +58 dB / -8 - +50 dB (when set to GUITAR)
Input impedance: XLR: 2.7 kO
TRS: 18 kO / 330 kO (when set to GUITAR)
Maximum input level: XLR: +6 dBu
TRS: +22 dBu / +8.5 dBu (when set to GUITAR)
Phantom power: +48 V
OUTPUT A (standard phone jacks)
Type: TRS phone jacks (impedance balanced)
Maximum output level: +10 dBu (at 0 dBFS)
Output impedance: 100 O
OUTPUT A-B (headphone jacks): Type: 3.5mm stereo mini jacks - 30 mW + 30 mW (32 O load)
Output impedance: 10 O
USB: USB Type-C (audio interface function)
Use a USB cable that supports data transfer. USB bus power is supported.
DC 5V: USB Type-C (for power supply)
Frequency Response: 44.1 kHz: 1 dB (20 Hz - 20 kHz) - 96 kHz: 1.5 dB (20 Hz - 40 kHz)
Equivalent input noise: -120 dBu or less (IHF-A) at +58 dB/150O input

Audio interface

Input and output channels: Recording: 4 channels
Playback: 4 channels
Sampling frequencies: 96 kHz, 88.2 kHz, 48 kHz, 44.1 kHz
Bit depth: 24-bit
Interface: USB 2.0
Class: USB Audio Class 2.0

Power

2 AA batteries (alkaline, lithium, or rechargeable NiMH), AC adapter (ZOOM AD-17): DC 5 V/1 A -USB bus power is supported.
Rated Current
USB/AC adapter (5 V): 350 mA
Batteries (2.4 V): 560 mA
Estimated continuous operation time using batteries
44.1 kHz, 48 V off, with 32O headphone load
Alkaline batteries: about 3 hours
NiMH batteries (1900 mAh): about 4.5 hours
Lithium batteries: about 8.5 hours
The above values are approximate. Continuous battery operation times were determined using in-house testing methods. They could vary greatly according to use conditions.
Power Consumption: 5 W maximum

Dimensions: 129.0 mm (W) × 74.0 mm (D) × 46.0 mm (H)
Weight (unit only): 177 g
Weight (including batteries): 223 g

Notes: With its novel microphone capsule and 32-bit float technology, the M2 MicTrak enables any user to make very good-sounding recordings in one take.

X/Y microphone with honeycomb protective grille
2-track recording (mono/stereo)
Monochrome LCD display (waveform display)
2x AA battery operation (up to 11 hours)
32-bit float USB mic function for Mac/Windows and iOS/Android
Improved coating to reduce grip noise during recording

Best possible results - guaranteed

The M2 MicTrak is Zoom's latest innovation in mobile recording. Featuring a new X/Y microphone capsule design and 32-bit float technology, the M2 delivers great sound from the first take.

One take - that's all you need

The M2 records clipping-free audio always. Thanks to 32-bit float recording, there's no need for leveling. Whether you're recording softly spoken dialogue or thundering drums, you'll always get the sound you want.

Podcasting, no matter where

When you're on the road, you need no other recorder than the M2 to deliver high-resolution, transparent stereo voice recordings anytime.

For breaking news, there's only one take

When there's only one opportunity to record the story, the M2 won't let you down.

Extremely quiet grip noise

Combined with the specially designed high-gloss finish, the M2's unique, resiliently suspended X/Y stereo microphones ensure that hand noise is drastically minimised.

Stereo and mono modes

Record in either mono or stereo mode. Stereo is recommended for music performances, while mono is the perfect choice for recording interviews and dialogue.

Normalize function

The M2 offers a NORMALIZE function that allows you to optimise the levels of your recordings by raising or lowering the volume. This saves time and makes the post-production process more efficient.

Always in sight

Thanks to the real-time waveform display on the M2's LCD screen, you can always keep an eye on your recordings.

Always in control

Use the headphone output to listen to your recordings or use the internal speaker for quick reference.

USB microphone with 32-bit float

Connect the M2 via USB to record and stream with a PC, Mac or in iOS or Android.

Integrated microphone mount

For stationary recording, mount the Zoom M2 on a microphone stand using the supplied microphone holder.

Long battery life

Up to 11 hours of battery life via Type AA batteries, securely housed via a new locking system, ensures the M2 is always ready to record when you need it.

Tech Specs

USB-C port (2.0)
USB bus power supported
Recording media
4GB-32GB microSDHC cards
64GB-1TB microSDXC cards
Built-in speaker
Headphone jack
Recording format: 44.1/48/96kHz, 32-bit float (48kHz in Audio Interface Mode), mono/stereo BWF and iXML

Whats in the box
Quick Guide
Windscreen
Microphone clamp

Optional power supply
Zoom AD-17

Notes: The new lightweight stereo in-camera recorder that records in 32-bit float to ensure perfectly modulated audio on every recording. The M3 has a line output to send audio directly to the camera input and has a selectable mono/90-/120- recording pattern.

Stereo shotgun microphone with stereo recorder
High level stability (133dB SPL)
Support for mid-side (M/S) raw recording
Shock mount for camera included
REC/ PLAY button and mono/90/120
2xAA battery operation (up to 12 hours)
Perfect sound with every picture. In one take.

The M3 MicTrak offers filmmakers the ability to enhance their content with pristine sound quality. Designed to be mounted on a camera, the stereo microphone with built-in recorder records every sonic nuance with 32-bit float technology.

32-bit float recording

The M3 records clipping-free audio at all times. Thanks to 32-bit float recording, no equalisation is necessary. Whether it's dialogue, sound effects or ambience in outdoor recordings, you'll always get a perfect recording.

Absolutely ready at all times

The specially designed elastic mount keeps weight to a minimum and ensures minimal transmission of handheld noise.

Mono and stereo modes

Switch easily between mono and stereo modes. Mono mode is ideal for dialogue recording. 90O provides accurate, transparent stereo recording. 120O stands for a generous stereo pick-up, which is especially recommended for atmosphere or sound effects.

More flexibility in post-production

The M3 saves a backup file in mid-side RAW format at any time, giving you the flexibility to adjust the stereo width of the recording in post-production.

Backup for your recordings

Use the 3.5mm stereo output to connect the M3 to your camera and record a backup there. This is especially useful for synchronising audio to a video.

Effectiveness in post-production

With the M3 Edit and Play software, you can adjust the stereo width of your recordings and normalise your files to prepare them for dubbing and post-production.

USB Mic

Connect the USB-C port to a PC or Mac to use the M3 as a USB microphone for streaming or recording.

Monitoring

Listen to your recordings via the 3.5mm headphone output.

Power supply

Power the M3 on long production days with up to 12 hours of recording from two Type AA batteries.

Storage

Record onto SDXC cards with a capacity of up to 1 TB.

Tech specs
USB-C connector (2.0)
USB bus power supported
Recording media
4GB-32GB microSDHC cards
64GB-1TB microSDXC cards
Headphone jack
12 hours battery life
Recording format: 44.1/48kHz, 32-bit float (48kHz in audio interface mode), mono/stereo BWF and iXML

Whats in the box

Quick Guide
Windscreen
3.5 mm mini-jack coiled cable
Elastic microphone holder

Notes: Top quality recordings anywhere you want from Zoom's smartly designed M4, incorporating a 32-bit recording unit into a microphone format. Built-in timecode generator makes life easy for filmmakers.

Supplier's Notes:
The first portable recorder to feature both 32-bit recording and a built-in timecode generator for easy synchronisation with video. This innovative and compact recorder offers 4 tracks and is the perfect solution for musicians and filmmakers.

X/Y microphone with honeycomb protective grille
4-track recording (L+R and 2 XLR/combo inputs)
Colour LCD display (waveform display)
Time code generator (in-out) for synchronisation with video applications
4x AA battery operation (up to 18 hours)
32-bit float USB mic function for Mac/Windows and iOS/Android
Improved coating to reduce grip noise during recording

Perfect tracks. In one take.

The M4 MicTrak is the first portable recorder with 32-bit float recording and built-in timecode generator, providing everything filmmakers and musicians need for outstanding audio recording.

Audio without clipping

On set, you can't risk working with audio that is overdriven or too quiet. The M4 records with 32-bit float, which allows you to record audio perfectly in any situation, even without clipping.

Attention... And... Action!

Filmmakers can use the two XLR inputs to record dialogue, while you record atmosphere via the X/Y microphones. In post-production, the M4's built-in timecode generator makes it easy to synchronise recordings to a video.

Create great sounding music videos

Combine the audio recorded with the internal X/Y microphones with two external microphones to give your videos studio-quality sound regardless of the environment.

Wav-watching
Keep track of your tracks at all times via the M4's proprietary colour LCD display with real-time waveform display.

Extremely low hand noise

The goal in designing the M4 was to create the quietest handheld recorder ever. The unique, resiliently suspended X/Y microphones and high-gloss finish minimise hand noise, ensuring clean, clear audio at all times.

Timecode on board

Serious videographers use timecode to perfectly synchronise audio and video. The M4's built-in timecode generator provides professional accuracy of 0.2 ppm.

Powerful inputs

The M4 features two XLR/TRS inputs equipped with the same professional, low-noise preamps as the flagship F-Series recorders.

Perfect outputs

Connect the line output to your camera to record a backup or sync track to your video. Listen to recordings via the built-in headphone output.

Normalisation in one step

Save time in post-production by automatically raising or lowering the volume of your recordings to the optimum level, even without audio compression, using the built-in NORMALIZE function.

Listening options

Use the headphone output to listen to your recording, or use the built-in speaker for quick reference playback.

Six seconds for safety

The PRERECORD function captures and stores audio six seconds at a time before you press the RECORD button - perfect for any surprise recording start.

Record all day

With 18 hours of battery life, the M4 can record all day if needed.

RC4 remote control

Control your M4 from up to 5 metres away using the Zoom RC4 (sold separately).

32-bit float audio interface

The M4 can be used as an audio interface with 32-bit float technology and 4 inputs and 2 outputs.

Tech Specs

USB-C connector (2.0)
USB bus power supported
2x XLR/jack combo sockets with 48V phantom power
Recording media
4GB-32GB microSDHC cards
64GB-1TB microSDXC cards
Built-in loudspeaker
Headphone jack
Line-out
Time code in/out
Connection for Zoom RC4 remote control (not included)
Recording format: 44.1/47.952/48/48.048/96/192kHz (48kHz in audio interface mode), 32-bit float mono/stereo BWF and iXML

Whats in the box

Quick Guide
Windscreen

Optional accessories

Power supply Zoom AD-17
Zoom RC4 remote control

Notes: The Zoom G2 Four is a compact, easy-to-use multi-effects processor that offers a huge range of sounds with new amp modelling, multi-layer IR technology and over 100 effects:

Features

22 amp/cabinet models with newly developed multi-layer IR technology
79 guitar effects including boutique pedal modelling
Use of up to 7 effects simultaneously
250 preloaded patches with sounds that recreate guitar sounds from the 50s to today
300 patch memories in total
Additional effects/patches can be installed, edited and saved via the Handy Guitar Lab app for iOS and Android.
An external expression pedal can be used to control effects such as volume, pitch and wah in real time
Lightweight and compact design that fits in the pocket of your guitar case
80-second looper function
68 rhythm patterns that can be played in sync with the looper
Output EQ for quick adjustment of the overall sound to the playing environment
AUX IN jack for connecting a music player, etc.
Autosave function that automatically saves effect settings
Tuner function that supports open tuning and drop tuning
USB connection for Handy Guitar Lab, 2-in/2-out audio interface and firmware updates
Can be powered via USB bus (computer or power bank) or via the supplied AC adapter (AD-16)

Sounds without end

Using all-new amp modelling and innovative IR technologies, the Zoom G2 Four gives guitarists more sound variations to choose from than ever before. You can create amazing sounds right out of the box.

Comprehensive amp models

Zoom G2 Four takes amp modelling to the next level. Carefully recreated emulations of classic amps are combined with speaker simulations using our new multi-layer IR technology. As a result, guitarists benefit from great sounds and always have the feeling of being on the "big stage", regardless of the environment.

Multi-layer IR

Each amp model is based on Zoom's innovative Multi-Layer IRs, which capture the sound characteristics as well as the feel of classic amps and speaker cabinets. These IRs have been sampled at three volume levels through legendary cabinets and can be crossfaded and activated depending on the volume of your guitar.

Historic guitar sounds

Preloaded in the form of 250 presets, these patches were designed to document the sonic evolution of guitar sound. Each patch recreates the sound of a legendary song from the 1950s to the present day.

Brimming with effects

The internal patches include over 100 effects, recreating a wide range of traditional and boutique sounds, from classic spring reverbs to extreme distortion and modulation effects to wah-wah and more. Mix and match up to 7 effects to create your own patches.

Controls

Zoom's new cross-key navigation concept helps you control the pedal with just your feet and make adjustments on the fly. In addition, four endless knobs allow you to quickly adjust effect parameters as well as output settings.

Programming

The redesigned control surface makes it even easier to edit effect parameters, rearrange effect chains, and access the looper and tuner.

The perfect addition to your pedalboard
The G2 Four's compact design and diverse effects selection make it a powerful addition to any existing pedalboard.

Optimised for amps, monitor speakers and headphones
The G2 Four is designed to connect to guitar amps, studio monitors, PAs and headphones. After switching on, you set up the G2 Four perfectly for your setup by selecting between LINE and AMP.

Looper

Use the built-in 80-second looper for songwriting or enhance your performance with additional sound layers.

Play to the beat

Play along to any of the 68 beats on the built-in rhythm machine. This rhythm section is the perfect accompaniment when practising, whether it's metal, blues or any other genre.

Audio interface

Record at home or in the studio with your favourite effects and amp models by connecting the G2 Four to your computer via USB-C.

Guitar lab

Thanks to the ever-growing library of patches and effects, every guitarist can expand their sound selection via the Guitar Lab app (for iOS / Android).

Notes: The Zoom G2x Four is a compact, easy-to-use multi-effects processor that offers a huge range of sounds with new amp modelling, multi-layer IR technology and over 100 effects:

Features

22 amp/cabinet models with newly developed multi-layer IR technology
79 guitar effects including boutique pedal modelling
Use of up to 7 effects simultaneously
250 preloaded patches with sounds that recreate guitar sounds from the 50s to today
300 patch memories in total
Additional effects/patches can be installed, edited and saved via the Handy Guitar Lab app for iOS and Android.
Expression pedal lets you control effects such as volume, pitch and wah in real time
Lightweight and compact design that fits in the pocket of your guitar case
80-second looper function
68 rhythm patterns that can be played in sync with the looper
Output EQ for quick adjustment of the overall sound to the playing environment
AUX IN jack for connecting a music player, etc.
Autosave function that automatically saves effect settings
Tuner function that supports open tuning and drop tuning
USB connection for Handy Guitar Lab, 2-in/2-out audio interface and firmware updates
Can be powered via USB bus (computer or power bank) or via the supplied AC adapter (AD-16)

Sounds without end

Using all-new amp modelling and innovative IR technologies, the Zoom G2X Four gives guitarists more sound variations to choose from than ever before. You can create amazing sounds right out of the box.

Comprehensive amp models

The G2X Four takes amp modelling to the next level. Carefully recreated emulations of classic amps are combined with speaker simulations using our new multi-layer IR technology. As a result, guitarists benefit from great sounds and always have the feeling of being on the "big stage", regardless of the environment.

Multi-layer IR

Each amp model is based on Zoom's innovative Multi-Layer IRs, which capture the sound characteristics as well as the feel of classic amps and speaker cabinets. These IRs have been miked at three volume levels through legendary cabinets and can be crossfaded and activated depending on the volume of your guitar.

Historical guitar sounds

Preloaded in the form of 250 presets, these patches were designed to document the sonic evolution of guitar sound. Each patch recreates the sound of a legendary song from the 1950s to the present day.

Brimming with effects

The internal patches include over 100 effects, recreating a wide range of traditional and boutique sounds, from classic spring reverbs to extreme distortion and modulation effects to wah-wah and more. Mix and match up to 7 effects to create your own patches.

Controls

Zoom's new cross-key navigation concept helps you control the pedal with just your feet and make adjustments on the fly. In addition, four endless knobs allow you to quickly adjust effect parameters as well as output settings.

Programming

The redesigned control surface makes it even easier to edit effect parameters, rearrange effect chains, and access the looper and tuner.

The perfect addition to your pedalboard
The G2X Four's compact design and diverse effects selection make it a powerful addition to any existing pedalboard.

Optimised for amps, monitor speakers and headphones

The G2X Four is designed to connect to guitar amps, studio monitors, PAs and headphones. After switching on, set up the G2X Four perfectly for your setup by selecting between LINE and AMP.

Looper

Use the built-in 80-second looper for songwriting or enhance your performance with additional sound layers.

Play to the beat

Play along to any of the 68 beats on the built-in rhythm machine. This rhythm section is the perfect accompaniment when practising, whether it's metal, blues or any other genre.

Express yourself

The G2X Four features an expression pedal for controlling volume, wah-wah and more.

Audio interface

Record at home or in the studio with your favourite effects and amp models by connecting the G2X Four to your computer via USB-C.

Guitar lab

Thanks to the ever-growing library of patches and effects, every guitarist can expand their sound selection via the Guitar Lab app (for iOS / Android).

Notes: Great value from this compact, portable multi-track recorder. Record instruments or vocals anywhere. Pre-loaded drum loops and built-in synth instruments help you get started.

Supplier's Notes:
The R12 Multitrak - Live to make music.

The R12 is made for musicians who live to make music. And they want the freedom to make music wherever they go.

All you need on-board

Compact and mobile, you can record and mix songs without a computer. Use the R12's full-colour LCD touchscreen to cut, copy, loop, and edit your tracks.

Amazing sound

The R12 has super-clean preamps and you'll love the way they sound. With two XLR/TRS inputs, and 8 tracks of audio, the R12 is perfect for recording everything from demos to release-ready songs.

Fully loaded

The R12 includes a send effects channel offering reverb, chorus and delay with a ddedicated effects return fader. For advanced tones, you can use presets and effects from Zoom's Guitar Lab.

Take it everywhere

The R12 provides up to 5 hours on four AA batteries allowing you to bring your production anywhere. Additionally, you can use the R12 with the included AD-17 power adapter, or a USB battery.

The R12 also has pan and a 3-channel EQ for each track and a compressor on inputs 1 and 2.

Playback. Play along.

Use Sequence Play to create a playlist of your projects. Then use them as backing tracks, whether you're playing live or rehearsing a set.

It starts with a groove

With 150 preloaded drum loops in a variety of patterns and genres, the R12 provides a versatile rhythm section for any project.

Import audio files

Add additional audio samples by importing files into your R12 via Micro SD card or USB thumb drive.

From headphones to monitors

The R12 includes an 1/8" stereo headphone jack as well as dedicated 14" monitor outputs.

Interface + control surface

Use the R12 as a stereo audio interface with your favorite DAW or streaming platform, via USB-C. As a control surface, the transport controls and faders make it easy to adjust and control your software during production.

Attention to detail

Connections

Connect microphones, instruments or line level devices like keyboards, mixers and more.

Hi-Z

Input 1 on the R12 has a Hi-Z switch, allowing you to plug your guitar directly into the recorder.

Phantom Power

Both inputs on the R12 offer 48V Phantom Power for condenser microphones.

Stay in time. Every time.

Activate the fully customizable click track with the press of a button. Click balance blends the metronome with your playback audio and routes it to your headphones and/or the main outputs.

Add some synth

The R12 has 18 FM synth instruments built in. They can be played by plugging in a MIDI keyboard via USB-C or programmed using the touchscreen.

What's in the box:
R12 MultiTrak
AD-17 AC Adapter
USB Cable

Specs

INPUTS / OUTPUTS
INPUTS - MIC/LINE (mono): 2
OUTPUTS - MASTER OUT: 1
PHONES: 1

INPUTS
MIC/LINE (MONO) Connectors: 2 XLR/TRS combo jacks (Balanced, XLR: 2 HOT / TRS: TIP HOT)
Input gain: +6 ~ +50 dB
Input impedance: XLR: 3.9 kO TRS: 3.9 kO/1 MO (when Hi-Z ON, INPUT 1 only)
Phantom power: +48 V (switchable separately for INPUTS 1 and 2)
Equivalent input noise: -121 dBu or less (IHF-A) at +50 dB/150 O input
Frequency response: -1.0/+0.5 dB: 20 Hz - 20 kHz

OUTPUTS
MASTER OUT - Connectors: 2 TRS phone jacks (balanced)
Maximum output level: +14 dBu
Output impedance: 200 O
PHONES Connectors: 1 stereo 3.5mm mini jack
Maximum output level: 45 mW + 45 mW (into 32 O load)
Output impedance: 10 O

RECORDER
Maximum simultaneous recording tracks: 2
Maximum simultaneous playback tracks: 8
Recording format: 44.1kHz, 16/24-bit, mono/stereo WAV
Recording media: Cards compatible with microSDHC specifications 4 GB - 32 GB

TRACK SETTINGS
EQ
High: 10 kHz, 12 dB, shelving
Middle: 2.5 kHz, 12 dB, peaking
Low: 100 Hz, 2 dB, shelving
Pan: L100 - R100

EFFECTS
Input Dynamics: Comp/Limiter/Gate
Patch memory effects: 3 types can be used simultaneously
50 patch memories
Guitar Lab supported
Can be assigned and used as an insert (input) or send effect
Dedicated send effects: 10 types of spatial effects

TUNER: Chromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGAD

CLICK (METRONOME)
Time signatures: 3/4, 4/4, 6/8
Tempo range: 40.0 - 250.0 BPM

POWER
Batteries: 4 AA (alkaline, lithium, or rechargeable NiMH)
AC adapter: ZOOM AD-17 (5V/1.0A)

RHYTHM LOOPS
Sound source format: PCM
Number of loops: 150

SYNTH
Sound source format: FM
Polyphony: 8
Number of sound types: 18 (and a PCM drum kit)

DISPLAY: 2.4" (320×240) full-color touchscreen LCD

USB
CONNECTOR: USB Type-C
Note: Use a USB cable that supports data transfer. USB bus power is supported.

AUDIO INTERFACE FUNCTION:
2-in/2-out or 2-in/2-out (iPad): USB 2.0 Full Speed - 44.1 kHz, 16/24-bit
2-in/4-out: USB 2.0 High Speed - 44.1 kHz, 16/24-bit

MASS STORAGE FUNCTION
Device: USB 2.0 High Speed (5 V/200 mA power supplied when host)
GUITAR LAB CONNECTION: USB 1.1 Full Speed
DAW CONNECTION (CONTROL SURFACE): USB 1.1 Full Speed

MASS STORAGE FUNCTION
Host: USB 2.0 High Speed (5V/200 mA power supplied)

USB MIDI KEYBOARD CONNECTION: USB 1.1 Full Speed (5 V/200 mA power supplied)

ESTIMATED CONTINUOUS OPERATION TIME USING BATTERIES
During playback with +48V off and 32O headphone load
Alkaline batteries: about 5 hours
NiMH batteries (1900 mAh): about 5 hours
Lithium batteries: about 11 hours
* The above values are approximate. Continuous battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.

POWER CONSUMPTION: 5 W maximum
DIMENSIONS: 256 mm (W) × 158 mm (D) × 61 mm (H)
WEIGHT (including batteries): 827 g
NOTE: 0 DBU = 0.775 VRMS

Notes: Representing a new generation of portable recording, the H2n is Zoom's most innovative handheld recorder to date. Zoom have packed groundbreaking features into an ultra-portable device that allows you to record pristine audio anywhere you go. From film and broadcast, to journalism, podcasting, musical performance, songwriting and rehearsal, the H2n provides amazing recording quality. No matter the application, the H2n brings the very best in stereo recording to a convenient, user-friendly package that fits in your pocket.

The H2n's onboard 90- X/Y stereo condenser mics are arranged with the right and left mics on the same axis. This design ensures that the mics are always equidistant from the sound source for perfect localization and no phase shifting. The result is brilliant stereo recording with natural depth and accurate imaging.

The H2n features Zoom's best microphones yet and is the only portable recorder with five mic capsules onboard. This design enables the H2n to offer four unique recording modes: Mid-Side (MS) stereo, 90- X/Y stereo, 2-channel and 4-channel surround sound.

The Zoom H2n Handy Recorder, the new standard in portable recording.

Notes: The Zoom F6 is the first professional field recorder to feature both 32-bit float recording and dual AD converters, providing an unprecedented amount of dynamic range. With 6 inputs, Zoom's solid time code, multiple power options and wireless control, the F6 is poised to be your new secret weapon.

32-Bit Float Recording:
In the field, fluctuating dynamics can prove challenging. Loud sounds can cause clipping and quiet sounds can get lost in the noise. The F6 uses 32-bit float recording with dual A/D converters to capture both explosive and subtle sounds at full audio quality - without ever adjusting gain!

For Those Hard to Reach Places:
Rugged enough to withstand the most demanding scenarios and small enough to fit into the tightest spaces, the F6 will become your go-to recorder.

Mic Preamps:
The F6 is equipped with six professional-grade preamps. Featuring a super-low noise floor (-127 dBu EIN), high gain (up to 75 dB), and selectable mic/line levels for each input, the F6 is built for location sound.

Precision Time Code:
Keep your tracks perfectly synced even when you power down for lunch. On or off, the F6's Temperature Compensated Crystal Oscillator (TCXO) generates time code at 0.2 ppm accuracy.

Advanced Look-Ahead Hybrid Limiters:
When recording in 24-bit, the F6 uses advanced look-ahead hybrid limiters to provide overload protection. By adding a 1-millisecond delay, the limiters "look ahead" anticipating clipping before it's recorded.

Zoom AutoMix:
Zoom AutoMix lets you keep your eyes on the action by automatically adjusting the levels of your mix to reduce ambient sound.

What's included with the F6:

- F6 Field Recorder
- Camera mount adapter
- AA batteries (x4)
- Cubase LE and WaveLab LE download codes
- Quick Start Guide

Notes: Portable recording made with musicians in mind, the R4 records up to four tracks in 32-bit float resolution, with on-board EQ and effects, amp simulation and the option to bounce recordings down then overdub.

Supplier's Notes:
The Little Recorder For Big Ideas

Introducing the Zoom R4 MultiTrak

Designed By Musicians

All of our engineers are musicians and they designed the R4 to empower musicians to explore big ideas. With a unique dedicated 'bounce track' and 32-bit float recording, the R4 is perfect for capturing your most ambitious compositions.

Record. Bounce. Repeat.

With the R4, you can record up to four tracks, mix and then bounce them to the dedicated 'bounce track.' This lets you free up additional tracks to keep adding layers.

You can choose to do a 'quick' bounce or mix and bounce in real time.

The R4 also allows you to 'undo' your last bounce, if you're not satisfied with the results.

32-Bit Float Recording

The R4 captures perfect audio with every take, without the need to set gain.

Combo Inputs

The R4 has 2 XLR/TS combo inputs with legendary Zoom preamps. You can plug in microphones, instruments, keyboards, and more.

Track Effects

Each track features a 3-band EQ, pan, echo, and reverb to refine your mix.

Input Effects

Apply effects to input A such as amp simulations, delays, distortions and more.

Built-In Microphone

The R4 features a high-quality built-in microphone, perfect for acoustic guitars, vocals, or capturing a quick reference recording.

Much More Than A Metronome

The R4 has a rhythm section preloaded with over 80 different drum patterns to play along with featuring genres such as rock, hip hop, funk, heavy metal, and more.

Every Take Is Saved

Tracks that you record are automatically saved individually, even after they have been bounced.

32-Bit Float Audio Interface

The R4 is also a powerful 2-in/ 2-out USB audio interface with 32-bit float technology. Connect it to either your computer or smartphone.

Control and Create

With a fader for each track and dedicated hardware buttons for the most used functions, you won't need to menu dive to record your music.

Powered For Your Ideas

The R4 can be powered by 4 AA Batteries, or through its USB-C port.

Specs

Inputs/outputs
Inputs: Built-in mic (mono): 1
XLR/TS inputs (mono): 2
Output: Headphones: 1

Inputs
XLR/TRS inputs:
Connectors: 2 XLR/TRS combo jacks (Balanced, XLR: 2 HOT)
Input gain: No adjustment required (dual A/D converter circuit used)
Input impedance XLR: 2.3 kO; TS: 1 MO
Maximum input level: XLR: +4 dBu, TS: +10 dBu
Phantom power: +48 V (switchable separately for INPUTS A and B)
Equivalent input noise: XLR: -120 dBu or less (IHF-A); TS: -107 dBu or less (IHF-A)
Frequency response: XLR: -0.5 /+0.0 dB : 20 Hz - 20 kHz; TS: -0.2 /+0.0 dB : 20 Hz - 20 kHz

Built-in mic input
Directionality: Omnidirectional
Input gain: No adjustment required (dual A/D converter circuit used)
Maximum sound pressure input:
115 dB SPL
Output

Headphone

Connector: 1 stereo 3.5mm mini jack
Output impedance: 10 O
Maximum output level: 20 mW + 20 mW (into 32O load)

Recorder

Maximum simultaneous recording tracks: 2
Recording format: WAV: 48kHz, 32-bit float, mono
Recording media: Cards compatible with microSDHC specifications 4 GB - 32 GB; Cards compatible with microSDXC specifications 64 GB - 1 TB

Display: 2" full-colour LCD (240 × 320)

USB

Connector: USB Type-C
Note: Use a USB cable that supports data transfer. USB bus power is supported.
Audio interface function
Class: USB 2.0 High Speed
Sampling frequency: 48 kHz
Bit rate: 24-bit/32-bit float
Input / output channels: 2 in/2 out
Mass storage function: USB2.0 High Speed

Power supply

Batteries: 4 AA (alkaline, lithium, or rechargeable NiMH)
AC adapter: ZOOM AD-17 (5V/1.0A)
* USB bus power is supported.
Estimated continuous operation time using batteries

Alkaline batteries: about 7 hours
NiMH batteries (1900 mAh): about 6 hours
Lithium batteries: about 14 hours
* Use conditions: Recording 1 track, playing 1 track, phantom power off, headphones into 32O load, power saving on
* The above values are approximate. * Continuous battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.

Power consumption: 5 W
External dimensions: 74 mm (W) × 138 mm (D) × 36 mm (H)
Weight (including batteries): 287 g
Note: 0 dBu = 0.775 Vrms

Notes: The Zoom MS-90LP+ is a versatile stereo looper. With the tap of your foot you can add loops, layers, effects and rhythm patterns. And with 32-bit float processing, the MS-90LP+ gives creators flawless audio quality every time.

Notes: Exceptional value from one of Zoom's entry-level recorders. Quick and easy to set up and use, the H1essential offers excellent stereo sound quality. Records to microSD card, with option to transfer files via USB.

Supplier's Notes:
Zoom H1essential - 32-Bit Float Recording for All

The World's Easiest Recorder, Just Got Easier

With the push of a button the H1essential captures perfect audio for musicians, podcasters, filmmakers, and content creators. Simply hit record and discover the power of 32-bit float.

32-Bit Float Magic

With 32-bit float recording, you never have to adjust levels. The H1essential captures every nuance of your sound ensuring high-quality audio with every take

The First Handy Recorders with Accessibility

The Essential Series was designed with Accessibility for the blind and visually impaired. Navigate the menu with audible descriptions through the built-in speaker or headphones. Creators can choose English, Spanish, French, Japanese, German, Italian or Chinese.

Loud and Clear

The onboard X/Y microphones capture clean audio up to 120 dB SPL, equivalent to the sound of a high-performance engine.

The Perfect Practice Companion for Musicians

Musicians can use the H1essential to record every rehearsal, a great way to improve your playing. Features like overdubbing and playback-speed-adjustment are great for writing and practicing.

Sound Makes the Scene

The H1essential is great for filmmakers. Record and send audio directly to your camera or use it to record sound effects to complete your scene.

For Storytellers

Podcasters can mount the H1essential on a tripod for sit down conversations or use 'mono mode' for on-the-go interviews.

Big Features, Small Package

The H1essential has advanced features such as overdubbing, pre-record, auto record, and playback speed adjustment.

Features

32-bit float recording: perfect audio with no need to set gain
120 dB SPL 90 degree XY Mics
Records up to 96kHZ sample rate
New OLED Display
Overdubbing, auto record, pre-record and timer functions
USB Microphone Function
Audio guidance function for the blind and visually impaired
10 hours of battery life on 2 AAA Batteries or USB-C Bus power

Specs

Inputs

Built-in mic: 90 degree XY stereo format
Directionality: Unidirectional
Sensitivity: -37 dB/1 Pa at 1 kHz
Maximum sound pressure input: 120 dB SPL

MIC/LINE IN jack

Connector: Stereo mini jack
Input impedance: 2 kO or more
Plug-in power: 2.5 V

Built-in mic
90 degree XY stereo format
Directionality: Unidirectional

Outputs

PHONE / LINE OUT jack
Connector: Stereo mini jack
Maximum output level: 20 mW + 20 mW(into 32O load)
Output impedance: 10 O or less
Built-in speaker Type: 20 x 30mm oval dynamic speaker
Practical maximum output: 250mW

Recorder
Recording formats:
WAV
44.1/48/96 kHz, 32-bit Float
Stereo / Mono
BWF and iXML formats supported

Recording media
4-32GB cards compatible with the microSDHC specification
64GB-1TB cards compatible with the microSDXC specification

Display
OLED: 128 x 64

USB
Connector: USB Type-C (Use a USB cable that supports data transfer.)
USB Mic: USB 2.0 High Speed
48 kHz, 24-bit
File transfer: USB 2.0 High Speed

Power

2 AAA batteries Alkaline, Lithium, or Rechargeable NiMH
AC adapter: ZOOM AD-17: DC 5 V/1 A
USB bus power is supported.

Estimated continuous operation time using batteries

Alkaline batteries: About 10 hours
NiMH batteries (800 mAh): About 9 hours
Lithium batteries: About 18 hours
Stereo recording, 48kHz/32-bit float, no headphones, Power Save 1min
These values are approximate.
Continuous battery operation times were determined using in-house testing methods.
They will vary greatly according to use conditions.

Power consumption: 5 W maximum
Dimensions: 53.9 mm (W) × 136.6 mm (D) × 29.0 mm (H)
Weight (including batteries): 92 g
Note: 0 dBu = 0.775 Vrms

Notes: Zoom H4essential Handy Recorder

Four Tracks. More Options

With four tracks, 32-bit float recording, advanced X/Y mics and 2 XLR/TRS inputs, creators have more ways to record their music, podcasts, and audio-for-video.


Features

4-track 32-bit float recorder with Dual A/D Converters
Clip-free recording with no need to set gain
Records up to 96kHZ sample rate
Colour LCD Screen
130 dB SPL XY Mic
2 XLR/TRS combo inputs with locking connector
3.5mm mic/line input for lavalier mics and line level sources
Built-in mixer to adjust each track's audio level
Built-in speaker for quick reference playback
3.5mm line output for headphones or to connect to a camera
Voice Guidance accessibility for the visually impaired
32-Bit Float audio interface for PC, Mac, iOS, and Android devices via USB-C port
Use as an interface and record to SD card simultaneously
Using the BTA-1* Bluetooth Adapter, sync with wireless timecode devices via Bluetooth
Use the BTA-1* Bluetooth Adapter to pair with the H4essential Control App for iOS
Record to SD cads up to 1TB
10 hours of battery life on AA battery (2x) or USB-C Bus Power
*Please note: BTA-1 Adapter not included

Now in colour

The new full-colour LCD screen makes it easy to navigate through the H4essential's menu and functions.

Advanced X/Y mics

The onboard X/Y microphones capture crystal clear audio up to 130 dB SPL.

High capacity storage

The H4essential supports SDXC cards up to 1TB to record hours and hours of audio.

For interview and podcasts

Podcasters can use the H4essential's XLR inputs with external mics for one-on-one conversations and the X/Y mics for interviews on-the-go.

Big stage sound for musicians

The H4essential is perfect for recording music. With 2 XLR/TRS inputs and the stereo X/Y microphones it's easy to record live shows, rehearsals and songs.

Pair with your iOS device

Use the BTA-1* Bluetooth Adapter to pair with your iOS device to remotely hit record, adjust your mix, view your waveforms, and change settings.

Bluetooth timecode

With the BTA-1* Bluetooth Adapter you can also pair with Bluetooth timecode devices for audio and video sync. *BTA-1 Adapter not included

Specifications

Input & output channels

Inputs
Built-in mic (stereo): 1
XLR/TRS: 2
MIC/LINE IN: 1

Outputs
Headphones: 1
Built-in speaker (mono): 1

Inputs
Built-in mic: 90O XY stereo format
Directionality: Unidirectional
Sensitivity: -43 dB/1 Pa at 1 kHz
Maximum sound pressure input: 130 dB SPL

INPUT1-2
Connector: XLR/TRS combo jacks ×2, (XLR:2 HOT TRS:TIP HOT)
Input gain: Adjustment unnecessary
Input impedance: MIC: 3.8 kO or more, LINE: 39 kO or more
Maximum input level: MIC: +4 dBu, LINE: +24 dBu
Phantom power: +48 V
Channel total: 10 mA or less
Equivalent input noise MIC: -120 dBu or less(IHF-A) @150 O input, LINE: -95 dBu or less(IHF-A) @600 O input

MIC/LINE IN (supports plug-in power)
Connector: Stereo mini jack
Input gain: Adjustment unnecessary
Input impedance: 2 kO or more
OUTPUTS
Headphones
Connector: Stereo mini jack
Maximum output level: 20 mW + 20 mW(into 32 O load)
Output impedance: 15 O or less

Built-in speaker
Type: 20 x 30mm elliptical dynamic speaker
Effective maximum output: 250mW

RECORDER
Maximum simultaneous recording tracks: 4
Maximum simultaneous playback tracks: 4

Recording formats:
WAV
44.1/48/96 kHz,
32-bit float mono/stereo
BWF and iXML formats supported

Recording media:
4-32GB cards compatible with the microSDHC specification
64GB-1TB cards compatible with the microSDXC specification

Display: 2.0-inch full-colour LCD: 360 x 240

USB
Connector: USB Type-C (Use a USB cable that supports data transfer).
USB Mic: USB 2.0 High Speed, 44.1/48 kHz, 24-bit /32-bit float, 4-in/2-out
File transfer: USB2.0 High Speed

Remote
Dedicated wireless adapter: ZOOM BTA-1

Power:

2 AA batteries; Alkaline, lithium or rechargeable NiMH batteries
AC Adapter:
ZOOM AD-17:DC 5V / 1 A - USB bus power is supported.

Estimated continuous operation times using batteries: 2-track recording (built-in XY mic)
Alkaline batteries: About 9 hours
NiMH batteries (1900 mAh): About 9 hours
Lithium batteries: About 19 hours

48 kHz/32-bit float, phantom power off, no headphones, no remote, display power saving on, display brightness at Medium
These values are approximate.
Continuous battery operation times were determined using in-house testing methods.They will vary greatly according to use conditions.

Estimated continuous operation times using batteries: 4-track recording (built-in XY mic with INPUT 1-2)
Alkaline batteries: About 2 hours 30 minutes
NiMH batteries (1900 mAh): About 4 hours
Lithium batteries: About 8 hours
48 kHz/32-bit float, phantom power off, headphones used (33O load), no remote, display power saving on, display brightness at Medium
These values are approximate.
Continuous battery operation times were determined using in-house testing methods. They will vary greatly according to use conditions.

Estimated continuous operation times using batteries : 4-track recording (plug-in power mic with INPUT 1-2)
Alkaline batteries: About 40 minutes
NiMH batteries (1900 mAh): About 1 hour 30 minutes
Lithium batteries: About 3 hours 30 minutes
48 kHz/32-bit float, phantom power off, headphones used (33O load), no remote, display power saving on, display brightness at Medium
These values are approximate.
Continuous battery operation times were determined using in-house testing methods.They will vary greatly according to use conditions.

Power consumption: 3 W maximum
Dimensions: 66.9 mm (W) × 156.1 mm (D) × 38.0 mm (H)
Weight (including batteries): 243 g
Note: 0 dBu = 0.775 Vrms

Notes: The Triple Cap Chaos(C^3 Chaos) is a 2hp analog, chaos based, noise oscillator, pseudo ring modulator/harmonics generator, and audio mangler Eurorack module available as a DIY Eurorack kit, PCB and Panel, or built.

It is a unique module, like the Diode Chaos, because it has never existed as a musical instrument until now. There is also no other module to my knowledge that can do exactly what the Triple Cap can do. The circuit(with several modifications) is based on the paper "Simple Autonomous Chaotic Circuits" by J.C. Sprott and Jessica R. Piper. As opposed to the Diode Chaos that generates control voltage this module focuses on the audio rate.

The "Emanate" potentiometer controls the coarser overall spectrum of the chaos, from lots of activity counter clock wise up to less chaos and more of a steady oscillation. The "Width, CV ATT" potentiometer can be thought of as more of a fine control for the chaos/oscillator. When something is inserted into the "CV" in the voltage normalization from the width knob is broken and the potentiometer now acts as an attenuator for the incoming cv. The Triple Cap is not a traditional volt per octave exponential VCO, and has a sort of narrow frequency range to exploit the chaotic behavior.

It expects a +5v to -5v max signal in to modulate the chaos. The "IN" jack is an A.C. coupled input for audio in, although cv and audio can work for both the "CV" in jack and "IN." The "IN" will interfere and interact with the onboard chaotic oscillator depending on the frequency of the input, which may take some experimentation. It can create ring mod ish sounds, to added harmonics, to almost bit crushed sounds depending on the "X" or "Y" output. The "X" output is a more windy noisy sinusoidal based output and the "Y" output is more squared off and aggressive, harsher sounding output.

Some quirks about the Triple Cap: The "X" output can offset negatively or positively a little bit depending on the pot settings, but both outputs tend to stay around 10vpp. With the "Emanate" and "Width" pots all the way up the typical frequency will be around 150hz although some will reach 200hz at this setting. With the "Emanate" pot full counter clock wise "Width" pot full clock wise the frequency will be around 250hz. It is possible to send signals into the triple cap that can bring it out of the desired range causing the oscillation to cut out.

The Triple Cap has a double sided panel. meaning one side has the classic graphics and the other is Soulless with less graphics.

Notes: The Entropy Expander is a 3hp Analog Random Voltage Generator that expands upon the features of the Entropy Euroack Module. Available as a Eurorack DIY Kit, PCB and Panel, or Built Module.

The Entropy+Expander packs together some of the most random voltage options in 6hp. It provides a controllable "Glide"(slew) out for the S/T\H, a comparator with a controllable rate("Thrsh") of random gates("Rand Gate") out with an input to compare other waveforms(Comp In, inserting a cable into here breaks the white noise normalization), and high pass filtered white noise resulting in approximate "Blue noise" (+3db/octave) and "Violet noise"(+6db/octave) outs.

The unique part of the circuit is a voltage controlled A/B switch thats normalled to the "Rand Gate" out that's switching between the S/T\H out(left Blue led window)and Infra out(right Red led window), the Glide control also effects the S/T\H coming out of the switch so you can get really random results from the "Entropy Out." Inserting a cable into "Switch CV In" breaks the random gate normalization and lets you toggle between A/B(left S/T\H out and right Infra out, indicated by the led windows) with your own gate or trigger.

There is a jumper on the pcb to select if you want glide on the s/t\h at, Entropy out, or un-slewed operation. There is also a trimmer for setting the amplitude of the incoming signal at "Comp In" which sets the frequency range of random gates. This may have to be adjusted depending on your Entropy version.

The random gate range can also be set up more as a noise oscillator by turning the pcb trim(clockwise) up or it can be set so random gates are extremely slow(trim counter clockwise) with minutes between random gates.

Notes: The Dual VCA is a 2hp 2 channel Analog VCA and Mixer Eurorack Module available as a Eurorack DIY Kit, PCB and Panel, or Built Module.

It is a DC coupled OTA(LM13700) Dual Linear VCA based on the same fabled design of the VnIcursal VCA. The 2 VCAs are summed together so it can be used as a voltage controlled mixer at the "SUM OUT" or all 3 outs can be used separately and simultaneously. 5 volts into the CV in will provide unity gain, anything above 5 volts can clip the input.

Notes: Perennial favourite nearfield monitor with a look inspired by the classic NS-10s. Punchy sound with the clarity and accuracy needed for production and mixdowns. Great value.

Supplier's notes:
The Yamaha HS8 is the new flagship model of Yamaha's HS series of active studio monitors, taking its cues from the ever popular and much demanded NS-10.

The Yamaha HS8 Active Studio Monitor features biamplified full range 2 way speakers rated at 75W and 45W and has been developed by Yamaha to offer an exceptionally flat and accurate frequency response for use in music production and composition as well as the home project studio. The HS range of monitors has been designed in the same tradition of the legendary NS10M monitors.

Yamaha HS8 speakers feature a low resonance bass reflex enclosure which improves the rigidity of the overall speaker, and less cabinet resonance means that the signal remains clear and uncoloured. This is very important in getting an accurate mix which translates across all systems.

Port noise has also been audibly reduced by up to 6dB using the new Yamaha proprietary technology right across the HS range, which also helps to deliver a clean and precise signal. The HS8 is equipped with XLR and TRS jack connectors as well as room control and hi trim response controls.

Notes: 12-channel version of the MG mixer series packs a lot of functionality into a small footprint. Class A pre-amps, three-band EQ and neat, ergonomic design. Great value.

For a more precise control and enhancement of your sound, XU models of the MG Series come equipped with a suite of Yamaha's renowned SPX effects. Featuring high-resolution Chorus, Flanger, Distortions, Reverb and Delay, all with editable parameters, these are the same multieffects processors used on Yamaha's high-end mixing consoles, giving you the tools you need to elevate your mixes to a higher plane.

For more than a century, Yamaha has been building a legacy of superior craftsmanship and innovation exemplified in all of our products, from an unrivalled catalog of world-class musical instruments to touring-grade professional audio. Now in its third incarnation, the MG Series embodies this pursuit of design excellence, and incorporates some of the same technologies developed for use in high-end professional consoles, including studio-quality preamps, powerful digital processing, and a rugged, reliable construction. With an intuitive, easy-to-use interface, the MG Series boasts an extensive lineup of compact mixing consoles with models ranging from six to twenty channels, suitable for a diverse range of users and applications. For installed, recording, or live music settings, the solid construction and flexible design of these consoles lets you shape your sound with confidence, continually delivering peak performance and a level of sound quality and reliability unrivalled in its class.

D-PRE (Discrete Class-A Mic Preamps): This is where it all starts. Everything you do as a sound engineer is dependent on the quality of your preamps, which determines the direction your mix will take, and ultimately how good it is going to sound. MG Series mixing consoles feature Yamaha's studio-grade discrete class-A D-PRE preamps, which utilize an inverted Darlington circuit comprising two cascading transistors in a configuration that provides more power with lower impedance. Delivering fat, natural sounding bass and smooth, soaring highs, with very low distortion, D-PRE preamps possess an impressively wide frequency range that allow them to handle signal from any audio source without overly amplifying any specific elements of the sound. Having such a pure sonic platform to build on will ultimately save you time and effort by eliminating the need for excessive EQing or additional effects processing in order to "fix" your mix.

High Quality Sound Op-amp: The head amp determines sound quality, and op-amp integrated circuits are one of the most important parts in the head amp circuit. MG Series mixers feature new, high-quality, custommade MG01 op-amps that we developed in cooperation with the semiconductor manufacturer. Although many other Op-amps prioritize electrical design and efficiency, we worked directly with the semiconductor manufacturer to focus on sound quality first. MG01 op-amps feature redesigned circuitry in which even the internal components and wiring have been optimized, and use materials such as high-quality silicon wafers and copper wire to achieve superb resolution.

Switchable Phantom Power & PAD Switch: With phantom power, MG Series consoles allow you to take full advantage of the greater frequency response and high sound quality of condenser microphones. The input channel with PAD switch accepts MIC to line level of inputs, PAD Switch attenuates high input signals that often accompany mic'ed instruments during performance, avoiding the clippingthat can seriously affect your mix.

When was the last time you heard guitar without EQ or a completely unprocessed vocal on one of your favorite songs? Probably never. Yamaha mixers are famous for their flat response and sonic purity, but it often takes more than a perfectly-captured instrumental performance or vocal to achieve a professional-sounding mix. Equipped with some of the same state-of-the-art functionality featured on Yamaha's high-end consoles, the MG Series gives you the tools you need to produce high quality sound that is uniquely your own.

Notes: Loosely inspired by the look of the classic NS10 studio monitors, Yamaha's HS range offers much more modern sound. Punchy low end and clear highs from this 6.5-inch model.

Supplier's notes:
This second generation of 'HS' nearfield reference monitors, like their predecessors, share the same design philosophy as the legendary NS-10M studio monitors - Providing accurate signal reproduction and superior sonic performance.

The Yamaha HS7 employ a new, highly efficient tweeter providing an extended high frequency range up to 30KHz. The matching HS8S 150W powered subwoofer provides an extend bass when a well defined bottom end is required.

A low resonance enclosure built using a three way mitre joint technique ensures that the corners of the speaker are firmly anchored leading to dramatically improved durability and the elimination of unwanted resonances that can colour the original sound. Yamaha's 'Vortex Sound Control' technology is deployed to decrease unwanted airflows around the speaker ports. This in turn reduces audible noise by up to 6dB.

Product video: http://www.youtube.com/watch?feature=player_embedded&v=Dvj3StP4fVE

Notes: Updated version of the hugely popular MSP3, now with Yamaha's Twisted Flare Port technology for improved low-end response. Small design with big sound thanks to 4-inch woofer and precise dome tweeter.

Supplier's Notes:
MSP3A powered monitor speaker provides faithful sound reproduction in a compact form

The MSP3, a compact reference monitor speaker loved for many years, has been renewed as the MSP3A. This new reference monitor is the first in this series to include our Twisted Flare Port technology and provides an even clearer and tighter low-end while also realizing faithful sound reproduction.

The built-in 22W power amplifier is optimized for the speaker unit, which comprises a 10 cm (4") woofer and a 2.2 cm (.87") tweeter, to achieve a clear and natural reference sound.

The cabinet features a refined, simple design and weighs a mere 3.6 kilograms (7.9 pounds), making it easy to reposition and carry to different locations. Just like its predecessor, this monitor has multiple input connectors and controls, and is compatible with a variety of optional brackets, making it useful for a wide range of uses. These include serious audio and music monitoring in settings from small-scale studios to broadcast and post-production suites, as well as monitoring audio from digital musical instruments and ICT devices, and surround sound playback.

Twisted Flare Port technology, which is included in the MSP3A for the first time in this series, is an aerodynamic sound control technology that we at Yamaha have created by leveraging our extensive subwoofer development experience. Using it, we apply aerodynamic sound analysis and flow visualization measurement technologies to pinpoint and control noise generation mechanisms. Noise-generating air flow turbulence at both ends of the port is suppressed by changing how the port widens from input to output and adding a twist to it. Suppressing turbulence reduces bothersome muddiness in the sound and lowers the amount of noise generated at the port ends. This strengthens the connection between the sound and main speaker and delivers clear, tight low frequencies along with pitch and rhythm.

Compared to the air turbulence generated by the "ordinary port" shown in pink on the left, turbulence is reduced and air flows smoothly through the Twisted Flare Port shown in blue on the right.

Featuring a 22-watt built-in amplifier and Twisted Flare Port for clearer bass, the MSP3A reference monitor produces sound that is faithful to the original. With a variety of inputs, controls and optional support brackets, the MSP3A is ideal for small studios, post-production, monitoring electronic instruments and surround reproduction.

General specifications:

Speaker type: 2-way powered speaker, Bass-reflex type (Twisted Flare Port)
Frequency response: (-10dB) 67Hz - 22kHz
Components- LF: 4" (10 cm) Cone, HF: 0.8" (2.2 cm) Dome
Crossover: 4kHz
Output power: 22W
Maximum Output Level (Measured peak, IEC noise@1m): 99dB SPL
Input sensitivity- LINE 1 : -10 dBu, 10kO (RCA), LINE 2 : +4.0 dBu, 10kO (Combo)
I/O connectors- LINE 1 : RCA, LINE 2 : Combo (XLR/TRS phone)
Indicators: Power ON (Green LED)
Power requirements (May vary depending on region): 120V 50/60Hz, 110 - 120V 50/60Hz, 230V 50/60Hz, 220 - 230V 50/60Hz, 220V 50Hz, 240V 50Hz
Power consumption: 30W
Others: Level control (LINE1, LINE2); Tone control (LOW = Center, REF = 100Hz : MIN -3.0 i 2.0 dB, MAX +3.0 i 2.0 dB; HIGH = Center, REF = 10kHz : MIN -3.0 i 2.0 dB, MAX +3.0 i 2.0 dB)
Dimensions: W- 144mm (5-5/8"), H- 236mm (9-1/4"), D- 166mm (6-5/8")
Net weight: 3.6kg (7.9 lbs.)
Accessories: Power cord, Owner's manual
Packaging: Single
Flying and mounting hardware: 2 x M5 (Depth 15)
Options: Mic stand adaptor BMS-10A, Free-angle clamp BAS-10, Wall mounting bracket BWS20-120 / BWS20-190, Ceiling bracket BCS20-150 / BCS20-210

Notes: Sound:
Vintage Keyboard Sound Engine with six incredibly detailed vintage keyboard types.

Each keyboard type matches a carefully chosen Drive and Tremolo setting to provide an incredibly musical pairing.

The six keyboard types are:

- RdI, early '70s tine electric piano

- RdII, late '70s tine electric piano

- Wr, late '60s reed electric piano

- Clv, 70s struck string Clavinet

- Toy, toy piano

- CP, Yamaha CP80 electric grand piano

128-note polyphony ensures dropout-free performance.

Five stomp box-style effects with direct control@
The effect types are:

- Drive (adds harmonics and distortion)

- Tremolo (Auto-Pan for Rd) or VCM Wah with adjustable depth and rate

- Chorus with adjustable depth and speed

- VCM Phaser with adjustable depth and speed

- Digital or Analog-Type Delay with adjustable time and depth

- Reverb with adjustable depth

Control:
- Based on the FS action found on the flagship Motif XF, HQ (High Quality) Mini Keys provide premium feel and response for fast, accurate and natural playing

- Sustain pedal input allows the sustain function for all electric piano sounds

Mobility & Connectivity:
- Speakers

2W 3cm stereo speaker system lets you play any place, any time.

Specially designed bass reflex port technology enhances bass response for full, rich sound.

- USB

USB "TO HOST" allows MIDI connectivity to your USB-equipped computer or iOS device.

- Audio output

Dual 1/4"unbalanced line outputs provide connection to mixers, audio interfaces, DI boxes and more.

- Audio input

A 3.5mm aux line input lets you connect and hear mobile devices, tablets and more through the instrument.

Battery Operation:
- Battery powered - uses six "AA" batteries with five hours of life

Create your Soundmondo. Inspire and be inspired:
Soundmondo is a free sound sharing community that lets you discover, create and share reface Voices and Set Lists using Google Chrome any place, any time you're online.

Powered by Web MIDI, Soundmondo is simple to use - just connect reface to Chrome and you're ready to create or start browsing.

Notes: Configuring a streaming setup from scratch can be a daunting task, particularly for users with little or no music production experience. The minimalist design of the AG01 takes this into account by combining a high-quality condenser microphone with DSP effects, a LOOPBACK function, flexible input connectivity, and a simple, intuitive mixer for stress-free streaming operation.

Simply connect to your computer or iOS/Android device along with the headphones of your choice, then set your levels and you've got a fully operational streaming station that can be up and running within minutes. If you're an aspiring live streamer that requires a compact yet comprehensive, high quality all-in-one solution, the AG01 is ready when you are.

In most streaming applications your microphone is likely to feature prominently onscreen so it is important for it to complement your overall vision. With a unique and iconic design that blends classic and contemporary aesthetics, the AG01 looks as good as it sounds, offering both black and white-based models to suit your preference.

In addition to the condenser microphone audio input, the AG01 is equipped with a mini stereo line input jack, and an upgraded 4-pole mini jack (TRRS) for smartphones that allows input and output. You can also add audio from devices connected via USB in LOOPBACK mode. Combined with these features, this microphone-type model can cover a wide variety of streaming styles that could not be achieved in the past without a separate mixing device.

The AG01's high-performance condenser microphone utilizes a cardioid polar pattern that captures your voice or musical instrument performance precisely, and converts it into high resolution audio (192kHz, 24bit) while blocking out unwanted ambient noise from the rear or sides.

The AG01 features high-quality DSP effects, allowing you to easily add COMP/EQ and REVERB to color and hone your audio and get the best sound possible to broadcast to your audience. What's more, these tools are processed by the internal DSP chip so there is no delay, making the AG01 particularly valuable for live streaming, when real-time accuracy is required.

You can also turn these effects off completely to capture pure, raw recordings of the AG01's condenser microphone for music/audio production that will be edited by an engineer later.

There are many situations in live streaming where you may need to make audio adjustments on the fly. The carefully configured physical controls of the AG01 respond to these needs providing a simple operating experience that won't detract from your live content or performances.

AG Controller offers two modes, "Simple" and "Detail," which allow users with varying degrees of audio engineering experience to easily and precisely check and adjust the AG's DSP processing from any Windows/Mac or iOS device connected via USB.

The AG01 can be easily placed on a desk or any flat surface with its dedicated stand, or mounted on a desk arm, making it adaptable to almost any environment.

It can also be used in combination with a mobile battery allowing you to take your fully functioning streaming station anywhere you like.

*For stable operation of the AG01, a power supply of DC 5V 900mA or more is required.

AG01 comes bundled with Cubase AI music production software, as well as WaveLab Cast for audio production and editing. The AG01 is also compatible with Rec'n'Share and Cubasis LE applications for iOS devices which are available free of charge from Yamaha and Steinberg to support and inspire your audio content creation.

Specifications

Microphone Unit: Back electret condenser type
Polar Pattern: Cardioid
Adress Type: Side
Frequency Response: 30 Hz - 20 kHz
Max Input SPL: 110 dB (THD - 1.0% at 1 kHz)
Sensitivity: -34 dB i 3 dB (0 dB=1 V/Pa, at 1 kHz)
Connector: USB Type-C

Input Channels
Microphone: 1 (Mono condenser microphone)
AUX: 1 - Stereo mini
Smartphone: 1 - 4-pole mini input/output (TRRS)
USB: 1

Output Channels
PHONES: 1 - Stereo mini
Smartphone: 1 - 4-pole mini input/output (TRRS)
USB: 1
Bus: 1 Stereo
Functions: MIC GAIN (HIGH / MID / LOW), MUTE button x 1, STREAMING OUT (MIC / INPUT MIX / LOOPBACK), MIX MINUS MIC (ON / OFF)

On-board processors
DSP: COMP/EQ, REVERB (SPX Reverb) *Detail is Controlled on AG Controller
USB Audio: 2 IN / 2 OUT, USB Audio Class 2.0 Compliant, Sampling Frequency: Max. 192 kHz, Bit Depth: 24-bit, Type-C
USB DC Power Input: 1 - Type-C, 5 V DC, 900 mA

General specifications
Power requirements 5 V DC, 900 mA
Power consumption Max. 4.5W
Dimensions: W: 116 mm (4.6") H: 281 mm (11.1") D: 118 mm (4.6")
Net weight: 1.2 kg (2.6 lbs)
Included accessories: USB 2.0 Cable (1.5 m), Quick Guide, Safety Guide, Wavelab Cast Download Information, Cubase AI Download Information
Others: Operating Temperature: 0 to + 40C

Notes: Raising the Bar.

Condenser microphones have become a staple of most studio and broadcasting environments around the world for good reason. Their ability to capture the most subtle nuances of vocal and instrument performances has made them the preferred choice for a majority of studio and broadcast professionals.

The YCM01 is a studio-quality condenser microphone that adopts a cardioid polar pattern for more focused sensitivity, making it ideal for a broad range of applications, from live streaming or gaming voice chat, to remote meetings, and of course, music production. Offered in both black and white versions to adapt to your preferred streaming or recording environment, the stylish iconic design of the YCM01 will add a new level of professionalism to your creative content.

Hone in on your sound

The cardioid polar pattern of our condenser microphone ensures the highest sensitivity to sound directly in front of your mic while substantially reducing ambient noise from the rear and sides.

This allows the YCM01 to capture the distinct tones and timbre of your voice or instrument with stunning accuracy, giving your streaming audio an added quality and performance advantage.

*The YCM01 can also be mounted on a tabletop stand, a standard microphone stand, or a desk arm.

Specifcations

Microphone Unit: Back electret condenser type
Polar Pattern: Cardioid
Adress Type: Side
Frequency Response: 30 Hz - 20 kHz
Max Input SPL: 130 dB
Dimensions (Microphone Only): (Diameter) 55 x 166 mm ((Diameter) 2.2" x 6.5")
Weight (Microphone Only): 0.4 kg (0.9 lbs)
Included Accessories: Microphone stand adaptor x 1, Microphone pouch x 1, Owner's manual, Technical specifications

Notes: Raising the Bar.

Condenser microphones have become a staple of most studio and broadcasting environments around the world for good reason. Their ability to capture the most subtle nuances of vocal and instrument performances has made them the preferred choice for a majority of studio and broadcast professionals.

The YCM01 is a studio-quality condenser microphone that adopts a cardioid polar pattern for more focused sensitivity, making it ideal for a broad range of applications, from live streaming or gaming voice chat, to remote meetings, and of course, music production. Offered in both black and white versions to adapt to your preferred streaming or recording environment, the stylish iconic design of the YCM01 will add a new level of professionalism to your creative content.

Hone in on your sound

The cardioid polar pattern of our condenser microphone ensures the highest sensitivity to sound directly in front of your mic while substantially reducing ambient noise from the rear and sides.

This allows the YCM01 to capture the distinct tones and timbre of your voice or instrument with stunning accuracy, giving your streaming audio an added quality and performance advantage.

*The YCM01 can also be mounted on a tabletop stand, a standard microphone stand, or a desk arm.

Specifcations

Microphone Unit: Back electret condenser type
Polar Pattern: Cardioid
Adress Type: Side
Frequency Response: 30 Hz - 20 kHz
Max Input SPL: 130 dB
Dimensions (Microphone Only): (Diameter) 55 x 166 mm ((Diameter) 2.2" x 6.5")
Weight (Microphone Only): 0.4 kg (0.9 lbs)
Included Accessories: Microphone stand adaptor x 1, Microphone pouch x 1, Owner's manual, Technical specifications

Notes: The smallest speaker in Yamaha's range, the compact MS101-4 sits happily on even the most cramped desktop or attaches to a mic stand for versatile monitoring anywhere.

Supplier's Notes:
The industry standard in compact monitors

Yamaha MS101-4: The de facto standard for compact monitoring in a simple form

The standard model in Yamaha's range of desktop utiility powered monitors, the MS101-4 offers portability in a simple, compact design, with comprehensive functions for outstanding usability. The MS101-4 comes with a 3/8-16 threaded female mounting for direct attachment to a Euro microphone stand. Optional accessories can also be added for use in a wide range of applications.

A compact, convenient approach to high-quality monitoring anywhere

Compatible with both line and mic inputs, the MS101-4 offers the flexibility needed for temporary or permanent use in applications requiring simple, compact monitors.

Simple, portable, durable design

Yamaha Powered Monitor Speaker MS101-4: front and rear

With the controls (power switch, volume and tone controls) and the combo jack input on the lower front panel, you'll find the MS101-4 is easy to operate. The sturdy metal grill offers complete protection for the four-inch cone driver, while the rear panel is equipped with one stereo mini and a TRS Phone input connector, along with an output jack. An AC inlet for a removeable power cord provides excellent portability. The bass reflex port is also located on the rear surface, resulting in a more compact chassis.

MS101-4 Powered Monitor Speaker

The standard model in our range of desktop utiility powered monitors, the MS101-4 offers portability in a simple, compact design, with comprehensive functions for outstanding usability.

30W of amplifier power provides clean, high output sound
Redesigned enclosure for an even lower profile
Combo Input jack accepts both XLR and 1/4" connectors
Directly mountable on Euro microphone stands (optional mic stand adaptor BMS-10A is available for adjusting tilt angle)

General specifications

Speaker type: Full range Powered Speaker, Bass-reflex Type
Frequency range (-10dB): 77 Hz-20 kHz
Maximum output level (1m; on axis): 115 dB SPL *1
Components: LF-HF 4" Cone, 1" Voice coil, Ferrite magnet
Dimensions: W: 142 mm, H: 196 mm, D: 187 mm
Net weight: 2.1 kg (4.6 lbs)
Flying and mounting hardware Screw threads (bottom): 2 x M5 depth 11 mm pitch 60 mm (for 2, M5 x 6-10 mm screws), 1 x 3/8" depth 12 mm (for 1 x 3/8" x 9-11 mm screw)
Amplifier class: Class-D
Power rating: Dynamic: 30 W
Continuous: 20 W
Cooling: Natural cooling (no fan)
I/O Connectors: Mic Input: [Front] INPUT: Combo, [Rear] INPUT LINE 1: Stereo Mini, INPUT LINE 2: Phone (TRS)
Line Out: 1 x Phone (TRS)
AC: 1 x AC inlet
Input impedance: [Front] INPUT: LINE=5.4 kO / MIC= 5.4 kO, [Rear] INPUT LINE 1,2: 10 kO
Input sensitivity: [Front] INPUT: LINE=-10 dBu / MIC=-40 dBu, [Rear] INPUT LINE 1, 2: -10 dBu (VOLUME: Maximum)
Input Level: [Front] INPUT: LINE=+5 dBu / MIC=-25 dBu, [Rear] INPUT LINE 1, 2: +5 dBu (Nominal Input Level / VOLUME: Center), [Front] INPUT: LINE=+20 dBu / MIC=-10 dBu, [Rear] INPUT LINE 1, 2: +20 dBu (Maximum Input Level)
Others: Controls: 1 x VOLUME, 1 x LOW CONTROL, 1 x HIGH CONTROL, POWER
Indicators POWER (Green LED)
Power consumption: 1/8 Power Consumption: 10 W, Idle Power Consumption: 3 W
Power requirements: 100 V - 240 V, 50/60 Hz
Options: Mic stand adaptor BMS-10A, Free-angle clamp BAS-10, Wall mounting bracket BWS20-190, Ceiling bracket BCS20-150 / BCS20-210

Notes: Entry-level model in the FGDP range, billed as the ultimate finger drum pads. The portable, rechargeable FGDP-30 features a built-in tone generator and speaker, all controlled by outstandingly responsive pads arranged in an ergonomic format.

Supplier's Notes:
The ultimate finger drum pad

With ultra-sensitive Pads in an ergonomic layout perfect for finger drumming, the FGDP features a Tone Generator, internal speaker, and rechargeable battery that make it a true all-in-one instrument that you can play anywhere. Let your fingers make the rhythm!

Made for finger drumming

Thoughtfully designed layout and Pads for the ultimate finger drumming performance. From sampled acoustic drums that sound like they're right in front of you to powerful electronic sounds, beloved and curated by top professional artists, covering a wide range of genres. Yamaha promises uncompromising performance.

Optimised layout

Introducing a distinctive Pad layout meticulously designed for optimal finger drumming by prioritizing ergonomic comfort.

With the FGDP, you have the freedom to assign Voices to Pads according to your creative vision, but at Yamaha, we recommend the 3-finger style. Harness the power of your thumb for the kick drum, rely on the enduring middle finger for precise hi-hat control, and let your dexterous index finger bring to life the delicate nuances and intricate phrases of the snare.

The home position enables you to effortlessly execute fundamental rhythms, like 8th notes using just one hand. You can use your other hand to play on the other symmetrically laid out pads to unleash captivating back beats in 16th note or double kick styles.

Equipped with an ample number of Pads perfectly suited for finger drumming, the FGDP empowers you to deliver your finest performances, setting itself apart from conventional Samplers and MIDI Pads.

Expressive precision

Featuring cutting-edge Pads designed to capture every subtle nuance, the FGDP ensures that no detail goes unnoticed. With the powerful combination of the internal Tone Generator, you can deliver delicate performances encompassing ghost notes, impactful accents, flams, and lightning-fast rolls. Moreover, the Pads support Aftertouch, enabling unique drumming techniques such as cymbal choking by applying pressure to a Pad while holding it pressed. With the FGDP, your drumming possibilities are limitless.

Specifications

Size/Weight

Dimensions
Width: 223 mm (8-3/4 in)
Height: 49 mm (1-15/16 in)
Depth: 195 mm (7-11/16 in)
Weight: 1.0 kg (2 lbs. 3 oz)

Packing Box
Width: 282 mm (11-1/16 in)
Height: 108 mm (4-1/4 in)
Depth: 244 mm (9-5/8 in)

Pad section

Drum Pads: 18 pads
Number of Trigger Settings: Preset 12
User: Preset overwrite
After Touch: Polyphonic, Channel

Control Interface
Voice Guide: English

Tone generator
Tone Generator AWM2

Maximum Polyphony: 64 notes
Drum kits: Preset: 39 Kits, User: Preset overwrite
Voices: 1,212
Kit Edit: Yes (only some parameter)
Effects Reverb: 11, Chorus: 10, Variation: 23, Speaker EQ: 5

Click
Tempo: 30 to 300 BPM, Tap Tempo supported.
Beat: 1 - 16
Others: Patterns (1/4, 1/4T, 1/8, 1/8T, 1/16, 1/16T, Clave)

Functions

Registration Memory

Number of Buttons: 2
Preset: 1 Bank, User: Preset overwrite

Amplifiers and Speakers
Amplifiers: 2.5 W
Speakers: 4 cm × 1

Other

Connectors
Headphones: Headphones/Output (Stereo mini jack x 1)
AUX IN AUX IN (stereo mini jack × 1)
USB: USB TO HOST (Micro B)

Power Supply
Power Supply: USB power adaptor 5 V/1.5 A or greater USB BC specification compatible products (Sold separately)
Internal Battery: 1,400 mAh, 4.5 Wh 3 hours
Power Consumption: 4 W

Accessories
Included Accessories: Owner's Manual, USB cable

Notes: The ultimate finger drum pad

With ultra-sensitive Pads in an ergonomic layout perfect for finger drumming, the FGDP features a Tone Generator, internal speaker, and rechargeable battery that make it a true all-in-one instrument that you can play anywhere. Let your fingers make the rhythm!

Made for finger drumming

Thoughtfully designed layout and Pads for the ultimate finger drumming performance. From sampled acoustic drums that sound like they're right in front of you to powerful electronic sounds, beloved and curated by top professional artists, covering a wide range of genres. Yamaha promises uncompromising performance.

Optimised layout

Introducing a distinctive Pad layout meticulously designed for optimal finger drumming by prioritizing ergonomic comfort.

With the FGDP, you have the freedom to assign Voices to Pads according to your creative vision, but at Yamaha, we recommend the 3-finger style. Harness the power of your thumb for the kick drum, rely on the enduring middle finger for precise hi-hat control, and let your dexterous index finger bring to life the delicate nuances and intricate phrases of the snare.

The home position enables you to effortlessly execute fundamental rhythms, like 8th notes using just one hand. You can use your other hand to play on the other symmetrically laid out pads to unleash captivating back beats in 16th note or double kick styles.

Equipped with an ample number of Pads perfectly suited for finger drumming, the FGDP empowers you to deliver your finest performances, setting itself apart from conventional Samplers and MIDI Pads.

Expressive precision

Featuring cutting-edge Pads designed to capture every subtle nuance, the FGDP ensures that no detail goes unnoticed. With the powerful combination of the internal Tone Generator, you can deliver delicate performances encompassing ghost notes, impactful accents, flams, and lightning-fast rolls. Moreover, the Pads support Aftertouch, allowing for enhanced expression and enabling unique drumming techniques such as cymbal choking by applying pressure to a Pad while holding it pressed. With the FGDP, your drumming possibilities are almost limitless.

Specifications

Size/Weight

Dimensions

Width: 223 mm (8-3/4 in)
Height: 51 mm (2 in)
Depth: 223 mm (8-3/4 in)
Weight: 1.1 kg (2 lbs. 7oz)

Packing Box

Width: 282 mm (11-1/16 in)
Height: 110 mm (4-11/32 in)
Depth: 272 mm (10-3/4 in)

Pad section

Drum Pads: 18 pads
RGB square pads: 8 pads

Number of Trigger Settings:
Preset: 12
User: 50
After Touch: Polyphonic, Channel
Assignable Functions: Yes

Control Interface
Display: LCD with backlight

Tone generator
Tone Generator AWM2

Maximum Polyphony: 64 notes
Drum kits: Preset: 48 Kits, User: 50 Kits
Voices: 1,500
Kit Edit: Yes
Effects: Reverb: 11, Chorus: 10, Variation: 23, Speaker EQ: 5

Audio Files
Import limit: 100 files
sample format: WAV, AIFF (44.1 kHz, 16-bit, mono/stereo)
Maximum loadable sample time approx. 600 seconds (44.1 kHz, 16-bit, mono), approx. 300 seconds (44.1 kHz, 16-bit, stereo), approx. 20 seconds per file

Click
Tempo: 30 to 300 BPM, Tap Tempo supported.
Beat: 1 - 16
Others: Patterns (1/4, 1/4T, 1/8, 1/8T, 1/16, 1/16T, Clave)

Session Creator

Number of Session Creators: 23
Sections: Intro, Main × 4, Ending
Parts: Drum, Bass, Other × 4

Recorder
Recording time: USB flash drive approx. 80 minutes per file
Format: WAV (44.1 kHz, 16 bit, stereo)

Functions

Voices
Note Repeat: Each Pad
Humanize: Each Pad

Registration Memory
Number of Buttons: 4
Preset: 5 Banks, User: 50 Banks

Amplifiers and Speakers

Amplifiers: 2.5 W
Speakers: 4 cm × 1

Other

Connectors

Headphones: Headphones/Output (Stereo mini jack x 1)
AUX IN: AUX IN (stereo mini jack × 1)
USB: USB TO DEVICE (Type A), USB TO HOST (Micro B)

Power Supply
Power Supply: USB power adaptor 5 V/1.5 A or greater USB BC specification compatible products (Sold separately)
Internal Battery: 1,400 mAh, 4.5 Wh 3 hours
Power Consumption: 7 W

Accessories
Included Accessories: Owner's Manual, USB cable

Notes: ***B-STOCK: Box opened, product in perfect working order***


The smallest speaker in Yamaha's range, the compact MS101-4 sits happily on even the most cramped desktop or attaches to a mic stand for versatile monitoring anywhere.

Supplier's Notes:
The industry standard in compact monitors

Yamaha MS101-4: The de facto standard for compact monitoring in a simple form

The standard model in Yamaha's range of desktop utiility powered monitors, the MS101-4 offers portability in a simple, compact design, with comprehensive functions for outstanding usability. The MS101-4 comes with a 3/8-16 threaded female mounting for direct attachment to a Euro microphone stand. Optional accessories can also be added for use in a wide range of applications.

A compact, convenient approach to high-quality monitoring anywhere

Compatible with both line and mic inputs, the MS101-4 offers the flexibility needed for temporary or permanent use in applications requiring simple, compact monitors.

Simple, portable, durable design

Yamaha Powered Monitor Speaker MS101-4: front and rear

With the controls (power switch, volume and tone controls) and the combo jack input on the lower front panel, you'll find the MS101-4 is easy to operate. The sturdy metal grill offers complete protection for the four-inch cone driver, while the rear panel is equipped with one stereo mini and a TRS Phone input connector, along with an output jack. An AC inlet for a removeable power cord provides excellent portability. The bass reflex port is also located on the rear surface, resulting in a more compact chassis.

MS101-4 Powered Monitor Speaker

The standard model in our range of desktop utiility powered monitors, the MS101-4 offers portability in a simple, compact design, with comprehensive functions for outstanding usability.

30W of amplifier power provides clean, high output sound
Redesigned enclosure for an even lower profile
Combo Input jack accepts both XLR and 1/4" connectors
Directly mountable on Euro microphone stands (optional mic stand adaptor BMS-10A is available for adjusting tilt angle)

General specifications

Speaker type: Full range Powered Speaker, Bass-reflex Type
Frequency range (-10dB): 77 Hz-20 kHz
Maximum output level (1m; on axis): 115 dB SPL *1
Components: LF-HF 4" Cone, 1" Voice coil, Ferrite magnet
Dimensions: W: 142 mm, H: 196 mm, D: 187 mm
Net weight: 2.1 kg (4.6 lbs)
Flying and mounting hardware Screw threads (bottom): 2 x M5 depth 11 mm pitch 60 mm (for 2, M5 x 6-10 mm screws), 1 x 3/8" depth 12 mm (for 1 x 3/8" x 9-11 mm screw)
Amplifier class: Class-D
Power rating: Dynamic: 30 W
Continuous: 20 W
Cooling: Natural cooling (no fan)
I/O Connectors: Mic Input: [Front] INPUT: Combo, [Rear] INPUT LINE 1: Stereo Mini, INPUT LINE 2: Phone (TRS)
Line Out: 1 x Phone (TRS)
AC: 1 x AC inlet
Input impedance: [Front] INPUT: LINE=5.4 kO / MIC= 5.4 kO, [Rear] INPUT LINE 1,2: 10 kO
Input sensitivity: [Front] INPUT: LINE=-10 dBu / MIC=-40 dBu, [Rear] INPUT LINE 1, 2: -10 dBu (VOLUME: Maximum)
Input Level: [Front] INPUT: LINE=+5 dBu / MIC=-25 dBu, [Rear] INPUT LINE 1, 2: +5 dBu (Nominal Input Level / VOLUME: Center), [Front] INPUT: LINE=+20 dBu / MIC=-10 dBu, [Rear] INPUT LINE 1, 2: +20 dBu (Maximum Input Level)
Others: Controls: 1 x VOLUME, 1 x LOW CONTROL, 1 x HIGH CONTROL, POWER
Indicators POWER (Green LED)
Power consumption: 1/8 Power Consumption: 10 W, Idle Power Consumption: 3 W
Power requirements: 100 V - 240 V, 50/60 Hz
Options: Mic stand adaptor BMS-10A, Free-angle clamp BAS-10, Wall mounting bracket BWS20-190, Ceiling bracket BCS20-150 / BCS20-210

Notes: The babies of the Yamaha HS range pack a bigger punch than their size might suggest. A good entry-level option for smaller studios. Clear, revealing monitors at a friendly price.

Supplier's notes:
The Yamaha HS5 is a new addition to Yamaha's HS series of active monitors, influenced by the critically acclaimed and highly sought after NS-10 studio monitor speakers.

The Yamaha HS5 Active Studio Monitor features biamped full range 2 way speakers rated at 45W and 25W and has been developed by Yamaha to offer an exceptionally flat and accurate frequency response for use in music production and composition as well as home project studios. The HS5 monitors' design has been informed by the tradition of the legendary NS10M monitors.

Yamaha HS5 speakers feature a low resonance bass reflex enclosure which improves the rigidity of the overall speaker, and less cabinet resonance means that the signal remains clear and uncoloured. This is very important in getting an accurate mix which translates across all systems.

Port noise has also been audibly reduced by up to 6dB using the new Yamaha proprietary technology in the HS5 studio monitors, which also helps to deliver a clean and precise signal. The HS5 is equipped with XLR and TRS jack connectors as well as room control and hi trim response controls.

Notes: In the 15 years since they were introduced, the HS Series powered studio monitors have become a favourite in professional, project and home studio environments.
The new special edition HS5 MP Set includes two HS5 monitors, both manufactured using a unique process and both utilising specially selected parts. The result is a pair of monitors, each as closely matched to one another as is possible.

2-way bass-reflex bi-amplified nearfield studio monitor with 5" cone woofer and 1" dome tweeter
54Hz - 30kHz (-10dB), 74Hz - 24kHz (-3dB) frequency response
45W LF plus 25W HF bi-amp system for high-performance 70W power amplification
ROOM CONTROL and HIGH TRIM response controls
XLR and TRS phone jack inputs accept balanced or unbalanced signals

The HS Series embodies the design philosophy on which Yamaha has long insisted for its studio monitors, and is now available as a special paired model that uses selected volume parts. The paired model series bears the designation of MP (Matched Pair), and MP stickers are affixed to the back of each unit. Manufactured at the same time and with paired serial numbers, the HS MP models can play a valued role in your recording, mixing, and mastering work.

Yamaha Pro Audio's history of aspiration and innovation goes back to 1969. Since the creation of Yamaha's first pro audio products (the VA120 and VA180 vocal amp systems), they've repeatedly aspired and innovated to create a wide-ranging lineup for applications including broadcast studios and commercial spaces, such as mixing consoles, power amplifiers, speakers, processors, and immersive sound solutions, each with the aim of becoming the new standard in their respective market.

Monitor speakers are one of the product areas that must be mentioned when speaking of Yamaha Pro Audio's fifty-year history. The NS10M STUDIO which went on sale in 1977 was a studio monitor speaker loved by numerous engineers, and earned a role in studios around the world. In 1998 came the MSP5 powered monitor speaker which focused on providing the painstakingly faithful playback of the original sound that is demanded from nearfield monitors. Subsequently, the MSP/MSP STUDIO series that appeared during the period 2000 through 2008 benefited from a full measure of the know-how and technology that has been accumulated in the field of pro studio monitor design, going on sale as a flagship model that boasted a stunning degree of perfection.

Yamaha have insisted on complete fidelity to the original sound and the ability to reproduce the subtle changes of tone and position in the mix, and these principles are exemplified in the HS series that appeared in 2005 with its bright white cones. As high-bit and high-sampling-rate continue as trends in the field of music production, leading to an increasing need for high-quality nearfield monitors, these speakers deliver the high-quality sound and accuracy that are ideal for the studio environment. In 2013, fusing the know-how and cutting-edge analysis technology that has been developed through many years of studio monitor design, and carefully rethinking every element, the next-generation HS series have been announced, adds yet more polish to the accuracy of these speakers.

Notes: In the 15 years since they were introduced, the HS Series powered studio monitors have become a favourite in professional, project and home studio environments.
The new special edition HS8 MP Set includes two HS8 monitors, both manufactured using a unique process and both utilising specially selected parts. The result is a pair of monitors, each as closely matched to one another as is possible.

2-way bass-reflex bi-amplified nearfield studio monitor with 5" cone woofer and 1" dome tweeter
54Hz - 30kHz (-10dB), 74Hz - 24kHz (-3dB) frequency response
45W LF plus 25W HF bi-amp system for high-performance 70W power amplification
ROOM CONTROL and HIGH TRIM response controls
XLR and TRS phone jack inputs accept balanced or unbalanced signals

The HS Series embodies the design philosophy on which Yamaha has long insisted for its studio monitors, and is now available as a special paired model that uses selected volume parts. The paired model series bears the designation of MP (Matched Pair), and MP stickers are affixed to the back of each unit. Manufactured at the same time and with paired serial numbers, the HS MP models can play a valued role in your recording, mixing, and mastering work.

Yamaha Pro Audio's history of aspiration and innovation goes back to 1969. Since the creation of Yamaha's first pro audio products (the VA120 and VA180 vocal amp systems), they've repeatedly aspired and innovated to create a wide-ranging lineup for applications including broadcast studios and commercial spaces, such as mixing consoles, power amplifiers, speakers, processors, and immersive sound solutions, each with the aim of becoming the new standard in their respective market.

Monitor speakers are one of the product areas that must be mentioned when speaking of Yamaha Pro Audio's fifty-year history. The NS10M STUDIO which went on sale in 1977 was a studio monitor speaker loved by numerous engineers, and earned a role in studios around the world. In 1998 came the MSP5 powered monitor speaker which focused on providing the painstakingly faithful playback of the original sound that is demanded from nearfield monitors. Subsequently, the MSP/MSP STUDIO series that appeared during the period 2000 through 2008 benefited from a full measure of the know-how and technology that has been accumulated in the field of pro studio monitor design, going on sale as a flagship model that boasted a stunning degree of perfection.

Yamaha have insisted on complete fidelity to the original sound and the ability to reproduce the subtle changes of tone and position in the mix, and these principles are exemplified in the HS series that appeared in 2005 with its bright white cones. As high-bit and high-sampling-rate continue as trends in the field of music production, leading to an increasing need for high-quality nearfield monitors, these speakers deliver the high-quality sound and accuracy that are ideal for the studio environment. In 2013, fusing the know-how and cutting-edge analysis technology that has been developed through many years of studio monitor design, and carefully rethinking every element, the next-generation HS series have been announced, adds yet more polish to the accuracy of these speakers.

Notes: The Yamaha HS5 is a new addition to Yamaha's HS series of active monitors, influenced by the critically acclaimed and highly sought after NS-10 studio monitor speakers.

The Yamaha HS5 Active Studio Monitor features biamped full range 2 way speakers rated at 45W and 25W and has been developed by Yamaha to offer an exceptionally flat and accurate frequency response for use in music production and composition as well as home project studios. The HS5 monitors' design has been informed by the tradition of the legendary NS10M monitors.

Yamaha HS5 speakers feature a low resonance bass reflex enclosure which improves the rigidity of the overall speaker, and less cabinet resonance means that the signal remains clear and uncoloured. This is very important in getting an accurate mix which translates across all systems.

Port noise has also been audibly reduced by up to 6dB using the new Yamaha proprietary technology in the HS5 studio monitors, which also helps to deliver a clean and precise signal. The HS5 is equipped with XLR and TRS jack connectors as well as room control and hi trim response controls.

Notes: Everyone loves a white speaker cone, right? Firm favourites since their release in 2013, the HS7s are ideal for entry-level production use or as a monitor for home DJ setups.

Supplier notes:
Ever since the 1970's the iconic white woofer and signature sound of Yamaha's nearfield reference monitors have become a genuine industry standard for a reason - their accuracy. Unlike studio monitors with added bass or treble frequencies which may sound more flattering at first, HS Series speakers were designed to give you the most honest, precise reference possible, providing an ideal sonic platform to build on throughout the mixing process.

By combining acquired knowledge and expertise with state-of-the-art sound technologies, Yamaha's speaker engineering team have examined, then optimized, every aspect that has contributed to making these monitors the most trusted in the business. The second generation HS Series also adds a new 6.5" model to the lineup, bringing its exceptional accuracy to an even greater variety of recording environments.

Notes: The 3rd generation of the Yamaha MG Mixer brings with it some neat updated features, great build quality and the same great sound and flexibility that we have come to expect from a Yamaha mixing console. Built with a sturdy metal chassis, the MG III series mixers are designed to last.

The MG-06X is a 6 channel mixer with 2 D-Pre Mic inputs for super-quiet operation. The MG-06X has +48v phantom power for condenser mics and XLR balanced outputs to ensure that no matter how big or small your operation is, the MG06X will act as the lynch-pin mixing desk that you can depend upon.

Also on the MG06X are a bank of Yamaha SPX effects to further enhance your sound with no need to add in additional processors.

Notes: ***B-STOCK: Box damaged, product in perfect working order***


Configuring a streaming setup from scratch can be a daunting task, particularly for users with little or no music production experience. The minimalist design of the AG01 takes this into account by combining a high-quality condenser microphone with DSP effects, a LOOPBACK function, flexible input connectivity, and a simple, intuitive mixer for stress-free streaming operation.

Simply connect to your computer or iOS/Android device along with the headphones of your choice, then set your levels and you've got a fully operational streaming station that can be up and running within minutes. If you're an aspiring live streamer that requires a compact yet comprehensive, high quality all-in-one solution, the AG01 is ready when you are.

In most streaming applications your microphone is likely to feature prominently onscreen so it is important for it to complement your overall vision. With a unique and iconic design that blends classic and contemporary aesthetics, the AG01 looks as good as it sounds, offering both black and white-based models to suit your preference.

In addition to the condenser microphone audio input, the AG01 is equipped with a mini stereo line input jack, and an upgraded 4-pole mini jack (TRRS) for smartphones that allows input and output. You can also add audio from devices connected via USB in LOOPBACK mode. Combined with these features, this microphone-type model can cover a wide variety of streaming styles that could not be achieved in the past without a separate mixing device.

The AG01's high-performance condenser microphone utilizes a cardioid polar pattern that captures your voice or musical instrument performance precisely, and converts it into high resolution audio (192kHz, 24bit) while blocking out unwanted ambient noise from the rear or sides.

The AG01 features high-quality DSP effects, allowing you to easily add COMP/EQ and REVERB to color and hone your audio and get the best sound possible to broadcast to your audience. What's more, these tools are processed by the internal DSP chip so there is no delay, making the AG01 particularly valuable for live streaming, when real-time accuracy is required.

You can also turn these effects off completely to capture pure, raw recordings of the AG01's condenser microphone for music/audio production that will be edited by an engineer later.

There are many situations in live streaming where you may need to make audio adjustments on the fly. The carefully configured physical controls of the AG01 respond to these needs providing a simple operating experience that won't detract from your live content or performances.

AG Controller offers two modes, "Simple" and "Detail," which allow users with varying degrees of audio engineering experience to easily and precisely check and adjust the AG's DSP processing from any Windows/Mac or iOS device connected via USB.

The AG01 can be easily placed on a desk or any flat surface with its dedicated stand, or mounted on a desk arm, making it adaptable to almost any environment.

It can also be used in combination with a mobile battery allowing you to take your fully functioning streaming station anywhere you like.

*For stable operation of the AG01, a power supply of DC 5V 900mA or more is required.

AG01 comes bundled with Cubase AI music production software, as well as WaveLab Cast for audio production and editing. The AG01 is also compatible with Rec'n'Share and Cubasis LE applications for iOS devices which are available free of charge from Yamaha and Steinberg to support and inspire your audio content creation.

Specifications

Microphone Unit: Back electret condenser type
Polar Pattern: Cardioid
Adress Type: Side
Frequency Response: 30 Hz - 20 kHz
Max Input SPL: 110 dB (THD - 1.0% at 1 kHz)
Sensitivity: -34 dB i 3 dB (0 dB=1 V/Pa, at 1 kHz)
Connector: USB Type-C

Input Channels
Microphone: 1 (Mono condenser microphone)
AUX: 1 - Stereo mini
Smartphone: 1 - 4-pole mini input/output (TRRS)
USB: 1

Output Channels
PHONES: 1 - Stereo mini
Smartphone: 1 - 4-pole mini input/output (TRRS)
USB: 1
Bus: 1 Stereo
Functions: MIC GAIN (HIGH / MID / LOW), MUTE button x 1, STREAMING OUT (MIC / INPUT MIX / LOOPBACK), MIX MINUS MIC (ON / OFF)

On-board processors
DSP: COMP/EQ, REVERB (SPX Reverb) *Detail is Controlled on AG Controller
USB Audio: 2 IN / 2 OUT, USB Audio Class 2.0 Compliant, Sampling Frequency: Max. 192 kHz, Bit Depth: 24-bit, Type-C
USB DC Power Input: 1 - Type-C, 5 V DC, 900 mA

General specifications
Power requirements 5 V DC, 900 mA
Power consumption Max. 4.5W
Dimensions: W: 116 mm (4.6") H: 281 mm (11.1") D: 118 mm (4.6")
Net weight: 1.2 kg (2.6 lbs)
Included accessories: USB 2.0 Cable (1.5 m), Quick Guide, Safety Guide, Wavelab Cast Download Information, Cubase AI Download Information
Others: Operating Temperature: 0 to + 40C

Notes: High-quality compact studio monitors for the uncompromising creator

HS Series speakers have become the standard in studio monitors, trusted for many years by the world's top audio engineers, producers, and artists. Now Yamaha has redefined their essence in a compact housing. The HS3 and HS4 are powerful tools to help create a wide range of audio content-from music production to video editing-that meets the expectations of creators who have limited space and need to keep the volume down but do not want to compromise on monitoring quality.

Sound that is always true to the original

The HS3 and HS4 continue the design philosophy and know-how of previous Yamaha studio monitors. No effort has been spared in the pursuit of the optimal product, and the resulting speakers comprise carefully selecting parts such as a high-performance class-D amp, a highly resilient MDF cabinet, and woofers and soft dome tweeters that deliver a sound that is faithful to the source despite their small size. They also feature proprietary "Twisted Flare Port" technology that reduces air turbulence noise in the bass reflex port, providing clear and accurate bass. That's the secret to why the HS3 and HS4 deliver outstanding resolution, sound image, and depth, with a flat response across all bandwidths without any colouring of the original sound.

Optimal sound tailored to your environment

The sound produced by speakers is sometimes affected by the surrounding environment.

The rear panels of the HS3 and HS4 are equipped with ROOM CONTROL and HIGH TRIM functions that allow you to make adjustments to achieve the ideal sound for any environment, such as reducing the unneeded, exaggerated low-end that can often occur when speakers are placed next to walls.

Inputs and controls to fit any use case

The rear panel of the HS3 and HS4 is equipped with combination XLR/TRS phone, RCA, and stereo mini connectors, allowing you to connect to a wide range of professional and consumer equipment such as computers, audio interfaces, audio mixers, and electric instruments. The most commonly used features-power button, volume knob, and headphone connector-are located in the front for easy access.

Compact and portable

The compact size of the HS3 and HS4 was made possible thanks to the highly efficient class-D amp. Using one amp for two speakers has enabled us to both reduce the weight of the speakers and simplify the cable connections. They take up little space even in a small bedroom studio, and are easy to take with you on the road.

General specifications

Speaker type: 2-way powered speaker, Bass-reflex type
Frequency response (-10dB): 60 Hz - 22 kHz
Frequency response (-3dB): 83 Hz - 20 kHz
Crossover: 2.3 kHz
Maximum Output Level (Measured peak, IEC noise@1m): 102 dB SPL
Components: HF: " Dome, LF: 4.5" Cone
Nominal impedance: 6 O
I/O connectors: [Input Connector] L Side: COMBO (XLR/TRS Phone) ×2, RCA ×2, Stereo Mini, R Side: Speaker Input; [Output Connector] L Side: Headphone, Speaker Output
Output power: 26 W + 26 W (Dynamic, RL=6 O), 20 W + 20 W (THD 0.1%, 1kHz, RL=6 O)
Input sensitivity: LINE 1 (COMBO): +4 dBu, LINE 2 (RCA, ST Mini): -10 dBu (Volume: Maximum)
Input Level: LINE 1 (COMBO): +20 dBu, LINE 2 (RCA, ST Mini): +6 dBu (Maximum Input)
Input impedance: LINE 1 (COMBO): 20 kO, LINE 2 (RCA, ST Mini): 10 kO
Controls: Front: Volume, Rear: ROOM CONTROL SWITCH (0/-2/-4 dB under 500 Hz), HIGH TRIM SWITCH (+2/0/-2 dB above 2 kHz)
Indicators: Power ON (White LED)
Power requirements: Depending on area of purchase; 100-240 V, 50/60 Hz (*)
Power consumption: 15 W
Cabinet material: MDF

Dimensions

Width: L Side: 150 mm (5.9"), R Side: 150 mm (5.9")
Height: L Side: 240 mm (9.4"), R Side: 240 mm (9.4")
Depth: L Side: 213 mm (8.4"), R Side: 203 mm (8.0")

Net weight: L Side: 3.7 kg (8.2 lb), R Side: 3.1 kg (6.8 lb)

Accessories: Stereo Mini - RCA Cable 1.5 m, Speaker Cable 2.5 m, Anti Slip Pad, Quick Start Guide, Safety Guide
Packaging: Pair

* While this product will work at a voltage of between 100 V to 240 V, as limiter settings vary depending on the supply voltage, make sure to use this product at the supply voltage indicated on the rear panel of this product.

Notes: *** App Update- August 2024 ***

Yamaha Music is proud to announce the release of SEQTRAK App v1.0.2, a significant upgrade now available on Web and App stores worldwide. This update marks a substantial improvement in the app's functionality, speed, and overall user experience.

Transformative Enhancements in v1.0.2:

1. Revolutionized Data Syncing: Users will experience dramatically faster load times thanks to intelligent cached data usage, making workflow smoother and more efficient than ever before.
2. Advanced Sorting Capabilities: The newly implemented Packs list sorting feature empowers users with enhanced organization tools, streamlining project management and creative processes.
3. Mac User Experience Boost: Mac users will enjoy improved accessibility with the addition of [ctrl + click] functionality for context menus, aligning with platform-specific user expectations.

Critical Issues Resolved:

This update doesn't just add features; it also significantly improves stability and reliability:

- Eliminated Visualizer scene loading issues, ensuring seamless visual performances
- Perfected Visualizer Reflection parameter value retention for consistent visual outputs
- Resolved UI display inconsistencies related to parameter-lock deletion, enhancing user interface reliability
- Optimized Sampler track Destination value changes for precise audio routing
- Rectified parameter-locked effects saving for Synth tracks, preserving complex sound designs

The culmination of these improvements results in a noticeably more robust, responsive, and user-friendly SEQTRAK App. Whether you're a professional musician, a live performer, or an enthusiastic hobbyist, v1.0.2 offers a substantially improved platform for your creative endeavours.

Users can immediately access this groundbreaking update through their respective App stores or via the Web platform.


Yamaha's all-in-one portable production tool offers an exciting new take on music making. Synth and sampler engines combine with a built-in sequencer, allowing you to create tracks from scratch.

Supplier's Notes:
Unlock your creativity anywhere

Introducing SEQTRAK, the ultimate music creation station that empowers you to capture, create and connect with fans - from anywhere you happen to be.

Capture

Capture ideas as quickly as they come.

All-in-one system

Drums. Synths. Sound design. Sequencing. All included. With an array of features, all loaded in a compact, lightweight design, SEQTRAK allows you to start producing right away - no matter where you are. It's got everything you need. And more.

Lightning-fast workflow

SEQTRAK makes capturing ideas simple with a clear 3-part user interface and real-time, hands-on controls. You'll produce your music without menu-diving or waiting for boot times. Seize moments of inspiration and unleash your creativity in no time at all.

Extensive sounds

SEQTRAK extensive library contains over 2,000 presets. You'll find a vast collection of professionally crafted sounds - from rich pianos, to shimmering synths and thundering drums. More will be available with updates to the SEQTRAK app.

Onboard sampling

Capture your own unique sound samples effortlessly. SEQTRAK's sampler offers seven sound slots and a variety of effects, allowing you to shape and transform your samples with ease. Say a phrase, tap a spoon, or record your favourite pet - then customize to create polished Tracks - all in high-quality 44.1 kHz/16-bit format.

Make music on the go

With its compact size, lightweight design, built-in speaker and microphone, as well as a rechargeable battery, you can take SEQTRAK anywhere - from the studio, to the stage, to the sofa. No need to worry about power outlets or tangled cables. Create, perform, and share your music - anytime, anywhere.

Create

Turn your ideas into original music.

Sound engines + effects

Double your creative potential with two versatile sound engines. AWM2 (Advanced Wave Memory 2) boasts an impressive 128-note polyphony and specializes in authentic sounds like pianos, strings, and guitars, while the four-operator FM engine produces stunning synth pads, leads, FM electric pianos, and more. Additionally, SEQTRAK includes powerful effects for a polished sound.

Sequencer

SEQTRAK's advanced Sequencer allows for intuitive and seamless composition, arrangement, and playback of musical Tracks. With its user-friendly interface, you can easily navigate and control various parameters, such as tempo, swing, and track settings.

Sound editing

Inside the included SEQTRAK app you'll find an intuitive graphic user interface that lets you quickly dive into each Track and shape your sounds with precision. Editing includes a comprehensive set of functions, including envelopes, filters, and effect manipulation, enabling you to refine your compositions with meticulous detail.

Connect

Share your music. Connect with your fans.

Performance

Take centre stage with the SEQTRAK's powerful performance features. Create arrangements on-the-fly by combining Tracks and Patterns, remixing beats, and muting/unmuting Tracks in real-time. Add polish and sparkle to your music using global effects - then control these sounds live while you perform.

Visualizer

The SEQTRAK app has a Visualizer mode that transforms your music into a captivating visual experience. With this free performance and production feature, you'll bring your music to life with stunning visuals that sync perfectly with your songs. Customize and tweak Patterns, motion effects and more, however you see fit. There's even an Augmented Reality (AR) mode that allows you to integrate 3D virtual objects into real-world live videos.

Connectivity

- Bluetooth MIDI: Connect wirelessly to the SEQTRAK App & Visualizer, enhancing convenience and mobility.

- Wi-Fi: Transfer WAV samples wirelessly, eliminating the need for cables.

- MIDI In/Out: Connect to other hardware synths, MIDI controllers, or a computer; expanding your sound options and enabling integration with external devices.

- USB-C: Establish a single cable connection for MIDI and stereo audio to a computer simplifying setup and streamlining workflow.

- AUX In: Connect to drum machines, synths, and other external sources, expanding and diversifying your sound.

*Wireless functions may not be available depending on your area. Check with your Yamaha dealer. Windows PC cannot use wireless functions.

Specs
Tone Generator: AWM2, FM: 4 operators
Maximum Polyphony: AWM2: 128, FM: 8
Wave: Preset: 800 MB (when converted to 16-bit linear format), User: 500 MB
Effects: Reverb × 12 types, Delay × 9 types, Master Effect × 85 types, Single Effect × 85 types, Master EQ 5 bands, LP-HP filters for each track

Tracks

Track Types: DRUM, SYNTH, DX, SAMPLER
Number of Tracks: 11

Sounds

Number of Sounds: Preset Sound: 2032 Preset Sampler Sound: 392 *Can be added from the SEQTRAK app
Connectivity


USB: USB Type-C (power, MIDI to host, MIDI to device, audio)
Headphones: [PHONES] (stereo mini jack)
A/D INPUT: [AUDIO IN] (stereo mini jack)
MIDI: [MIDI] IN/OUT *Only included cable can be used.

Functions
USB audio interface: [Sampling Frequency = 44.1 kHz (quantization bit depth: 24-bit)] Input: 2 channels (stereo 1 channel), Output: 2 channels (stereo 1 channel)
Bluetooth: MIDI transmission/reception (wireless capability varies by country)
Wi-Fi: Data transmission/reception with dedicated app (wireless capability varies by country) The highest SAR value: 1.11 W/kg

Sound System

Speakers: 2.3 cm, 1 W
Microphone: Internal MEMS microphone

Power Supply

Power Source: Rechargeable lithium-ion battery (2,100 mAh, 7.6 Wh) USB Power Delivery (PD) (Output voltage: 4.8 V to 5.2 V, Output current: 1.5 A or greater)
Power Consumption: 6 W
Battery life for continuous use: 3-4 hours
Battery charge time: 3-5 hours

Size/Weight

Dimensions

Width: 343 mm (13-1/2")
Height: 38 mm (1-1/2")
Depth: 97 mm (3-13/16")
Weight: 0.5 kg (1 lb 2 oz)

Packing Box

Width: 420 mm (16-9/16")
Height: 90 mm (3-9/16")
Depth: 165 mm (6-1/2")

Included accessories: USB-C to USB-C cable, dedicated MIDI Converter Cable, Quick Operation Guide, Safety Guide
Dedicated Software: SEQTRAK app
Sequencer Block - Maximum Steps: 128

Notes: *** Update- August 2024 ***

Yamaha Music is proud to announce the release of SEQTRAK App v1.0.2, a significant upgrade now available on Web and App stores worldwide. This update marks a substantial improvement in the app's functionality, speed, and overall user experience.

Transformative Enhancements in v1.0.2:

1. Revolutionized Data Syncing: Users will experience dramatically faster load times thanks to intelligent cached data usage, making workflow smoother and more efficient than ever before.
2. Advanced Sorting Capabilities: The newly implemented Packs list sorting feature empowers users with enhanced organization tools, streamlining project management and creative processes.
3. Mac User Experience Boost: Mac users will enjoy improved accessibility with the addition of [ctrl + click] functionality for context menus, aligning with platform-specific user expectations.

Critical Issues Resolved:

This update doesn't just add features; it also significantly improves stability and reliability:

- Eliminated Visualizer scene loading issues, ensuring seamless visual performances
- Perfected Visualizer Reflection parameter value retention for consistent visual outputs
- Resolved UI display inconsistencies related to parameter-lock deletion, enhancing user interface reliability
- Optimized Sampler track Destination value changes for precise audio routing
- Rectified parameter-locked effects saving for Synth tracks, preserving complex sound designs

The culmination of these improvements results in a noticeably more robust, responsive, and user-friendly SEQTRAK App. Whether you're a professional musician, a live performer, or an enthusiastic hobbyist, v1.0.2 offers a substantially improved platform for your creative endeavours.

Users can immediately access this groundbreaking update through their respective App stores or via the Web platform.


Unlock your creativity anywhere

Introducing SEQTRAK, the ultimate music creation station that empowers you to capture, create and connect with fans - from anywhere you happen to be.

Capture

Capture ideas as quickly as they come.

All-in-one system

Drums. Synths. Sound design. Sequencing. All included. With an array of features, all loaded in a compact, lightweight design, SEQTRAK allows you to start producing right away - no matter where you are. It's got everything you need. And more.

Lightning-fast workflow

SEQTRAK makes capturing ideas simple with a clear 3-part user interface and real-time, hands-on controls. You'll produce your music without menu-diving or waiting for boot times. Seize moments of inspiration and unleash your creativity in no time at all.

Extensive sounds

SEQTRAK extensive library contains over 2,000 presets. You'll find a vast collection of professionally crafted sounds - from rich pianos, to shimmering synths and thundering drums. More will be available with updates to the SEQTRAK app.

Onboard sampling

Capture your own unique sound samples effortlessly. SEQTRAK's sampler offers seven sound slots and a variety of effects, allowing you to shape and transform your samples with ease. Say a phrase, tap a spoon, or record your favourite pet - then customize to create polished Tracks - all in high-quality 44.1 kHz/16-bit format.

Make music on the go

With its compact size, lightweight design, built-in speaker and microphone, as well as a rechargeable battery, you can take SEQTRAK anywhere - from the studio, to the stage, to the sofa. No need to worry about power outlets or tangled cables. Create, perform, and share your music - anytime, anywhere.

Create

Turn your ideas into original music.

Sound engines + effects

Double your creative potential with two versatile sound engines. AWM2 (Advanced Wave Memory 2) boasts an impressive 128-note polyphony and specializes in authentic sounds like pianos, strings, and guitars, while the four-operator FM engine produces stunning synth pads, leads, FM electric pianos, and more. Additionally, SEQTRAK includes powerful effects for a polished sound.

Sequencer

SEQTRAK's advanced Sequencer allows for intuitive and seamless composition, arrangement, and playback of musical Tracks. With its user-friendly interface, you can easily navigate and control various parameters, such as tempo, swing, and track settings.

Sound editing

Inside the included SEQTRAK app you'll find an intuitive graphic user interface that lets you quickly dive into each Track and shape your sounds with precision. Editing includes a comprehensive set of functions, including envelopes, filters, and effect manipulation, enabling you to refine your compositions with meticulous detail.

Connect

Share your music. Connect with your fans.

Performance

Take centre stage with the SEQTRAK's powerful performance features. Create arrangements on-the-fly by combining Tracks and Patterns, remixing beats, and muting/unmuting Tracks in real-time. Add polish and sparkle to your music using global effects - then control these sounds live while you perform.

Visualizer

The SEQTRAK app has a Visualizer mode that transforms your music into a captivating visual experience. With this free performance and production feature, you'll bring your music to life with stunning visuals that sync perfectly with your songs. Customize and tweak Patterns, motion effects and more, however you see fit. There's even an Augmented Reality (AR) mode that allows you to integrate 3D virtual objects into real-world live videos.

Connectivity

- Bluetooth MIDI: Connect wirelessly to the SEQTRAK App & Visualizer, enhancing convenience and mobility.

- Wi-Fi: Transfer WAV samples wirelessly, eliminating the need for cables.

- MIDI In/Out: Connect to other hardware synths, MIDI controllers, or a computer; expanding your sound options and enabling integration with external devices.

- USB-C: Establish a single cable connection for MIDI and stereo audio to a computer simplifying setup and streamlining workflow.

- AUX In: Connect to drum machines, synths, and other external sources, expanding and diversifying your sound.

*Wireless functions may not be available depending on your area. Check with your Yamaha dealer. Windows PC cannot use wireless functions.

Specs
Tone Generator: AWM2, FM: 4 operators
Maximum Polyphony: AWM2: 128, FM: 8
Wave: Preset: 800 MB (when converted to 16-bit linear format), User: 500 MB
Effects: Reverb × 12 types, Delay × 9 types, Master Effect × 85 types, Single Effect × 85 types, Master EQ 5 bands, LP-HP filters for each track

Tracks

Track Types: DRUM, SYNTH, DX, SAMPLER
Number of Tracks: 11

Sounds

Number of Sounds: Preset Sound: 2032 Preset Sampler Sound: 392 *Can be added from the SEQTRAK app
Connectivity


USB: USB Type-C (power, MIDI to host, MIDI to device, audio)
Headphones: [PHONES] (stereo mini jack)
A/D INPUT: [AUDIO IN] (stereo mini jack)
MIDI: [MIDI] IN/OUT *Only included cable can be used.

Functions
USB audio interface: [Sampling Frequency = 44.1 kHz (quantization bit depth: 24-bit)] Input: 2 channels (stereo 1 channel), Output: 2 channels (stereo 1 channel)
Bluetooth: MIDI transmission/reception (wireless capability varies by country)
Wi-Fi: Data transmission/reception with dedicated app (wireless capability varies by country) The highest SAR value: 1.11 W/kg

Sound System

Speakers: 2.3 cm, 1 W
Microphone: Internal MEMS microphone

Power Supply

Power Source: Rechargeable lithium-ion battery (2,100 mAh, 7.6 Wh) USB Power Delivery (PD) (Output voltage: 4.8 V to 5.2 V, Output current: 1.5 A or greater)
Power Consumption: 6 W
Battery life for continuous use: 3-4 hours
Battery charge time: 3-5 hours

Size/Weight

Dimensions

Width: 343 mm (13-1/2")
Height: 38 mm (1-1/2")
Depth: 97 mm (3-13/16")
Weight: 0.5 kg (1 lb 2 oz)

Packing Box

Width: 420 mm (16-9/16")
Height: 90 mm (3-9/16")
Depth: 165 mm (6-1/2")

Included accessories: USB-C to USB-C cable, dedicated MIDI Converter Cable, Quick Operation Guide, Safety Guide
Dedicated Software: SEQTRAK app
Sequencer Block - Maximum Steps: 128
